Dahua Technology IPC-HDW5241H-AS-PV Quick Start Manual

Dahua Technology IPC-HDW5241H-AS-PV Quick Start Manual

Active deterrence eyeball
Hide thumbs

Advertisement

Quick Links

Download this manual
Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
Dahua IPC-
HDW5241H-AS-PV
o cerca il tuo prodotto tra le
migliori offerte di Videosorveglianza
Active Deterrence Eyeball Network
Camera
Quick Start Guide
V1.0.0
ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD

Advertisement

loading
Need help?

Need help?

Do you have a question about the IPC-HDW5241H-AS-PV and is the answer not in the manual?

Questions and answers

Related Manuals for Dahua Technology IPC-HDW5241H-AS-PV

Summary of Contents for Dahua Technology IPC-HDW5241H-AS-PV

  • Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Dahua IPC- HDW5241H-AS-PV o cerca il tuo prodotto tra le migliori offerte di Videosorveglianza Active Deterrence Eyeball Network Camera Quick Start Guide V1.0.0 ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD...
  • Page 2 Foreword General This Quick Start Guide (hereinafter referred to as "the Guide") introduces the functions, installation, and operations of the camera. Safety Instructions The following categorized signal words with defined meaning might appear in the Guide. Signal Words Meaning Indicates a medium or low potential hazard which, if not WARNING avoided, could result in slight or moderate injury.
  • Page 3  All the designs and software are subject to change without prior written notice. The product updates might cause some differences between the actual product and the Guide. Please contact the customer service for the latest program and supplementary documentation. ...
  • Page 4 Important Safeguards and Warnings Electrical Safety  All installation and operation should conform to your local electrical safety codes.  The power source shall conform to the Safety Extra Low Voltage (SELV) standard, and supply power with rated voltage which conforms to Limited power Source requirement according to IEC60950-1.
  • Page 5  It is recommended to use the device together with lightning arrester to improve lightning protection effect.  It is recommended to ground the device to enhance reliability.  Do not touch the image sensor directly (CMOS). Dust and dirt could be removed with air blower, or you can wipe the lens gently with soft cloth that moistened with alcohol.
  • Page 6 Regulatory Information The regulatory information herein might vary according to the model you purchased. Some information is only applicable for the country or region where the product is sold. FCC Information Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
  • Page 7 Table of Contents Foreword ..............................I Important Safeguards and Warnings ....................III Regulatory Information ..........................V 1 Introduction ............................1 2 Network Configuration.......................... 4 Initializing Device .......................... 4 Modifying Device IP Address ......................5 Logging in Web Interface ......................6 3 Installation ..............................
  • Page 8 Introduction Components Cable type might vary with different devices, and the actual product shall prevail.  Waterproof all the cable joints with insulating tape and waterproof tape to avoid short circuit  and water damage. For the detailed operation, see the FAQ Manual. Figure 1-1 Structure Components For more information about cable ports, see Table 1-1.
  • Page 9 Table 1-2 Alarm Information Port Port Name Function Outputs alarm signal to alarm device. ALARM_OUT When connecting to alarm device, only the ALARM_OUT port ALARM_OUT_G and ALARM_OUT_GND port with the same number can be used together. Alarm I/O ALARM_IN Receives the switch signal of external alarm source. ALARM_IN_GN Connect different alarm input devices to the same ALARM_IN_GND port.
  • Page 10 Figure 1-3 Mode A Figure 1-4 Mode B Step 3 Log in web interface, and configure alarm input and alarm output in alarm setting. The alarm input in the web interface is corresponding to the alarm input end of the ...
  • Page 11 Network Configuration Device initialization and IP address setting can be finished with the "ConfigTool" or in web interface. For more information, see the Web Operation Manual. Device initialization is available on select models, and it is required at first use or after the ...
  • Page 12 The Device initialization interface is displayed. Step 6 Select the devices that need initialization, and then click Initialize. The password setting interface is displayed. See Figure 2-2. Figure 2-2 Password setting Step 7 Set and confirm the password of the devices, then enter a valid email address, and then click Next.
  • Page 13 Figure 2-3 Modify IP Address Step 3 Select Static mode, and then enter start IP, subnet mask, and gateway. IP addresses of multiple devices will be set to the same if you select the Same IP  checkbox.  If DHCP server is available in the network, devices will automatically obtain IP addresses from DHCP server when you select DHCP.
  • Page 14 Installation Packing List  The tool required for the installation such as electric drill is not provided in the packing.  The operation manual and related tool are contained in the disk or the QR code, and the actual packing shall prevail. Dimension (Unit: mm [in]) Installation 7...
  • Page 15 Installing Device 3.3.1 Installation Type 3.3.2 Installing SD Card (Optional) Pull the power plug off before installing or removing the SD card.  Press and hold the RESET button for 10 s to reset the camera.  3.3.3 Attaching Device Installation 8...
  • Page 16 Make sure the mounting surface is strong enough to hold at least three times of the weight of the device and bracket. Cable going through the mounting surface Installation 9...
  • Page 17 Cable going through the side cable tray 3.3.4 Installing Waterproof Connector (Optional) This part is needed only when there is waterproof connector come with the device and the device is used outdoor. Installation 10...
  • Page 18 3.3.5 Adjusting Lens Angle Installation 11...
  • Page 19 ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. Address: No.1199, Bin'an Road, Binjiang District, Hangzhou, P.R. China Postcode: 310053 Tel: +86-571-87688883 Fax: +86-571-87688815 Email: overseas@dahuatech.com Website: www.dahuasecurity.com...
