Related Manuals for Cylinda F 2285N A+
Summary of Contents for Cylinda F 2285N A+
- Page 1 user manual bruksanvisning CYLINDA_pase_A5.indd 1 2012-06-14 14.20 F 2285N A+ F 2285N A+ +...
-
Page 3: Table Of Contents
Index BEFORE USING YOUR FRIDGE ................. 2 General warnings ....................... 2 Safety warnings ........................4 Installing and operating your freezer ................5 Before Using your Freezer ....................6 Information on No-Frost Technology ................6 USAGE INFORMATION ..................7 Operating your Freezer ...................... 7 MODE Button .......................... -
Page 4: Before Using Your Fridge
CHAPTER 1. BEFORE USING YOUR FRIDGE General warnings WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. - Page 5 - bed and breakfast type environments; - catering and similar non-retail applications • If the socket does not match the refrigerator plug, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. •...
-
Page 6: Safety Warnings
Old and out-of-order fridges • If your old fridge has a lock, break or remove the lock before discarding it, because children may get trapped inside it and may cause an accident. • Old fridges and freezers contain isolation material and refrigerant with CFC. Therefore, take care not to harm environment when you are discarding your old fridges. -
Page 7: Installing And Operating Your Freezer
• Do not re-freeze the frozen goods after being melted. This may cause health issues like food poisoning. • Do not cover the body or top of fridge with lace. This affects the performance of your fridge. • Fix the accessories in the fridge during transportation to prevent damage to accessories. -
Page 8: Before Using Your Freezer
Before Using your Freezer • When it is operated for the first time or after transportation, keep your freezer in the upright position for 3 hours and plug it on to allow efficient operation. Otherwise, you may damage the compressor. •... -
Page 9: Usage Information
CHAPTER 2. USAGE INFORMATION Operating your Freezer (For some models) SET BUTTON POWER LAMP FREEZER COMPARTMENT TEMPERATURE INDICATOR FAST FREEZING MODE BUTTON ECONOMY MODE MODE LAMP LAMP MODE Button • Mode button allows switching between Freezer Department Indicator, Fast Freezing Mode Lamp, Economy Mode Lamp. -
Page 10: Freezer Department Temperature Adjustment And Activating Fast Freezing Mode
Freezer Department Temperature Adjustment and Activating FAST FREEZING Mode • Initial temperature value for Freezer Department Indicator is -18 • Press mode button once. • The set value for freezer Department indicator starts to flash when you press this button. •... -
Page 11: While Sf Mode Is Selected
While SF mode is selected: To cancel SF Mode and continue with previous set value: Please press Mode Button 1 times and wait for 5 secs. SF mode will be cancelled and appliance will start to work according to previous set value. To cancel SF Mode and continue with new set value: Please press Mode Button 1 time and in 5 sec, push set button until you see set value you want and wait for 5 secs. -
Page 12: Warnings About Temperature Adjustments
Warnings about Temperature Adjustments • Your temperature adjustments will not be deleted when an energy breakdown occurs. • Do not pass to another adjustment before completing an adjustment • Temperature adjustments should be made according to the frequency of door openings, the quantity of food kept inside the fridge and ambient temperature of the place of your fridge. - Page 13 • For storing the frozen food; the instructions shown on frozen food packages should always be followed carefully and if no information is provided, food should not be stored for more than 3 months from the purchased date. • Maximum load; if you want to load large quantities and use the maximum net capacity, you can remove the drawers (Except the bottom one).
- Page 14 For A+ models If there is a power cut or malfunction, do not open the door. This will help maintain the temperature inside the freezer, ensuring that foods are conserved for about 9,5 hours at 25°C ambient temperature and about 8 hours at 32°C ambient temperature. Do not re- freeze food that is defrosting or that has already been defrosted.
- Page 15 Storage Thawing period at FRUITS AND Preparation Duration room temperature VEGETABLES (months) (hours) Remove outer leaves and cut core in pieces. Then Can be used without Cauliflower store in a container of water 10-12 waiting to be thawed with a small amount of lemon juice.
- Page 16 Storage Dairy Products Preparation Duration Storage Conditions and Pastries (months) Only homogenized Milk product They may be left in their original packages for Cheese - other short time storage. They In the form of slices than white cheese should also be wrapped in plastic foil for long term storage.
-
Page 17: Cleaning And Maintenance
CHAPTER 4. CLEANING AND MAINTENANCE • Make sure to unplug the freezer before starting to clean it. • Do not wash your freezer by pouring water onto it. • You can wipe the inner and outer sides of your appliance with a soft cloth or a sponge using warm and soapy water. -
Page 18: Shipment And Repositioning
CHAPTER 5. SHIPMENT AND REPOSITIONING • Original package and foam may be kept for re-transportation (optionally). • You should fasten your freezer with thick package, bands or strong cords and follow the instructions for transportation on the package for re-transportation. •... -
Page 19: Before Calling Service
CHAPTER 6. BEFORE CALLING SERVICE If your fridge is not operating ; • Is there any electrical faults? • Is the plug is placed properly in the receptacle? • Is the fuse of the receptacle that the plug is plugged or the main fuse blown? •... - Page 20 Temperature Warning: The temperature display flashes “LF” and an audible warning sounds, when the temperature in the freezer compartment is too warm. A rise in the temperature may be caused by; • Frequent door opening for long periods of time •...
- Page 21 If the edges of freezer cabinet that the door joint contact are warm; • Especially in summer (hot weather), the surfaces that the joint contact may get warmer during the operation of the compressor, this is normal. If humidity builds up inside the freezer; •...
-
Page 22: Advice For Saving Energy
Advice for Saving Energy • Do not install the appliance close to heat producing appliances. Such as cooker, oven, dishwasher or radiator, and locate the appliance in the coolest part of the room. • Locate the appliance ina cool well ventilated room and make sure that the air openings of the appliances are not obstructed. -
Page 23: The Parts Of The Appliance And The Compartments
THE PARTS OF THE APPLIANCE AND THE CHAPTER 7. COMPARTMENTS In some models there is a shelf with icematic in the top basket. This presentation is only for information about the parts of the appliance. Parts may vary according to the appliance model. 1. - Page 28 • Gå in på www.cylinda.se eller • Serienummer • Namn och adress • Ring 0771-25 25 00 (endast lokaltaxa) • Inköpsdatum • Ditt telefonnummer Våra tekniker är specialutbildade på Cylindaprodukter och vi använder bara originalreservdelar. Elektroskandia Sverige AB, Cylinda, 191 83 Sollentuna 5218XXXX...
