4 .3 ADB components

This section identifies the main ADB components.
q
r
t t
1 ADB components
Foam dividers
q
Ceiling template
w
ADB cover
e

4 .4 Thermostat compatibility

This section identifies the thermostat displays
compatible with this ADB.
Display
Connect Essential Thermostat
Connect Pro Thermostat
6
Rooftop Air Conditioner (Air Distribution Box, Wall Thermostat Controls)
w
t t
e
Long bolts
r
Air filter
t
Model
INC1LED
INC1015RD

4 .5 Rooftop component dimensions

This section provides the external dimensions and
clearance measurements of the rooftop component.
q q
w w
r
t y y
2 FreshJet (FJX3 and FJX4 series)
14.4 in. (366 mm)
q
29.6 in. (752 mm)
w
27.6 in. (701 mm)
e
18.0 in. (457 mm)
r
clearance
Air flow clearance area
t
(shaded)
e e
i i
u u
Center line of unit
y
Roof opening
u
Front of unit
i
