Dahua Technology IPC-HDW5842T-ZE Operation Manual page 448

Table 12-3 Description of HTTP mode parameter
Parameter
Report Period
IP/Domain name
Port
Path
Report type
Test
● FTP upload method
Figure 12-15 HTTP upload method
Description
Select the report period from the drop-down list.
It is 1 hour by default, which indicates that upload the report every 1
hour.
The IP address and port number of the server which the report will
be uploaded to.
The storage path of the server for the report.
Select the report type form the drop-down list. You can select more
than one types at the same time.
The report types in the drop-down list are the same with that
supported AI function. For example: If the camera supports people
counting, heat map, and video metadata, the 3 report types are
displayed in the drop-down list.
Test the network connection between the camera and the server.
