Bristan VAC BAS C MT (D4) Installation Instructions & User Manual

Specifications

Cold Water Supply
Dynamic Water Pressure
Min: 0.2 bar
Max: 5.0 bar
3.0
2.0 2.0 3.0
1.0 4.0 4.0
1.0
0.2 5.0 0.2 5.0
Pressure Pressure
BAR BAR
Min: 5°C Max: 25°C
Maximum Static Pressure: 10.0 bar
Tools You'll Need
Phillips Screwdriver Adjustable Spanner

Prior to Installation

All products manufactured and supplied by Bristan are safe
provided they are installed, used correctly and receive regular
maintenance in accordance with these instructions.
This product has been tested to the Water Regulations Advisory
Scheme (WRAS) and satisfies the requirements of the Water
Supply (Water Fittings) Regulations 1999 and current bylaws.
For full Installation Requirements & Notes (IRN)
please visit wras.co.uk/directory.
We recommend isolation valves to be fitted to the inlet water
supplies to ensure ease of future maintenance.
Before installing these taps the water supply must be thoroughly
flushed in order to remove any swarf, solder etc.
This product must not be modified in any way as this will
invalidate the guarantee.

Installation Instructions

& User Guide
Please leave these instructions
with the end user
Product code: VAC BAS C MT (D4)
Inlet Water Temperature Inlet Connections
Hot Water Supply
Max
65°C 80°C
25°C
60°C
5°C
60-65°C 80°C
recommended Maximum
Hexagonal Keys

Pack Contents

x1
1x
x1
x1

Spare Parts

To replace any spare parts
for your tap, why not
scan the QR Code or
visit www.bristan.com
and search for your product.
Installation
1
Fit the mixer body to
the basin using the
'C' plate fixing kit.
3
M12 x 15mm
Copper Tails
Once secured to
the basin, connect
the hot and cold
water supplies to
the threaded tails.
5
x2
x1
x1
Place the washer and waste body plate
onto the horizontal arm. Screw the waste
body plate onto the lower waste body.
Place the washer
2
over the hole in the
basin and feed the
mixer body and tails
through.
4
Fit the pop up waste,
with the flat washer
below and the shaped
washer above the basin.
6
Push the vertical
rod through the
back of the basin
tap.
Connect the rods
using the pop up
connector. Tighten
screws to secure.
