Page 1: Table Of Contents
7700 MultiFrame Manual 7705AT Fiber Audio Transmitter TABLE OF CONTENTS OVERVIEW............................1 INSTALLATION........................... 4 2.1. AES AUDIO AND RS-232/422 SERIAL PORT CONNECTIONS..........4 2.2. OPTICAL CONNECTIONS......................6 2.3. CARE AND HANDLING OF OPTICAL FIBER................6 2.3.1. Safety ..........................6 SPECIFICATIONS..........................7 3.1. - Page 2 7700 MultiFrame Manual 7705AT Fiber Audio Transmitter Figures Figure 1-1: 7705AT Block Diagram........................2 Figure 1-2: 7705AT-2 Block Diagram ........................3 Figure 1-3: 7705AT-8 Block Diagram ........................3 Figure 2-1: 7705AT Rear Panels .......................... 4 Figure 5-1: Jumper Locations ..........................10 Figure 5-2: Receiver Input Pullup Configuration ....................
- Page 3 Nov 08 Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for the rights of third parties, which may be effected in any way by the use thereof. Any representations in this document concerning performance of Evertz products are for informational use only and are not warranties of future performance, either express or implied.
- Page 4 7700 MultiFrame Manual 7705AT Fiber Audio Transmitter WARNING Never look directly into an optical fiber. Non-reversible damage to the eye can occur in a matter of milliseconds. Revision 1.6...
-
Page 5: Overview
7700 MultiFrame Manual 7705AT Fiber Audio Transmitter OVERVIEW The 7705AT series AES Audio Transmitter Multiplexors and 7705AR series AES Audio Receiver Demultiplexors provide an economical method of transmitting up to six AES audio signals (twelve mono), one RS-232/422 control signal, and linear Time Code (LTC) or eight AES audio signals (sixteen mono) using a single wavelength on a fiber optic cable, with minimum latency. -
Page 6: Figure 1-1: 7705At Block Diagram
7700 MultiFrame Manual 7705AT Fiber Audio Transmitter Features: • Six channel versions have six single-ended AES audio inputs with one balanced linear time code input and uni-directional RS-232/422 data input • Sixteen channel version has eight single-ended AES audio inputs •... -
Page 7: Figure 1-2: 7705At-2 Block Diagram
7700 MultiFrame Manual 7705AT Fiber Audio Transmitter DB25 Optical 1 RS-232/422 Transmitter Input Optical LTC Input Output Monitoring Control Unit Head Phone Jack Pushbutton Transmitter 6 AES Inputs Fault Figure 1-2: 7705AT-2 Block Diagram Optical Transmitter 8 AES Optical Inputs... -
Page 8: Installation
7700 MultiFrame Manual 7705AT Fiber Audio Transmitter INSTALLATION The one slot 7705AT and 7705AT-8 versions come with a companion rear plate that has a 25 pin female D connector and one SC/PC (shown), ST/PC or FC/PC optical connector. The two slot 7705AT-2 version also has 6 BNC connectors for the audio. -
Page 9: Table 2-1: Db25 Pin Connections
7700 MultiFrame Manual 7705AT Fiber Audio Transmitter AES/DATA/LTC IN: On the 7705AT there is a 25 Pin D connector for connection of 6 unbalanced AES channels, 1 RS-232/RS-422 data channel, and one differential time code channel. The serial port portion of the connector consists of 2 in pins and 1 ground pin. The SEL 4 jumper located at the rear of the module determines whether the port will be operated as a balanced RS-422 Receive channel, or one RS-232 Receive channel (See section 5.2 for... -
Page 10: Optical Connections
The transmission characteristics of the fiber are dependent on the shape of the optical core and therefore care must be taken to prevent fiber damage due to heavy objects or abrupt fiber bending. Evertz recommends that you maintain a minimum bending radius of 5 cm to avoid fiber-bending loss that will decrease the maximum attainable distance of the fiber cable. -
Page 11: Specifications
7700 MultiFrame Manual 7705AT Fiber Audio Transmitter SPECIFICATIONS 3.1. AES AUDIO INPUTS Number of Inputs: 7705AT: 7705AT-2: 7705AT-8: Standard: SMPTE 276M, single ended synchronous or asynchronous AES (synchronous AES required when sample rate converter is disabled.) Signal Level: 1V p-p ±0.1V... -
Page 12: Audio Monitoring Output
3.7. ELECTRICAL Voltage: + 12VDC Power: 6 Watts. EMI/RFI: Complies with FCC regulations for class A devices. Complies with EU EMC directive. 3.8. PHYSICAL 7700 or 7701 frame mounting: Number of slots: 7705AT: 7705AT-2: 7705AT-8: 7705AT - 8 Revision 1.6... -
Page 13: Status Leds
7700 MultiFrame Manual 7705AT Fiber Audio Transmitter STATUS LEDS 4.1. MODULE STATUS LEDS LOCAL FAULT (LD1): This Red LED will be On when there is an optical transmitter failure or when there is a fault in the module power supply. When the FRAME STATUS jumper is set to the ON position the FRAME STATUS bus will also be asserted. -
Page 14: Jumpers And User Adjustments
7700 MultiFrame Manual 7705AT Fiber Audio Transmitter JUMPERS AND USER ADJUSTMENTS FRAME STATUS J21 NO LOCAL FAULT MODULE OK OPTICAL FAULT LINK LEVEL SEL 4 CHANNEL SELECT MONITOR EVERTZ (A) 7705DT SFF POWER Figure 5-1: Jumper Locations 5.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED... -
Page 15: Selecting The Default Behaviour Of The Data Inputs When There Is No Signal Connected
7700 MultiFrame Manual 7705AT Fiber Audio Transmitter 5.3. SELECTING THE DEFAULT BEHAVIOUR OF THE DATA INPUTS WHEN THERE IS NO SIGNAL CONNECTED Jumper J21 located at the rear of the board controls the behaviour of the RS-422 inputs when there is no signal connected. - Page 16 7700 MultiFrame Manual 7705AT Fiber Audio Transmitter This page left intentionally blank 7705AT - 12 Revision 1.6...
