7700PTX-STP Serial Tally Protocol Translator
TABLE OF CONTENTS
? ...................................................................................................... 19
®
Revision 1.6
7700 MultiFrame Manual
Advertisement
Table of Contents
Related Manuals for evertz 7700
Summary of Contents for evertz 7700
-
Page 1: Table Of Contents
7700 MultiFrame Manual 7700PTX-STP Serial Tally Protocol Translator TABLE OF CONTENTS OVERVIEW ............................. 1 CARD EDGE CONTROLS......................2 2.1. DETERMINING CURRENT IP ADDRESS SETTINGS ............2 2.2. RESTORING FACTORY DEFAULTS..................2 2.3. CARD EDGE LEDS ....................... 2 TECHNICAL SPECIFICATIONS..................... 3 3.1. - Page 2 7700 MultiFrame Manual 7700PTX-STP Serial Tally Protocol Translator Figures Figure 2-1: PTX Card Edge ..........................2 Figure 4-1: Upgrade Jumper ..........................4 Figure 4-2: ‘Connect To’ Window ........................5 Figure 4-3: COM1 Properties ...........................5 Figure 4-4: HyperTerminal Main Menu......................6 Figure 4-5: 7700PTX Back Plate ........................8 Figure 4-6: RS-422 Pins ...........................9...
- Page 3 Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The only warranty offered by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
- Page 4 7700 MultiFrame Manual 7700PTX-STP Serial Tally Protocol Translator This page left intentionally blank Revision 1.6...
-
Page 5: Overview
The 7700PTX Universal Protocol Translator module provides an interface between third-party and Evertz equipment. The 7700PTX communicates with third-party equipment either via one of four serial ports or via a built in Ethernet port. These ports can provide bi-directional protocol support. -
Page 6: Card Edge Controls
7700 MultiFrame Manual 7700PTX-STP Serial Tally Protocol Translator CARD EDGE CONTROLS 2.1. DETERMINING CURRENT IP ADDRESS SETTINGS To read the current IP address during normal operation, press the front switch DOWN. The IP address can be read on the four-character alphanumeric display. -
Page 7: Technical Specifications
7700 MultiFrame Manual 7700PTX-STP Serial Tally Protocol Translator TECHNICAL SPECIFICATIONS 3.1. DATA INPUT SERIAL PORT Number of Ports: 4 RS-232 or 3 RS-422 Connector: Phoenix Terminal Block pins Baud Rate: Up to 1Mbaud 3.2. ELECTRICAL Voltage: +12V DC Power: < 6W... -
Page 8: Configuration
DEBUG/MONITOR PORT CONNECTION The 7700PTX-STP is configured via the debug/monitor port, the header of which is labeled J1. A special Evertz adapter cable allows this port to connect to the COM port of a personal computer. The following steps describe this procedure. - Page 9 7700 MultiFrame Manual 7700PTX-STP Serial Tally Protocol Translator 3. Connect the other end of the upgrade cable to a straight-through serial cable. Connect the serial cable to the serial or COM port of the computer. 4. Initiate HyperTerminal on your computer by selecting: “Start\Programs\Accessories\Communications\HyperTerminal”.
-
Page 10: Main Menu
7700 MultiFrame Manual 7700PTX-STP Serial Tally Protocol Translator 9. Enter the information for the COM1 Properties settings as listed in Figure 4-3. 10. Press the <Enter> key or select OK. The “COM Properties” window closes, leaving the HyperTerminal window open. -
Page 11: Network Configuration
7700 MultiFrame Manual 7700PTX-STP Serial Tally Protocol Translator 4.4. NETWORK CONFIGURATION 1. From the Main Menu select Network Configuration. 2. If DHCP (Dynamic Host Configuration Protocol) is desired, then the Use DHCP field is set to True. Otherwise, the IP address, subnet mask, and gateway (if any) are filled in and the Use DHCP field is set to False. -
Page 12: 4.5.2. Back Plate
7700 MultiFrame Manual 7700PTX-STP Serial Tally Protocol Translator 4.5.2. Back Plate Figure 4-5: 7700PTX Back Plate 7700PTX-STP - 8 Revision 1.6... -
Page 13: Rs-422 Wiring
7700 MultiFrame Manual 7700PTX-STP Serial Tally Protocol Translator 4.5.3. RS-422 Wiring Figure 4-6 shows which pins of the back plate are used for the RS-422 serial connection. Figure 4-6: RS-422 Pins Table 4-2 details how to connect the 7700PTX-STP to the switcher’s serial port for RS-422 operation. -
Page 14: Serial Tally Protocol Settings Setup
7700 MultiFrame Manual 7700PTX-STP Serial Tally Protocol Translator 4.6. SERIAL TALLY PROTOCOL SETTINGS SETUP 4.6.1. Parameters Table 4-3 lists the parameters associated with the Serial Tally Protocol. Parameter Notes The switcher can operate in either standard mode (136x138) or compact mode (128x128). - Page 15 7700 MultiFrame Manual 7700PTX-STP Serial Tally Protocol Translator Primary VGPI Group 1 (PP VGPI Group 2 (ME1 VGPI Group 3 (ME2 VGPI Group 4 (ME3 Source On-Air) On-Air) On-Air) On-Air) 7700PTX-STP - 11 Revision 1.6...
-
Page 16: Under Monitor Display Peer Setup
7700 MultiFrame Manual 7700PTX-STP Serial Tally Protocol Translator Table 4-4 : Primay Source/VGPI Changes to any of these serial tally protocol parameters do not require a reboot of the 7700PTX-STP. 4.7. UNDER MONITOR DISPLAY PEER SETUP Suppose the 7700PTX-STP is to transmit tally information to a PPV whose IP address is 192.168.18.55 and to a PPV whose IP address is 192.168.18.56. - Page 17 7700 MultiFrame Manual 7700PTX-STP Serial Tally Protocol Translator 13. Confirm the settings by selecting Show all setups. 14. Reboot the 7700PTX-STP. After the 7700PTX-STP reboots it will attempt to open TCP sessions with each PPV. Tally information can be transmitted to a PPV after the TCP session has been established.
-
Page 18: Troubleshooting Tips
7700 MultiFrame Manual 7700PTX-STP Serial Tally Protocol Translator TROUBLESHOOTING TIPS 5.1. CHECKING SWITCHER COMMUNICATION The steps below verify the 7700PTX-STP ability to communicate with the switcher. 1. Start a HyperTerminal session via the steps outlined in section 4.2. 2. From the Main Menu select Engineering/Debug. -
Page 19: Checking Umd Peer Communication
7700 MultiFrame Manual 7700PTX-STP Serial Tally Protocol Translator Figure 5-2: Switcher Communication Statistics 5.2. CHECKING UMD PEER COMMUNICATION The steps below verify the 7700PTX-STP ability to communicate with the PPV(s). 1. Start a HyperTerminal session via the steps given in section 4.2. - Page 20 7700 MultiFrame Manual 7700PTX-STP Serial Tally Protocol Translator Figure 5-3: UMD Peer Communication State 7700PTX-STP - 16 Revision 1.6...
-
Page 21: Firmware Upgrade
7700 MultiFrame Manual 7700PTX-STP Serial Tally Protocol Translator FIRMWARE UPGRADE There are two ways to upgrade PTX firmware: 1. Using FTP to perform the upgrade via TCP/IP. (recommended procedure) 2. Using a terminal application such as HyperTerminal to perform the upgrade via a serial connection. - Page 22 7700 MultiFrame Manual 7700PTX-STP Serial Tally Protocol Translator 6. After a few moments, the prompt PPCBOOT> will appear. Enter the command upload. 7. Start the firmware upload on the terminal application (for instance, in HyperTerminal select Transfer/Send File…), use Xmodem as the transfer protocol, and select the firmware file. For example, ptx.bin.
-
Page 23: Vistalink ® Remote Monitoring/Control
ISTA ® VistaLINK is Evertz’ remote monitoring and configuration platform which operates over an Ethernet ® network using Simple Network Management Protocol (SNMP). SNMP is a standard computer network protocol that enables different devices sharing the same network to communicate with each other. - Page 24 7700 MultiFrame Manual 7700PTX-STP Serial Tally Protocol Translator This page left intentionally blank 7700PTX-STP - 20 Revision 1.6...
