FM3612 First Start
Main Page
>
EOL Products
Contents
1 How to insert SIM card and connect battery
How to insert SIM card and connect battery
1.
Gently open
FM3612
FM3612
2.
Remove
3.
Insert SIM card as shown.
4.
Attach battery.
5.
Attach top housing cover.
2x6 socket pinout
>
FM3612
> FM3612 First Start
case using screwdrivers.
case.
Advertisement
Table of Contents
Related Manuals for Teltonika FM3612
Summary of Contents for Teltonika FM3612
- Page 1 FM3612 First Start Main Page > EOL Products > FM3612 > FM3612 First Start Contents 1 How to insert SIM card and connect battery 2 2x6 socket pinout 3 PC Connection (Windows) 4 How to install USB drivers (Windows) 5 Configuration (Windows)
- Page 2 Data for 1–Wire devices. INPUT 5 RX EXT (LVCAN - RX). PC Connection (Windows) Power-up FM3612 with DC voltage (10 – 30 V) power supply using supplied power cable. LED’s should start blinking, see “LED behaviour description”. Connect device to computer using Micro-USB cable: You will need to install USB drivers, see "How to install USB drivers...
- Page 3 After connection to Configurator recommended configuration will be displayed: In Advanced Configuration mode FM3612 is more configurable. FM3612 has one user editable profile, which can be loaded and saved to the device. After any modification of configuration the changes need to be saved to device using Save button. Main buttons offer following functionality: Connect / Disconnect –...
- Page 4 GND vehicle computer. Connecting the GND at an arbitrary point to the mass of the car is unacceptable, as static and dynamic potentials on the line GND will be unpredictable, which can lead to unstable FM3612 operation and even its failure.
- Page 5 The device must be firmly fastened in a predefined location. The programming must be performed using a PC with autonomic power supply. The device is susceptible to water and humidity. Installation and/or handling during a lightning storm is prohibited. https://teltonika-gps.com/product/fm3612...
