  • Page 1 Instruction manual MOTOmed letto2 - valid from Software Version 3.30 englisch...
  • Page 2 Please use the MOTOmed only after you have read the instruction manual. If you should not understand the language of the present version, please re- quest the instruction manual in your national language. Benutzen Sie das MOTOmed erst, nachdem Sie die Gebrauchsanweisung gelesen haben.
  • Page 3 MOTOmed letto...
  • Page 5 Supported by the latest computer technology it is an innovative quality product ”made in Germany” by RECK. This user manual will help you to get to know the MOTOmed letto2. It will guide you through the functions of the MOTOmed letto2 and will give you some tips and suggestions on how to use the new movement ther- apy device so as to gain optimal benefit from the training.

  • Page 7: Table Of Contents

    Introduction Page Set up, Transport Operation Accessories Troubleshooting Cleaning and Care Technical specifictions, Symbols Warranty Service Safety precautions EMC information Index NTRODUCTION...

  • Page 9: Introduction

    Introduction Page Appolication Normal use Restriction of liability NTRODUCTION...
  • Page 10 Application The MOTOmed letto2 is suitable only for the active and passive movement of a person’s lower extremities while being in a lying position. During the training the MOTOmed letto2 can be operated with a remote control or with an operat- ing panel.
  • Page 11 Restrictions of liability The manufacturer and his distributors don’t assume liability for conse- quences of abuse and misuse neglect of this instruction manual wanton damage and reckless usage over-intensive training use with unsuitable beds or couches use without prior consultation of the responsible doctor and ...

  • Page 13: Set Up, Transport

    Set up, transport Page Set up Moving / transporting Stand by mode ET UP RANSPORT...
  • Page 14 Pay attention not to overrun the mains cable. Stand-by mode Please plug the the mains plug of the MOTOmed letto2 into a wall socket. The green light next to the “start/stop“ button on the display module is now blinking for 6 seconds. Then blinking changes to a continuous light, the MOTOmed letto2 is now in stand-by mode.

  • Page 15: Operation

    Operation Page In general Fixing the MOTOmed to the bed Insertion and securing of legs Operation PERATION...
  • Page 16 At low temperatures (below 0 °C/32 °F) the display can be affected, this will not however lead to any long-term damage. Fixing the MOTOmed to the bed The MOTOmed letto2 is attached to the footboard or footend of the bed. Proceed as follows: Open both screw knobs at the bed mount and open the clamp.
  • Page 17 Open the wing screw of the height adjust- ment to raise the MOTOmed letto2 up to the required height. Open the wing screw at the handlebar section, slide it up as high as possible holding with one hand the handlebar in position. Fasten the wing screw with the other hand.
  • Page 18 You can adjust the pedal unit of the MOTOmed letto2 towards the patient by opening the screws of the horizontal adjustment and moving the pedals towards or away from the patient. Don’t forget to tighten the screws again afterwards. Attention: Regularly check the functioning of the pull-out prevention string securing the pedal unit from dropping out.
  • Page 19 Operation of MOTOmed letto2 PERATION...
  • Page 20 Last, press again the red “start/stop”-button  to switch off the MOTOmed. Start of training Press button “start/stop“ . Automatically the foot shells start moving slowly and the display  turns on. The MOTOmed letto2 starts with a short and gentle warm-up phase. Adjustment of speed With the “speed”-button the revolutions of the foot shell per minute can be...
  • Page 21 “You are cycling yourself “. Upon pressing the buttons “light“ (small weight)  and “heavy“ (big weight)  you can shift to a lower or higher gear. The MOTOmed letto2 provides 20 gears. Whenthe patient would like to get moved by the MOTOmed letto2 again, just tell him to stop cycling.
  • Page 22 Training suggestions/hints At the end of any training there are further MOTOmed letto2 training sug- gestions available. Just press the button “hints“  to read them through. Remark: The training suggestions are general advice. A doctor or therapist has to decide if they apply to special conditions of the patient as well.
  • Page 23 Duration of training It is possible to pre-set the duration of the training period, similar to setting a timer. When the set training time is over, the MOTOmed letto2 stops au- tomatically. The duration of training can be changed at all times.
  • Page 24 Starting parameters If you want to save the parameters (SpasmControl, speed, duration, gear, rotation forward/backward, motor power) of the MOTOmed letto2 you set individually during training proceed as follows: Primarily set the values that you would like to save.
  • Page 25 Adjust the volume By this function you can adjust the acoustic feedback during pressing buttons, i.e. when choosing a gear. Press the button “extras“  two times, followed by the button “adjust vo- lume“. Now you can adjust the volume by pressing the buttons “+“ or “-“. Change of duration of displayed information Displayed information during the MOTOmed training changes at certain intervals (the manufacturer’s setting is 15 seconds).
  • Page 26 Maximum speed The maximum speed function allows you to limit the speed that should not be exceeded during active training. To set the maximum speed press the “extras“  button three times, fol- lowed by the “max rpm“ button. Now you can set the maximum speed with the buttons “-“ and “+“. Language option The language option function allows the selection between a wide range of available languages.

  • Page 27: Accessories

    Accessories Page TrainCare leg guides with knee protection Further accessories Ankel joint adjustment with SlidingScales Pedal radium quick adjustment CCESSORIES...
  • Page 28 Leg guides with knee protection TrainCare For paralysed or unconscious patients it is absolutely vital that you use the TrainCare leg guides. The TrainCaire leg guides support the lower legs and prevent them from unintentional movement to the side, as they also prevent the knee joints from overstretching and blocking.
  • Page 29 Set the angle of the radial adjustment on both sides and fasten the fixing screws tight again. Before you start the MOTOmed letto2, please check if the legs of the patient get enough hold with the settings of the leg guides.
  • Page 30 Further accessories Item n° 149 Ankle joint adjustment The Ankle Joint Control enables precise, targeted movement of the ankle joint. Targeted ankle joint movement can significantly increase blood circu- lation throughout the body, especially in the legs. Item n° 507 Pedal radius quick adjustment With the pedal radius quick adjustment, you are able to adjust the range of movement/size of orbit of the foot shells.

  • Page 31: Troubleshooting

    Troubleshooting Page Safety instructions for troubleshooting The MOTOmed letto2 is jerky, runs uneven or makes noises The MOTOmed letto2 does not work at all or the operating panel does not react Error reports on the display Overheating The motor blocks...
  • Page 32 5. Are all Allen screws of the pedal radius quick adjustment tightened sufficiently? 6. Please check the position of the MOTOmed letto2. The safety foot musn’t touch the bed. 7. For stroke patients, it is possible that the pedal movement is uneven due to the uneven sides of the body (especially when using a low gear).
  • Page 33 The MOTOmed letto2 does not work at all or the operating panel does not react Please check whether the cockpit is mounted correctly and whether the main cable is plugged into the main socket (electric outlet) correctly. Also check the functioning of the main socket (electric outlet) by connecting another electric device to it.
  • Page 34 The motor blocks This error message appears as soon as the SpasmControl is activated 25 times at short intervals or if the motor was locked for a period of 3 minutes. Please pull the mains plug out of the plug socket and put it in again. Then please check if the motor power is adjusted too low or if the pedal radius is adjusted too high in relation to the patient’s condition.

  • Page 35: Cleaning And Care

    (electric outlet) so that the power supply is completely discon- nected. Clean the surface of the MOTOmed letto2 only with a soft and dry cloth. It is absolutely crucial that no water enters the device. If several users use the MOTOmed letto2, please disinfect the handlebar and the operating panel with a suitable disinfectant.

  • Page 37: Technical Specifictions, Symbols

    Technical specifications, symbols General data for all MOTOmed viva2 Measurements and weight (basic model) Height: 107–133 cm / 42-52,5 inches Width: 51 cm / 20 inches Depth: 85 cm / 33,5 inches Weight: 61 kg / 134,5 lb Ambience conditions Operation: 0 °C to +40 °C / 32 °F - 100 °F Storage:...
  • Page 38 Technical data for 115 V~ devices Power requirement Mains voltage: 115 V~ Mains appliance: 50/60 Hz Power consumption Non-operating: max. 7,5 VA Operating: max. 185 VA Class of protection class I, Type B Technical data for 100 V~ devices Power requirement Mains voltage: 100 V~ Mains appliance:...
  • Page 39 Attention, consult ACCOMPANYING DOCUMENTS Attention! Follow operating instructions The MOTOmed letto2 meets the standards for medi- cal devices 93/42/EWG Construction year of the MOTOmed letto2 (e.g. 2007).

  • Page 41: Warranty

    Warranty The RECK company offers a warranty on material and manufacturing faults of 12 months on the MOTOmed letto2 valid as of day of deli- very or invoice date. During the 12 months warranty period the RECK Technik GmbH & Co.

  • Page 43: Service

    MOTOmed representative. If you have friends or family to whom you would like to recommend the MOTOmed letto2, we are always happy to send information about the MOTOmed MovementTherapySystems, either to you or directly to your friends – at no cost and with no obligation.

  • Page 45: Safety Precautions

    Safety precautions The first time use of the MOTOmed letto2 must always be supervised by a qualified person giving instructions. Assessment of MOTOmed traininig in regard to the patient’s health situation as well as the time, duration and intensity of the training periods have to be discussed with a doctor and physiotherapist before start of the training.
  • Page 46 5 rpm, the parameter speed of the starting parame- ter has to be reduced after the start. The use of the MOTOmed letto2 has to be adapted to individual health con- ditions. Training suggestions by the manufacturer or its distributors are given without guarantee.
  • Page 47 Under the influence of alcohol, medicine or drugs, the health risks of using the MOTOmed letto2 can be increased. Such usage is advised against. Place the MOTOmed letto2 so that it cannot tilt or fall over and cause inju- ries to somebody. Don’t put weight on only one side of the MOTOmed letto2.
  • Page 48 Never try to grab hold of any moving parts! The MOTOmed letto2 must not be moved while legs are inserted or secured to the device. Please train only after you’ve switched on the MOTOmed letto2! Children should never use the MOTOmed letto2 without supervision.
  • Page 49 MOTOmed letto2 to is also properly earthed. The MOTOmed letto2 must only be used if the power cable is free from grazes, bruises, porous points, kinks or buckles –...
  • Page 50 When cycling actively in small gears, the function “ServoCycling“ can be recognized easily. This means that through the support of the motor the speed of the MOTOmed letto2 can be significantly increased by applying only little muscle strength. Thus, the effect of the muscle force applied is enforced by the motor.

  • Page 51: Emc Information

    EMC information Page Manufacturer’s declaration – electromagnetic emmissions Manufacturer’s declaration – electromagnetic immunity Recommended separation distance EMC I NFORMATION...
  • Page 52 The manufacturer states that the mains cable of the MOTOmed letto2 com- plies with the requirements of the EN 60601–1–2:2001. If the original mains cable coming with the MOTOmed letto2 is nottaken into use the electromagnetic emission of the MOTOmed letto2 may increase and the immunity may decrease.
  • Page 53 Manufacturer’s declaration – electromagnetic immunity The MOTOmed letto2 is suitable for use in the specified electromagnetic environment. The customer and/or the user of the MOTOmed letto2 should assure that it is used in an electromagnetic environment as described below. Immunity Test...
  • Page 54 To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survy should be considered. If the measured field strength in the location in which the MOTOmed letto2 is used exceeds the applica- ble RF compliance level above, the MOTOmed letto2 should be observed to verify normal operation. If abnormal per- formance is observed, additional measures may be necessary, such as re-orienting or relocating the MOTOmed letto2.
  • Page 55 Recommended separation distances between portable and mobile RF communications equipment and the MOTOmed letto2. The MOTOmed letto2 is supposed to be operated in an electromagnetic environment where the RF interference is controlled. The customer or user of the MOTOmed letto2 can help avoid electromagnetic interference by keeping the separation distances between portable and mobile RF commu- nications equipment (transmitters) and the MOTOmed letto2 –...
  • Page 56 NTRODUCTION...

  • Page 57: Index

    Index Accessories Direction change Active ServoCycling Display Active Training Ambience conditions Ankle joint control Application Electromagnetic Emissions Electromagnetic Immunity EMC information End of training Break Error messages Button lock Buttons of the operating panel First time use Fixation at the bed CE sign Forwards/backwards Class of medical products...
  • Page 58 Identification plate Passive Training Immunity Pause Inserting and securing the legs Pedal radius quick adjustment Introduction Power Consumption/Usage Power Requirement Precautions Language option Leg insertion/removal aid Radial adjustement Recommended Separation Distance Recycling Resistance Maintenance Restrictions of liability Measurements Motor power MovementProtector Safety Safety foot shells...
  • Page 59 Technical data Volume Time TrainCare leg guides Training analysis Training start Training suggestions Warm-up phase Training time Warranty Transport rollers Weight Transportation Troubleshooting Unpacking NDEX...
  • Page 60 GB 713.4/W39 c 10.08 Lohner Edith (D Version c) Technical modifications for the purpose of technical improvement are subject to change without notice. Reprint, even in parts, only by approval of the RECK company.
  • Page 66 Instruction manual MOTOmed letto2 RECK-Technik GmbH & Co. KG Reckstraße 1-4, 88422 Betzenweiler, GERMANY Phone +49 (0) 73 74-18 85 +49 (0) 73 74-18 480 contact@motomed.com, www.motomed.com...
