Summary of Contents for Bartscher 109557
- Page 1 Instructions for Installation, Use and Maintenance 109557 COD.: 3050ED APPLICARE ETICHETTA Ed. 01 - 02/2019 MATRICOLA...
- Page 2 Thank you for choosing our machine. The instructions for installation, maintenance and use found on the following pages have been prepared to ensure a long life and perfect operation of your unit. Please, do follow the instructions carefully. We have designed and built this machine using the latest innovative technologies. Now you shall take good care of it.
-
Page 3: Table Of Contents
TRANSLATION OF THE ORIGINAL INSTRUCTIONS CONTENTS Page WARNINGS 1. MACHINE INSTALLATION 1.1 Dataplate INSTALLER SECTION 1.2 Receiving the machine 1.3 Water connection 1.3.1 Water supply characteristics 1.4 Electrical connection 1.5 Temperature adjustment 1.6 Rinse aid dispenser operation 1.7 Steam evacuation 1.8 Installation 1.8.1 Positioning the machine 1.9 Optional programming... -
Page 4: Warnings
WARNINGS This instruction booklet must be kept with the machine for future consultation. If this machine is sold or transferred to other users, make sure the booklet always goes with the unit so that the new owner can have all the necessary information on operations and all relevant instructions. - Page 5 Shut the water supply valve(s). Disregarding the aforesaid prescriptions is a serious misuse and can cause damages and injures to property and people, and will relieve the manufacturer from whatever liability. • The user shall not carry out any repair and/or maintenance operations. In any case contact qualifi...
-
Page 6: Machine Installation
WARNING: Once the installation is complete, it is recommended to detach and preserve the installer’s guide section of this manual for future reference. 1. MACHINE INSTALLATION 1.1 Dataplate RoHS IPXX ° kcal Model FAMIGLIA PRODOTTO FAMILY PRODUCT FAMILLE DU PRODUIT FAMILIA PRODUCTO ANNO E=2010 - 2011... -
Page 7: Installer Section
INSTALLER SECTION 1.2 Receiving the machine After removing the packaging, make sure that the machine was not damaged during transportation. Should this be the case, please notify the seller immediately. If safety has been compromised, do not install the machine. Double check the fi... -
Page 8: Electrical Connection
INSTALLER SECTION 1.4 Electrical connection The electrical connection shall be carried out by qualifi ed personnel, in accordance to the local laws in force. Make sure that the supply voltage is the same as written on the machine plate. A suitable omni-polar one-way switch shall be installed and sized according to the absorption provided, in order to completely guarantee the disconnection from the supply mains, under “category III”... -
Page 9: Steam Evacuation
INSTALLER SECTION For proper chemical product dosage see the chemical-product manufacturer recommendations (see also paragr. 5.3). N.B.: for each screw rotation the rinse product dosage varies by 1,6 cm pulled into the hose, equal to 0,2 cc/rotation (about 0,21 g/rotation with product density of 1,05 g/cc). The rinse aid dispenser cannot function properly if there is a slope of over 80 cm between the bottom of the machine and the canister. -
Page 10: Detergent Dispenser Retrofit
INSTALLER SECTION 2. DETERGENT DISPENSER RETROFIT 2.1 Electrical connection Read the electric diagram, enclosed with the machine. ATTENTION: output arranged for electrical dispenser 230V max 50W. 2.2 Pipe connection a) A Ø12mm hole must be drilled on the front side of the appliance. On some models the hole has already been made and is plugged with a plastic cap. -
Page 11: Technical Data And Useful Information On Pumps
INSTALLER SECTION 3. TECHNICAL DATA AND USEFUL INFORMATION ON PUMPS 3.1 Washing pump When the dishwasher has not been used for some time, check that the washing pump turns freely. To do this, operate using a screwdriver in the special slot on the ventilating side of the motor shaft. In case of blocking, turn the main switch off... - Page 12 INSTALLER SECTION page 30...
-
Page 13: User Section
USER SECTION 4. CONTROL PANEL AND RELATIVE SYMBOLS Cycle Light Indicator START push-button to start up cycle / select cycle ON / STAND BY indicator Drain Pump indicator Drain Push-button (optional) Switching – On / STAND BY button Washing type 3 Washing type 2 Washing type 1 Set temperature reached, signal... -
Page 14: Cutlery And Crockery Loading
USER SECTION 5.1 Cutlery and crockery loading Before cutlery and crockery loading in the machine, coarsely clean them from the leftover food. It isn't necessary to rinse the cutlery an crockery under water. ATTENTION: Do not wash articles polluted with petrol, paint, chips of steel or iron, ash, sand, wax, lubricant grease. -
Page 15: Drain Pump System (Optional)
USER SECTION 5.4 Drain pump system (optional) To drain completely the wash-tank keep the machine ON, extract the overfl ow pipe and shut the hood. Press the button (see chap. 4) for at least one second: the discharge pump will automatically drain the wash-tank. Once the machine is completely drained, the machine will turn off... -
Page 16: Maintenance
USER SECTION 6. MAINTENANCE WARNING: The machine is not protected against pressurized water jets. Do not use pressure cleaning system against the machine. It is recommended to contact the seller of chemicals for proper cleaning instructions, in order to have detailed indications on methods and products for the correct periodical machine sanitation. -
Page 17: Alarms
USER SECTION 7. ALARMS Alarms will be displayed by the lighting of LEDs. according to their typology. TYPE OF ALARM CAUSE REMEDIES Flashing of the cycle lamp No water fi lling: when it is forgotten to put the overfl ow Verify the full opening of the water inlet pipe in the machine or the water fi... -
Page 18: Ecological Aspects
USER SECTION 9. ECOLOGICAL ASPECTS 9.1 Recommendations for optimal use of energy, water and additives Use the machine fully loaded when possible: This shall prevent detergent, rinse aid, water and energy consumption waste. Detergent and rinse-aids: Use detergents and rinse-aid chemicals with high biodegradability, to best respect the environment. - Page 19 USER SECTION Type of Problem Possible Causes Cure Glasses or dishes are not Not enough rinse aid. Check the canister level and the ballast is properly positioned properly dried. or contact che Technical Assistance The rack is not suitable for the pots Use the suitable rack which gives the pots and tools an or the tools.
