Configurator. Make sure that Micro-SIM card cut-off corner is pointing forward to slot. Remove the adhesive tape protection. Place the battery inside the casing of the FMC920. Make sure the adhesive tape sticks to the casing. Connect the internal battery to the FMC920 PCB.
Page 2
DOUT 1 Digital output. Open collector output. Max. 3,3 A DC. Configuration (Windows) At first FMC920 device will have default factory settings set. These settings should be changed according to the user's needs. Main configuration can be performed via Teltonika Configurator software.
Page 3
Various and etc. FMC920 has one user editable profile, which can be loaded and saved to the device. After any modification of configuration the changes need to be saved to device using Save to device button. Main buttons offer following functionality: Load from device –...
Page 4
Installation photos FMC920 is the device that has internal GNSS and GSM antenna. Device should be mounted with the sticker view to the open sky (metal free). FMC920 area with sticker is shown in figure below:...
Page 5
FMC920 can be mounted under the plastic panel behind the front window, with the sticker direction to a window (sky). It is recommended to place FMC920 behind dashboard as close to the window as possible. A good example of GNSS antenna placement is displayed in a picture below (area colored green).
Page 6
The device is designed to be mounted in a zone of limited access, which is inaccessible to the operator. All related devices must meet the requirements of EN 60950-1 standard. The device FMC920 is not designed as a navigational device for boats. Precautions Do not disassemble the device.
