evertz 7700 Manual

Contribution tally protocol translator
Hide thumbs Also See for 7700:
Table of Contents

Advertisement

Quick Links

Download this manual
1.
OVERVIEW ..................................................................................................................................... 1
2.
CARD EDGE CONTROLS.............................................................................................................. 4
2.1. DETERMINING CURRENT IP ADDRESS SETTINGS .......................................................... 4
2.2. RESTORING FACTORY DEFAULTS.................................................................................... 4
2.3. CARD EDGE LEDS ............................................................................................................... 4
3.
TECHNICAL SPECIFICATIONS..................................................................................................... 5
3.1. DATA INPUT SERIAL PORT................................................................................................. 5
3.2. ELECTRICAL......................................................................................................................... 5
3.3. PHYSICAL ............................................................................................................................. 5
4.
CONFIGURATION .......................................................................................................................... 6
4.1. CONFIGURATION STEPS .................................................................................................... 6
4.2. DEBUG/MONITOR PORT CONNECTION............................................................................. 6
4.3. MAIN MENU........................................................................................................................... 8
4.4. NETWORK CONFIGURATION.............................................................................................. 9
4.5. SERIAL PORT SETUP .......................................................................................................... 9
4.5.1. Parameters ................................................................................................................. 9
4.5.2. Rear Plate ................................................................................................................. 10
4.5.3. RS-232 Wiring........................................................................................................... 11
4.5.4. RS-422 Wiring........................................................................................................... 12
4.6. CTP PROTOCOL SETUP .................................................................................................... 13
4.6.1. VGPI Image Video Display Id ................................................................................... 14
4.6.2. VGPI Refresh Count ................................................................................................. 14
4.6.3. Program Output Number........................................................................................... 15
4.6.4. Program VGPI Offset ................................................................................................ 15
4.6.5. Tx Program UMD ...................................................................................................... 16
4.6.6. Program UMD Display Id .......................................................................................... 16
4.6.7. Preview Output Number............................................................................................ 16
4.6.8. Preview VGPI Offset ................................................................................................. 17
4.6.9. Tx Preview UMD ....................................................................................................... 17
4.6.10. Preview UMD Display Id ........................................................................................... 18
7700PTX-CTP Contribution Tally Protocol Translator

TABLE OF CONTENTS

Revision 1.6
7700 MultiFrame Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7700 and is the answer not in the manual?

Questions and answers
