User's Manual
2
Getting Started
The figure below shows the physical appearance of AudioCodes' RX-PANEL Meeting Room
Scheduler.
See
here
for more information about the device.
2.1
Before Getting Started
Make sure you received the following in the shipped box:
Ethernet cable
4 screws, 4 wall anchors, 1 template (for concrete wall mount)
Glass-mounting bracket (for glass partition mount)
Note:
Power Supply (PS) is not supplied but can be ordered separately.
2.2
Positioning
Position the device at the entrance to a conference room. Mount the device on a:
concrete wall -or-
glass partition
Note:
Note that the device is suitable for mounting at a height no more than 2m.
Version 2.2
9
2. Getting Started
RX-PANEL
