evertz 7700 Manual

Fiber data transceiver
Hide thumbs Also See for 7700:
Table of Contents

Advertisement

Quick Links

Download this manual
1.
OVERVIEW.......................................................................................................................................... 1
2.
INSTALLATION................................................................................................................................... 4
2.1. RS-232/422 SERIAL PORT AND LTC CONNECTIONS ............................................................ 4
2.2. OPTICAL CONNECTIONS ......................................................................................................... 6
2.2.1. Single Fiber Versions ...................................................................................................... 6
2.2.2. Dual Fiber Versions......................................................................................................... 6
2.3. CARE AND HANDLING OF OPTICAL FIBER............................................................................ 7
2.3.1. Safety .............................................................................................................................. 7
2.3.2. Handling And Connecting Fibers .................................................................................... 7
3.
SPECIFICATIONS............................................................................................................................... 8
3.1. OPTICAL INPUT/OUTPUT ......................................................................................................... 8
3.2. DATA INPUT/OUTPUT............................................................................................................... 8
3.3. LTC INPUT/OUTPUT.................................................................................................................. 8
3.4. ELECTRICAL ............................................................................................................................. 8
3.5. PHYSICAL .................................................................................................................................. 9
4.
STATUS LEDS .................................................................................................................................... 9
5.
JUMPERS AND USER ADJUSTMENTS .......................................................................................... 10
BY THE GLOBAL FRAME STATUS ........................................................................................ 10
5.2. SELECTING THE LINK MODE................................................................................................. 10
CONNECTED ........................................................................................................................... 11

TABLE OF CONTENTS

Revision 1.6
7700 MultiFrame Manual
7705DT Fiber Data Transceiver

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7700 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for evertz 7700

Summary of Contents for evertz 7700

  • Page 1: Table Of Contents

    7700 MultiFrame Manual 7705DT Fiber Data Transceiver TABLE OF CONTENTS OVERVIEW............................1 INSTALLATION........................... 4 2.1. RS-232/422 SERIAL PORT AND LTC CONNECTIONS ............4 2.2. OPTICAL CONNECTIONS ......................6 2.2.1. Single Fiber Versions ...................... 6 2.2.2. Dual Fiber Versions......................6 2.3. CARE AND HANDLING OF OPTICAL FIBER................7 2.3.1.
  • Page 2 7700 MultiFrame Manual 7705DT Fiber Data Transceiver Figures Figure 1-1: 7705DT Block Diagram – Single Fiber Versions ................2 Figure 1-2: 7705DT Block Diagram – Dual Fiber Versions .................. 3 Figure 2-1: 7705DT and 7705DT-LTC Rear Panels ..................... 4 Figure 5-1: Jumper Locations for Rev A Modules ....................10 Figure 5-2: Receiver Input Pullup Configuration ....................
  • Page 3 Nov 08 Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for the rights of third parties, which may be effected in any way by the use thereof. Any representations in this document concerning performance of Evertz products are for informational use only and are not warranties of future performance, either express or implied.
  • Page 4 7700 MultiFrame Manual 7705DT Fiber Data Transceiver This page left intentionally blank Revision 1.6...

  • Page 5: Overview

    7700 MultiFrame Manual 7705DT Fiber Data Transceiver OVERVIEW The 7705DT series Fiber Data Transceivers provide an economical method of transmitting up to eight RS-232 or four RS-422 data signals over a fiber optic link. Another 7705DT Data Transceiver facilitates conversion back to RS-232 or RS-422 data signals at the destination.

  • Page 6: Figure 1-1: 7705Dt Block Diagram - Single Fiber Versions

    7700 MultiFrame Manual 7705DT Fiber Data Transceiver The chart below shows some typical applications and power budget calculations. Transmit Side Receive Side Fiber Optical/Link Ordering Ordering Fiber Type Description Links Budget Product Info Power Product Info Sensitivity Multi-Mode < 3km...

  • Page 7: Figure 1-2: 7705Dt Block Diagram - Dual Fiber Versions

    7700 MultiFrame Manual 7705DT Fiber Data Transceiver Optical Optical Output Transmitter RS-232/422 Data Optical & LTC Input Optical Receiver DIP Switches Data Control Error Figure 1-2: 7705DT Block Diagram – Dual Fiber Versions 7705DT - 3 Revision 1.6...

  • Page 8: Installation

    7700 MultiFrame Manual 7705DT Fiber Data Transceiver INSTALLATION The 7705DT-FC, 7705DT-FW and 7705DT-LTC versions come with a companion rear plate that has a 25 pin female D connector and one SC/PC (shown), ST/PC or FC/PC optical connector. The 7705DT-F2 and 7705-LTC-F2 versions come with a companion rear plate that has a 25 pin female D connector and two SC/PC (shown), ST/PC or FC/PC optical connectors.

  • Page 9: Table 2-1: Db25 Pin Connections

    7700 MultiFrame Manual 7705DT Fiber Data Transceiver On all versions, the SEL 1, 2, 3, and 4 jumpers located at the rear of the module determine whether each section will be operated as a balanced RS-422 Receive and Transmit channel, or two RS-232 Receive and Transmit channels (See section 5.3 for location of the SEL jumpers).

  • Page 10: Optical Connections

    7700 MultiFrame Manual 7705DT Fiber Data Transceiver 2.2. OPTICAL CONNECTIONS In order to establish a valid link between a pair of 7705DT modules, one module must be configured as ‘Mode A’, and the other as ‘Mode B’. Selection of the correct mode is achieved by setting jumper J22, at the rear of the board.

  • Page 11: Care And Handling Of Optical Fiber

    3 cm to avoid fiber-bending loss that will decrease the maximum attainable distance of the fiber cable. The Evertz fiber optic modules come with cable lockout devices, to prevent the user from damaging the fiber by installing a module into a slot in the frame that does not have a suitable I/O module.

  • Page 12: Specifications

    7700 MultiFrame Manual 7705DT Fiber Data Transceiver SPECIFICATIONS 3.1. OPTICAL INPUT/OUTPUT Number: 1 (Standard, FC and FW versions) 2 (F2 versions) Connector: Female SC/PC, ST/PC or FC/PC Input Wavelengths: 1310nm to 1610nm Maximum Input Power: 0 dBm Input Optical Sensitivity:...

  • Page 13: Physical

    7700 MultiFrame Manual 7705DT Fiber Data Transceiver 3.5. PHYSICAL 7700 or 7701 frame mounting: Number of slots: 1 STATUS LEDS LOCAL FAULT (LD2): This Red LED will be On when there is insufficient optical input power, an optical transmitter failure or when there is a fault in the module power supply. When the FRAME STATUS jumper is set to the ON position the FRAME STATUS bus will also be asserted.

  • Page 14: Jumpers And User Adjustments

    7700 MultiFrame Manual 7705DT Fiber Data Transceiver JUMPERS AND USER ADJUSTMENTS FRAME STATUS LOCAL FAULT MODULE OK OPTICAL FAULT NO LINK SEL 3 SEL 4 SEL 1 SEL 2 EVERTZ (A) 7705DT SFF POWER Figure 5-1: Jumper Locations for Rev A Modules 5.1.

  • Page 15: Selecting The Default Behaviour Of The Inputs When There Is No Signal Connected

    7700 MultiFrame Manual 7705DT Fiber Data Transceiver SEL 1: To set section 1 inputs and outputs to operate in the RS-232 standard, install the jumper in the RS-232 position. In this mode, section 1 of the connector will be configured as two Rx/Tx ports (Port 1A and Port 1B) as shown in Table 2-1.
  • Page 16 7700 MultiFrame Manual 7705DT Fiber Data Transceiver This page left intentionally blank 7705DT - 12 Revision 1.6...
