- Page 1 Crestron SRD-AMP-1 High-Gain Line Amplifier Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2008 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Crestron SRD-AMP-1 Contents High Gain Line Amplifier: SRD-AMP-1 Introduction...1 Block Diagrams ...2 Specifications...3 Included Items ...3 Industry Compliance...4 Installation ...4 Problem Solving...5 Troubleshooting...5 Further Inquiries ...6 Future Updates...6 Return and Warranty Policies ...7 Merchandise Returns / Repair Service...7 CRESTRON Limited Warranty...7 Installation Guide –... -
Page 5: Crestron Srd-Amp
Crestron SRD-AMP-1 High Gain Line Amplifier: SRD-AMP-1 Introduction The SRD-AMP-1 is an inline amplifier intended for use in overcoming cable and splitter losses in a Crestron distribution network. It is rated to provide 16 dB (typical) of gain in the satellite radio band (2320-2345 MHz), and is powered from the DC bias voltage (4.5 VDC to 6.5 VDC nominal) provided by the antenna connection on the satellite radio tuner downstream. -
Page 6: Block Diagrams
High Gain Line Amplifier Block Diagrams The following diagrams illustrate three typical installation configurations using the SRD-AMP-1 line amplifier. Single SRD-AMP-1 Installation Double SRD-AMP-1 Installation Triple SRD-AMP-1 Installation 2 • High Gain Line Amplifier: SRD-AMP-1 Crestron SRD-AMP-1 Installation Guide – DOC. 6720A... -
Page 7: Specifications
Crestron SRD-AMP-1 Specifications Following are specifications for the SRD-AMP-1. SRD-AMP-1 Specifications SPECIFICATION Gain Current consumption Power passing Environmental temperature Humidity Overall dimensions: Height Width Depth Included Items The items included in the SRD-AMP-1 are listed and shown below. SRD-AMP-1 Included Items DESCRIPTION Amplifier with Mounting Screws F-male to F-male Coupler... -
Page 8: Industry Compliance
High Gain Line Amplifier Industry Compliance As of the date of manufacture, the SRD-AMP-1 has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling. Installation Refer to the illustrations on page 2, and, using the screws provided, orient and mount the amplifier(s) appropriately according to the distance between the antenna and the radio. -
Page 9: Problem Solving
Crestron SRD-AMP-1 Problem Solving Troubleshooting The table after this paragraph provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. SRD-AMP-1 Installation Troubleshooting TROUBLE No signal reception. Radio display shows: “Antenna Disconnected”, or “Acquiring Signal”... -
Page 10: Further Inquiries
High Gain Line Amplifier SRD-AMP-1 Installation Troubleshooting (Continued) TROUBLE Limited reception or channels available for XM and/or SIRIUS tuners. Further Inquiries If you cannot locate specific information or have questions after reviewing this guide, please take advantage of Crestron's award winning customer service team by calling Crestron at 1-888-CRESTRON [1-888-273-7876]. -
Page 11: Return And Warranty Policies
Crestron SRD-AMP-1 Return and Warranty Policies Merchandise Returns / Repair Service 1. No merchandise may be returned for credit, exchange or service without prior authorization from CRESTRON. To obtain warranty service for CRESTRON products, contact an authorized CRESTRON dealer. Only authorized CRESTRON dealers may contact the factory and request an RMA (Return Merchandise Authorization) number. - Page 12 Crestron Electronics, Inc. Installation Guide – DOC. 6720A 15 Volvo Drive Rockleigh, NJ 07647 (2021527) Tel: 888.CRESTRON 08.08 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
