RICH-61D0

NUC form factor board

Version 2.1

RICH-61D0 User's Guide

Table of Contents

Need help?

Do you have a question about the RICH-61D0 and is the answer not in the manual?

Questions and answers

Summary of Contents for Portwell RICH-61D0

Page 3: Table Of Contents
5.3.2 Intel® HD Graphics 50X ..................................24 5.3.3 Intel LAN I210IT/I219LM Gigabit Ethernet Controller ..........................25 6 BIOS Setup Items........................................26 6.1 Introduction ........................................26 6.2 BIOS Setup ........................................26 6.2.1 Main ........................................28 Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 4 6.2.5 Save & Exit ..................................... 57 7 Troubleshooting ........................................59 7.1 Hardware Quick Installation ....................................59 7.2 BIOS Setting ........................................60 7.3 FAQ ..........................................61 8 Portwell Software Service ....................................63 9 Industry Specifications ......................................64 Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 5 Portwell provides no warranty with regard to this user’s guide or any other information contained herein and hereby expressly disclaims any implied warranties of merchantability or fitness for any particular purpose with regard to any of the foregoing. PORTWELL assumes no liability for any damages incurred directly or indirectly from any technical or typographical errors or omissions contained herein or for discrepancies between the product and the user’s guide.
Page 6 Warranty”). PORTWELL may in its sole discretion modify its Limited Warranty at any time and from time to time. Beginning on the date of shipment to its direct customer and continuing for the published warranty period, PORTWELL represents that the products are new and warrants that each product failing to function properly under normal use, due to a defect in materials or workmanship or due to non conformance to the agreed upon specifications, will be repaired or exchanged, at PORTWELL’s option and expense.
Page 7: Introduction
14nm process technology, delivering significant power reduction, performance improvements and smaller platform footprint over the ® previous Intel Atom processor E3900 series. The RICH-61D0 can provide the low power consumption for low profile fan-less applications such as Medical, Panel PC, POS, Print Imaging, ATM, Kiosk, Digital Security and Digital Signage. Copyright © Portwell 2018...
Page 8: Specifications
1x M.2 socket (E key) support WiFi, BT Serial Port 1x RS-232 connector - 4x USB 3.0 ports support by stacked connector (Front + Left) - 2x USB 2.0 ports on board with pitch 2.0 header Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 9 - Realtek ALC255 HDA F23 - Audio jack with MIC In orLine-out - 1x HDMI (1.4b) port on board connector, up to 3840x2160@30 MHz Display Interface - 1x DP(1.2) port on rear I/O, up to 4096x2160@60Mhz Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 10: Supported Operating Systems
RICH-61D0 2.1 Supported Operating Systems The RICH-61D0 supports the following operating systems.  Windows 10* (64 bit)  Wind River* 8.0 Linux Distribution(64 bit)  Yocto* Tool-based Embedded Linux Distribution (64 bit)  Android* 6.0(64bit)  VxWorks*7.0 (RTOS) (64 bit) Copyright ©...
Page 12: Power Consumption
3 Test Configuration ® CPU Type Intel Pentium CPU N4200 @ 1.10GHz SBC BIOS Portwell,Inc. BIOS Version: 70908T00 Memory DDR3L-1866 non-ECC up to 8GB VGA Card (DDI1, RTD2168) Resolution up to 1920 x 1200 VGA Driver Intel Driver Version: 21.20.16.4590...
Page 13: Environmental Specifications
CPU +24V Device+12V Device +5V CPU+ Device +24V+12V USB3.0 Loading Test 4.94 V/ 860 mA 2.4 Environmental Specifications Storage Temperature : -40~85°C Operation Temperature : 0~60°C Storage Humidity : 5~90% Operation Humidity: 10~90% Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 15: Hardware Configuration
4 Hardware Configuration 4.1 Connector Function We have made a list of connector function. The following figure shows where the connectors are and what they are called in board file. Figure1. RICH-61D0 System View Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 16: Jumper Settings
Figure2. RICH-61D0 Board View 4.2 Jumper Settings For users to customize RICH-61D0’s features. In the following sections, Users can refer to Figure 1& 2 for the Jumper allocations. Jumper Table The jumper settings are schematically depicted in this manual as follows: Connector Function List: Copyright ©...
Page 17 Global Headset + MIC-IN PWR_BT PWRBTN/RSTBTN/LEDs SATA SATA3 WLAN SLOT HDD_PW DEVSLP BIOS BIOS SPI SOCKET SODIMM1 DDR3L SO-DIMM SOCKET SODIMM2 DDR3L SO-DIMM SOCKET BATTERY CR2032/40mm/1.25 MEDIA Micro SD CPU_FAN CPU_FAN PWR_BUTTON SIO NCT5510Y PWR Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 18 Description SLEEVE_CON HPOL_CON HPOR_CON RING2_CON HPOUT-JD_C PWR_BT: PCB Footprint PIN No. Signal Description PIN No. Signal Description CLK_25M_80H LFRAME# LAD0 PMU_PLTRST_N LAD1 LAD3 LAD2 +V3.3S SERIRQ_3V3 -PANSHW MPD_+ MPD- WDT# SATA_LED_P +V5S +V5A Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 20 RICH-61D0 BIOS: PCB Footprint PIN No. Signal Description PIN No. Signal Description HOLD# BATTERY: PIN No. Signal Description PIN No. Signal Description Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 21 RICH-61D0 Micro SD: PIN No. Signal Description PIN No. Signal Description DAT2 DAT3 DAT0 DAT1 MEDIA: PIN No. Signal Description PIN No. Signal Description FAN_VCC TACH_PWRFAN1 PWM_PWMFAN1 Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 23: System Resources
Intel® Pentium® Processor N4200 (2M Cache, up to 2.50 GHz) 5.2 Main Memory RICH-61D0 provides 1 x 204-pin SO-DIMM sockets which supports DDR3L non-ECC memory. The maximum memory can be up to 8GB. Memory clock and related settings can be detected by BIOS via SPD interface.
Page 24: Chipset Component Driver
5.3.1 Chipset Component Driver The RICH-61D0 build with Intel® Pentium® Processor J/N Series including J3455 / N3350 / N4200 sku. It’s a new chipset that some old operating systems might not be able to recognize. To overcome this compatibility issue, for Windows Operating Systems such as Windows 10, please install its INF before any of other Drivers are installed.
Page 25: Intel Lan I210It/I219Lm Gigabit Ethernet Controller
5.3.3 Intel LAN I210IT/I219LM Gigabit Ethernet Controller - RTL8111H Gigabit Ethernet controller and RJ45 connector on rear I/O Drivers Support Please find RTL8111H LAN driver in Ethernet directory of RICH-61D0 CD/DVD-title. The driver supports Windows 10. Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 26: Bios Setup Items
The BIOS setup program provides a General Help screen. The menu can be easily called up from any menu by pressing <F1>. The Help screen lists all the possible keys to use and the selections for the highlighted item. Press <Esc> to exit the Help Screen. Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 29 The date format is <Day>, <Month> <Date> <Year>. Use [＋] or [－] to configure system Date. System Time The time format is <Hour> <Minute> <Second>. Use [＋] or [－] to configure system Time. Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 32 Description Options When enabled, a VMM can utilize the additional hardware capabilities provided by ★Enabled, Disabled Intel Virtualization Technology Vanderpool Technology. ★Enabled, Disabled VT-d Enable/Disable CPU VT-d. ★Enabled, Disabled EIST Enable/Disable Intel SpeedStep. Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 34 Description Options ★Enable, Disable High Precision Timer Enable or Disable the High Precision Event Timer. ★Enable, Disable HD-Audio Support Enable or Disable HD-Audio Support. ★Disabled, Enabled BIOS Lock Enable or Disable BIOS Lock Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 36 ★Disabled, Enabled Network Stack Enable or disable UEFI Network Stack. Network Stack[Enable] ★Disabled, Enabled IPv4 PXE Support ★Disabled, Enabled IPv6 PXE Support ★Disable Enable Wake on LAN Enable or disable the Wake on LAN. Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 40 If enable, SATA port will be reported as hot Plug capable. Capability SCC SD Card Support ★Enable, Disable Enable/Disable SCC SD Card Support (D27:F0) ★Enable, Disable SCC eMMC Support (D28:F0) Enable/Disable SCC eMMC Support Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 42 Enable/Disable USB port. Once disabled, any USB devices plug into the connector ★Enabled, Disabled USB Port#7 will not be detected by BIOS or OS. Enable/Disable USB port. Once disabled, any USB devices plug into the connector ★Enabled, Disabled USB 3 Port #0 Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 43 ★20 sec, 1 sec, 5 sec, 10 USB transfer time-out The time-out value for Control, Bulk, and Interrupt transfers. sec, ★20 sec, 10 sec, 30sec, Device reset time-out USB mass storage device Start Unit command time-out. 40 sec Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 44 Maximum time the device will take before it properly reports itself to the Host ★Auto, Manual Device Power-up delay Controller. ‘Auto” uses default value: for a Root port it is 100 ms, for a Hub port the delay is taken from Hub descriptor. Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 46 Wake up day you would like the system to wake up Wake up Time(HH: mm: ss) Use [Enter], [TAB] to select field, HH: 0-23, mm: 0-59, ss: 0-59 HH: 0-23, mm: 0-59, ss: 0-59 Copyright © Portwell 2018 RICH-61D0 User's Guide...
Page 53: Security
RICH-61D0 6.2.3 Security This section lets you set security passwords to control access to the system at boot time and/or when entering the BIOS setup program. Copyright © MEDWEL 2018 RICH-61D0 User's Guide...
Page 54 [Setup] check password when enter setup screen. [Power on] check ★Setup, Power on Password Check Mode password on every time system power on. ★No default setting Setup Administrator Password Set Setup Administrator Password Copyright © MEDWEL 2018 RICH-61D0 User's Guide...
Page 56 DOS; This item setting will effect LPSS & XHCI Hand-off item setting. MSDOS ★Enabled, Disabled Full screen Logo Enables or disables Quiet Boot option and Full screen Logo. BOOT Option Priorities ★UEFI: Built-in EFI Shell, Disabled Boot Option #1 Sets the system boot order Copyright © MEDWEL 2018 RICH-61D0 User's Guide...
Page 58 UEFI: Built-in EFI Shell Reset the system after saving the changes. (Boot option filter: UEFI only) Attempts to Launch EFI Shell application (Shell.efi) from one of the available Launch EFI Shell from filesystem device filesystem devices. Copyright © MEDWEL 2018 RICH-61D0 User's Guide...
Page 59: Troubleshooting
7 Troubleshooting This chapter provides a few useful tips to quickly get RICH-61D0 running with success. As basic hardware installation has been addressed in Chapter 2, this chapter will focus on system integration issues, in terms of BIOS setting, and OS diagnostics.
Page 60: Bios Setting
To make sure that you have a successful start with RICH-61D0, it is recommended, when going with the boot-up sequence, to hit “Del” key And enter the BIOS setup menu to tune up a stable BIOS configuration so that you can wake up your system far well.
Page 61: Faq
Question: I forgot my password of system BIOS, what am I supposed to do? Answer: You can switch off your power supply then find the RTC battery on the RICH-61D0 to remove it and wait 10 seconds to clean your password then insert it back to connector and switch on your power supply.
Page 62 RICH-61D0 Question: How to update the BIOS file of RICH-61D0? Answer: 1. Please visit web site of Portwell download center as below hyperlink http://www.portwell.com.tw/support/download_center.php Registering an account in advance is a must. (The E-Mail box should be an existing Company email address that you check regularly.) http://www.portwell.com.tw/member/newmember.php...
Page 63: Portwell Software Service
8 Portwell Software Service Portwell Evaluation Tool (PET) The Portwell Evaluation Tool (PET) is an API which Portwell's customers can access the GPIO, I2C, SMBus, etc under Windows and Linux OS. For more information please contact Portwell. Portwell BIOS web Tool (PBT) The Portwell BIOS web Tool (PBT) is a brand new on-line utility which innovated by Portwell.
Page 64: Industry Specifications
RICH-61D0 9 Industry Specifications The list below provides links to industry specifications that apply to PORTWELL modules. Low Pin Count Interface Specification, Revision 1.0 (LPC) http://www.intel.com/design/chipsets/industry/lpc.htm Universal Serial Bus (USB) Specification, Revision 2.0 http://www.usb.org/home PCI Specification, Revision 2.3 https://www.pcisig.com/specifications Serial ATA Specification, Revision 3.0 http://www.serialata.org/...
