Components - Pytes V Series User Manual

2.2 Components

No. Name
1 Ground
2 Power button
3 Soft start switch
4 DIP Switch
Running Light
5
Alarm Indicator
SOC indicator
External CAN
6
communication port
External RS-485
7
communication port
Cascade
8
communication port
9 Negative Power Terminal
10 Positive Power Terminal
11 Dry Contact
LoT port
12
Warning: 6,7,8,9,10,11,12is DVC-A circuit, they shall not be connected to DVC-B/C circuit when installed, or hazard shock
will occur.
Label Functions description
Connection for ground cable
When switched to "ON", the system can be activated by
the "SW" key or external power supply; when switched to
POWER
"OFF", the system is off.
When the on/off button is "ON", press and hold this button
SW
for 1 second to enter the startup or sleep mode.
Set according to inverter brand, see checking list
ADD
Green light. The light flashes when Standby. The light is
constantly on when charging. The light blinks when
RUN
discharging.
Red light. The light flashes when Alarming. The light is
ALM
continuously on when protected.
SOC
Light bar shows current remaining capacity.
RJ45 port, follows CAN protocol, for outputting battery
CAN
information.
RJ45 port, follows RS485 protocol, for outputting battery
RS485
information.
RJ45 ports, connect Port 1 of the previous battery to Port
Prot 1/0 0 of the next one. The Port 0 of the master battery is
vacant.
"-" Negative input and output interface
"+" Positive input and output interface
IN1-/IN1+
COM2/NO2
1 way input and 3 ways output dry contact signal.
COM3/NO3
COM4/NO4
Real-time monitoring of battery status and remote upgrade
9
