Chapter 1
On-board Ultra I/O
- ITE 8671 I/O chip
- One Parallel (SPP/ECP/EPP) and two Serial (16550A compliant) ports
- One floppy disk drive connector supports up to 2.88MB, Japanese 3-Mode,
and 1Mbps transfer rates
- Supports HPSIR and ASKIR function up to 115.2Kbps
On-board Audio Chip
- ESS Solo-1(ES1938S) audio chip
- CD-quality, 16-bit stereo audio controller
- Programmable independent sample rate form 4KHz to 48KHz
for record and playback
- Full-duplex operation for simultaneous recording and playback
- Built-in high quality ESFM music synthesizer
- Integrated Spatializer-3D audio effects processor
Two Channel USB Ports
Now under compatibility testing with different peripherals
Board Dimensions
- Micro-ATX form factor, 244mm x 195mm, 4 Layers
- Six mounting holes
Advanced Management Features
- Innovative SeePU technology for jumperless CPU installation and 75/83/103/
124/133MHz overclocking technology
- Optional LDCM compliant System Monitor Hardware with Chassis intrusion
detection
- Power-on by Mouse movement or clicks, Keyboard password, WOL(Wake-
on-LAN) network card, Modem ring , RTC Alarm
- Software power off control, Over-ride power button, Power failure recovery,
Blinking LED in Suspend, etc.
- Poly-fuse protection for USB and keyboard circuitry
- Flash BIOS write protection against unauthorized access with Trend PC-Cillin
98 and ChipAway Virus to ensure virus-free booting procedure
2
(Optional)
