1.2 BMS Functions
Protection and Alarm
Charge / Discharge End Cut-off
Charge over Voltage Protection
Charge / Discharge over Current Protection
High / Low Temperature Warning
Over / Under Temperature Protection
Short Circuit Protection
Power Cable Reverse Protection

2 Interface and protection functions

2.1 Battery front panel schematic

Running Light
Alarm Indicator
Start Switch
Power Button
Ground
DIP Switch
CAN/RS485 communication Port
Management and Monitor
Cells Balance
Intelligent Charge
Charge/Discharge Current Limitation
Remaining Power Calculation
Administrator Monitoring
SOC Indicator
Dry Contact
IoT Port Negative
Power Terminal
8
Log Record
Positive
Power Terminal
V5°
V5°α
