Chapter 1 Introduction

Thank you very much for choosing an EIZO color LCD monitor.

1-1. Features

• 19.0 inches
• Supports a resolution of 1 M pixels (1280 dots × 1024 lines)
• VA panel with 178˚ horizontal and vertical viewing angles
• Dual-input system (DVI-D, D-sub)
• The CAL Switch function allows the user to select the display mode optimum to the displayed
image.
Refer to the Installation Manual (on the CD-ROM).
• Selectable DICOM
• The quality control software "RadiCS LE" used to calibrate the monitor and to manage the history is
included.
See "1-3. EIZO LCD Utility Disk" (page 11).
• Power saving function
This product is equipped with power saving function.
Auto EcoView function
The ambient light sensor on the front of the monitor detects the ambient brightness in order to automatically
adjust the screen brightness. Excessively high brightness may increase power consumption and cause
unwanted environmental effects. It may also lead to eye fatigue. The range of automatic adjustment can be
configured to personal preference.
• Stand with wide range of movement
The monitor can be adjusted to a position where it provides you with a comfortable and less tiring
work environment.
(Tilt: 30˚ up/0˚ down, swivel: 35˚ right /35˚ left, adjustable height: 100 mm)
• Long service life LED backlight LCD panel
• Displays HDCP (High-bandwidth Digital Content Protection) protected contents.

1-2. Package Contents

Check that all the following items are included in the packaging box. If any items are missing or damaged,
contact your local EIZO representative.
Note
• Please keep the packaging box and materials for future movement or transport of the monitor.
• Monitor
• Power cord
• Digital signal cable: DVI-D - DVI-D (DD300)
10
Chapter 1 Introduction
®
(page 19) Part 14 complied screen.
• USB cable: UU300
• EIZO LCD Utility Disk (CD-ROM)
• Mounting Screws (M4 x 12mm, 4 pcs)
• Instructions for Use
