Important
Please read this User's Manual carefully to
familiarize yourself with safe and effective

usage procedures.

Please retain this manual for future
reference.
SAFETY SYMBOLS ...................................................2
PRECAUTIONS .....................................................3
1. Introduction .............................................................7
1-1. Features ............................................................ 7
1-2. Buttons and Indicators ...................................... 8
1-3. Utility Disk ......................................................... 9
2. Installation .............................................................10
2-1. Environmental Settings ................................... 10
3. Screen Adjustment and Settings ..........................13
3-1. Basic Operation and Functions ....................... 13
3-2. Color Adjustment ............................................. 15
3-3. Power-save Setup ........................................... 18
3-4. Off Timer ......................................................... 19
3-5. Locking the Settings ........................................ 19
3-6. Power Indicator Setting ................................... 20
3-7. Displaying Lower Resolutions ......................... 20
3-9. Displaying EIZO logo ....................................... 21
4.Troubleshooting .....................................................22
5. Reference .............................................................24
5-1. Attaching an Arm ............................................. 24
5-2. Cleaning .......................................................... 25
5-3. Specifications .................................................. 26
5-4. Glossary .......................................................... 29
FCC Declaration of Conformity ................................ 31

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FlexScan MX300W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eizo FlexScan MX300W

Summary of Contents for Eizo FlexScan MX300W

  • Page 1: Table Of Contents

    3-5. Locking the Settings ... 19 3-6. Power Indicator Setting ... 20 3-7. Displaying Lower Resolutions ... 20 3-8. Setting the Orientation of the Adjustment Menu ... 21 3-9. Displaying EIZO logo ... 21 4.Troubleshooting ...22 5. Reference ...24 5-1. Attaching an Arm ... 24 5-2.

  • Page 2: Safety Symbols

    Indicates a prohibited action. Indicates to ground for safety. Copyright© 2007 EIZO NANAO CORPORATION All rights reserved. No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, or otherwise, without the prior written permission of EIZO NANAO CORPORATION.

  • Page 3: Precautions

    Do not open the cabinet or modify the unit. Opening the cabinet or modifying the unit may result in fire, electric shock, or burn. This symbol indicates Power switch Touch to turn the monitor’s power on or off. Alternating current Alerting electrical hazard Caution...
  • Page 4 WARNING Refer all servicing to qualified service personnel. Do not attempt to service this product yourself as opening or removing covers may result in fire, electric shock, or equipment damage. Keep small objects or liquids away from the unit. Small objects accidentally falling through the ventilation slots into the cabinet or spillage into the cabinet may result in fire, electric shock, or equipment damage.
  • Page 5 WARNING Handle the power cord with care. • Do not place the cord underneath the unit or other heavy objects. • Do not pull on or tie the cord. If the power cord becomes damaged, stop using it. Use of a damaged cord may result in fire or electric shock.

  • Page 6: To Use The Monitor Comfortably

    When the monitor is cold and brought into a room or the room temperature goes up quickly, dew condensation may occur inside and outside the monitor. In that case, do not turn the monitor on and wait until dew condensation disappears, otherwise it may cause some damages to it.

  • Page 7: Introduction

    EIZO LCD Utility Disk). • The utility software "ScreenManager Pro for Medical" (for Windows) to control the monitor from a PC with mouse/keyboard is included (refer to the EIZO LCD Utility Disk). • Portrait/Landscape display available (rotate 90 degrees clockwise) Tips •...

  • Page 8: Buttons And Indicators

    4. Control buttons (Left, Down, Up, Right) 5. Power button 6. Power indicator Indicator status Blue Orange *ScreenManager ® is an EIZO's nickname of the Adjustment menu. Adjustment menu (ScreenManager Operation status The screen is displayed Power saving Power off ®...

  • Page 9: Utility Disk

    1-. Utility Disk An "EIZO LCD Utility Disk" (CD-ROM) is supplied with the monitor. The following table shows the disk contents and the overview of the application software programs. Disk contents and software overview The disk includes a monitor information file, application software programs for adjustment, and User’s Manual.

  • Page 10: Installation

    • These environment described below can be set regardless of whether or not the computer is running. Displaying Two Screens Simultaneously It is possible to display two screens on a single monitor at the same time by using one graphics board with DVI-D2 type output or two graphics boards with DVI-D output on the same computer.
  • Page 11 Connect the [SIGNAL1] signal input connector and the computer using the [DD200DL-BK] signal cable. After connecting the cable connectors, tighten the screws of the connectors to secure the coupling. Connectors on the PC Hold down the button and press the The <Display Setup> menu will appear in the middle of the screen. Press the buttons to select "Single Display" and then press The <Signal Selection> menu will appear. Press the Link/10bit", and press button. Signal cable Signal cable (DD200DL-BK) button. Connectors on the monitor SIGNAL1 buttons to select "Single...

  • Page 12: Making Use Of Usb (Universal Serial Bus)

    • Using the USB Rev. 2.0 compatible PC or peripherals is recommended. • If the monitor is in the power saving mode, or if the monitor is connected to the power outlet with the monitor turned off, all the devices connected to the USB ports (upstream and downstream) work.

  • Page 13: Screen Adjustment And Settings

    . Screen Adjustment and Settings -1. Basic Operation and Functions ScreenManager allows you to adjust screen performance though the main menu and select a CAL Switch mode easily. CAL Switch Menu NOTE • The Adjustment menu and the CAL Switch menu cannot be displayed at the same time. Entering the ScreenManager Press once to display the main menu of the ScreenManager.
  • Page 14 Set the input signal selection of automatic or manual. 3-2. Color Adjustment 3-3. Power-save Setup 3-7. Displaying Lower Resolutions Set the monitor's Off Timer to on or off. Menu Size Change the size of the menu. Menu Position Adjust the menu position.

  • Page 15: Color Adjustment

    -. Color Adjustment Simple Adjustment [CAL Switch mode] This function allows you to select the best display mode for monitor brightness, etc. To select CAL Switch mode Directly pressing allows you to select the best suited mode for screen display from 4 CAL Switch modes;...

  • Page 16: Advanced Adjustments[Adjustment Menu]

    * These settings can be also adjusted on the CAL Switch menu. (See CAL Switch.) NOTE • Allow the LCD monitor to stabilize for at least 30 minutes before making image adjustments. (Allow the monitor to warm up for at least 30 minutes before making adjustments.) •...
  • Page 17 Adjustment Contents Menu Function Descriptions Brightness To set the brightness of the screen Tips • The values shown in the “%” are available only as reference. Temperature To set the color temperature Tips • The values shown in the Kelvin are available only as a reference tool. •...

  • Page 18: Power-Save Setup

    The <PowerManager> menu in the ScreenManager enables to set the power-save setup. NOTE • Do your part to conserve energy, turn off the monitor when you are finished using it. Disconnecting the monitor from the power supply is recommended to save energy completely.

  • Page 19: Off Timer

    -. Off Timer The off timer function causes the monitor to automatically enter a power off state after a predetermined amount of time has lapsed. This function was created to reduce Afterimage characteristics that are particular to LCD monitors when the monitor screen is left on for a long period without use.

  • Page 20: Power Indicator Setting

    -. Power Indicator Setting Light off the power indicator. This function is available for the multiple panels settings. [Procedure] 1. Select <Power Indicator> in the ScreenManager <Others> menu. 2. Select "Disable". -. Displaying Lower Resolutions The lower resolutions are enlarged to full screen automatically. Using the <Screen Size> function in the <Others>...

  • Page 21: Setting The Orientation Of The Adjustment Menu

    PC. Refer to the manual of the graphics board for details. -. Displaying EIZO logo When switching on the power button on the front control panel, the EIZO logo is displayed for a while. If you desire to display or undisplay this logo, use this function.

  • Page 22: Troubleshooting

    4.The screen is too bright or too dark. Possible cause and remedy • Check whether the power cord is connected correctly. If the problem persists, turn off the monitor, and then turn it on again a few minutes later. • Press •...
  • Page 23 6.Green/red/blue/white dots or defective dots remain on the screen. 7.Interference patterns or fingerprints remain on the screen. • Leave the monitor with a white screen or a black screen. 8.Noise appears on the screen. 9.The display image is appeared in lengthwise.

  • Page 24: Reference

    . Reference -1. Attaching an Arm The LCD monitor can be used with an arm by removing the tilt stand and attaching the arm stand to the LCD monitor. NOTE • When attaching an arm or stand, follow the instructions of their user’s manual.

  • Page 25: Cleaning

    -. Cleaning Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime. NOTE • Never use thinner, benzene, alcohol, abrasive cleaners, or other strong solvents, as these may cause damage to the cabinet or LCD panel.

  • Page 26: Specifications

    -. Specifications LCD Panel Panel Protector (MX300W-C) Viewing Angle Dot Pitch Horizontal Scan Frequency Vertical Scan Frequency Resolution Display Colors Display Area Power Supply Power Consumption Input Signal Connector Input Signal (Digital) Signal registration Plug & Play Environment Temperature Conditions Humidity Pressure standard...

  • Page 27: Default Settings

    Signal Selection Optional Graphics board Calibration Kit Network QC Management Software EIZO “RadiNET Pro” Ver.3.0.0 or later Cleaning kit 689 mm (W) x 511 ~ 629.5 mm (H) x 254.7 mm (D) (27.1"(W) x 20.1" ~ 24.8" (H) x 10"(D)) 689 mm (W) x 450 mm (H) x 90 mm (D) (27.1"(W) x 17.7"...

  • Page 28: Pin Assignment

    Pin Assignment •DVI-D Connector 1 2 3 4 5 6 7 8 10 11 12 13 14 15 16 19 20 21 22 23 24 17 18 SIGNAL1 : Applicable to DualLink Pin No. Signal T.M.D.S. Data 2- T.M.D.S. Data 2+ T.M.D.S.

  • Page 29: Glossary

    Gain Adjustment Adjusts each color parameter for red, green and blue. The color of the LCD monitor is displayed through the color filter of the LCD panel. Red, green and blue are the three primary colors. The colors on the monitor are displayed by combining these three colors.
  • Page 30 (Video Electronics Standards Association - Display Power Management Signaling) The acronym VESA stands for "Video Electronics Standards Association", and DPMS stands for "Display Power Management Signaling". DPMS is a communication standard that PCs and graphics boards use to implement power savings on the monitor side.

  • Page 31: Fcc Declaration Of Conformity

    Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord - Shielded Signal Cable (Enclosed) This Class B digital apparatus complies with Canadian ICES-003.
  • Page 32 1st Edition-November, 2007 03V22241A1 (U.M-MX300W)
