- Page 1 Mini swing with toddler seat SOLE030.100...
- Page 2 1,62 m 1,56 m 0,00 m Benaming TOE SOL 030 100 A Miniswoeng RVS Title Tekening Opmerking Peuterzitje Drawing Comment BOER Datum Afmetingen Dimensions 7-4-2014 Date SPEELTOESTELLEN...
- Page 3 4,63 m 2631 1,75 m Obstakelvrij EN-1176 Obstacle free EN-1176 Opvangzone Impact area Obstakelvrij WAS Obstacle free WAS Benaming TOE SOL 030 100 A Miniswoeng RVS Title Tekening Opmerking Peuterzitje Drawing Comment BOER Datum Obstakelvrije zone Obstacle free zone 7-4-2014 Date SPEELTOESTELLEN...
- Page 4 0,36 m 1,92 m 0,35 m Grondmarkering Ground level marker Benaming TOE SOL 030 100 A Miniswoeng RVS Title Tekening Opmerking Peuterzitje Drawing Comment BOER Datum Bodemplan Groundplan 7-4-2014 Date SPEELTOESTELLEN...
- Page 5 Geleverde modules: Supplied modules: Zie tabel See table Montageinstructie: Assembly instruction: - De hoofdmaten geven de maten van de staanders en vloeren aan - The main dimensions indicate the dimensions of the posts and floors - De detailtekeningen geven specifiek de maten van de verbindingen aan - The detailed dimensions show the specific dimensions of the connections - De modules met buizen zijn op de tekeningen bemaat op bovenkant kopplaat - The modules which contain tubes are dimensioned at the top of the flanges...
- Page 6 SOLE030.100 Mini swing with toddler seat LOGBOOK (Onderstaand logboek kan gebruikt worden om te voldoen aan de eisen, gesteld in artikel 14 van het Warenwetbesluit Attractie- en Speeltoestellen) Type indication Toddler Play Product code SOLE030.100 Name of equipment Miniswoeng met peuterzitje RVS...
-
Page 7: Maintenance
LOGBOOK Inspection and maintenance intervals months Inspection Maintenance between inspections Verify equipment's stability, junctions and missing parts. Add missing parts, secure joints, apply missing fixing Inspect bolts, screws and nuts for absence, jams, corrosion agent and replace corroded parts. and wear. Replace worn parts and/or remove non-functioning Check suspension for wear. - Page 9 4 10 13 15 18 17 Type Progr. Volgnr Bew. Rev. Benaming Opmerking Borgmoer M10 - RVS A2-70 Borgdopmoer M10 - RVS A2-70 M10 x 110 - RVS A2-70 Zeskantbout Bolkopbout ISO 7380 M10 x 16 - RVS A2-70 SLUITRING D-Sluiting 5 mm, RVS A2-70 ZESKANTBOUT...
