1.
OVERVIEW.......................................................................................................................................... 1
2.
INSTALLATION................................................................................................................................... 3
2.1. ETHERNET CONNECTIONS ..................................................................................................... 3
2.2. OPTICAL CONNECTIONS......................................................................................................... 5
2.2.1. Single Fiber version (7705ET)......................................................................................... 5
2.2.2. Dual Fiber Version (7705ET-F2) ..................................................................................... 5
2.3. CARE AND HANDLING OF OPTICAL FIBER........................................................................... 5
2.3.1. Safety .............................................................................................................................. 5
2.3.2. Handling and Connecting Fibers ..................................................................................... 6
3.
SPECIFICATIONS............................................................................................................................... 7
3.1. ETHERNET INPUT/OUTPUT ..................................................................................................... 7
3.2. OPTICAL INPUT/OUTPUT......................................................................................................... 7
3.3. ELECTRICAL ............................................................................................................................. 7
3.4. PHYSICAL .................................................................................................................................. 7
4.
STATUS INDICATORS ....................................................................................................................... 8
4.1. MODULE HEALTH LEDS .......................................................................................................... 8
4.2. FIBER LINK LED........................................................................................................................ 8
4.3. CARD EDGE ETHERNET LEDS................................................................................................ 8
4.4. REAR PANEL ETHERNET LEDS.............................................................................................. 9
5.
JUMPERS AND USER ADJUSTMENTS .......................................................................................... 10
BY THE GLOBAL FRAME STATUS........................................................................................ 10
5.2. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES ............................................. 11
5.3. SELECTING THE CARD ADDRESS (Single Fiber version only) ......................................... 11
TABLE OF CONTENTS
Revision 1.4
7700 MultiFrame Manual
7705ET Ethernet Fiber Transceiver
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for evertz 7700
Summary of Contents for evertz 7700
-
Page 1: Table Of Contents
7700 MultiFrame Manual 7705ET Ethernet Fiber Transceiver TABLE OF CONTENTS OVERVIEW............................1 INSTALLATION........................... 3 2.1. ETHERNET CONNECTIONS ..................... 3 2.2. OPTICAL CONNECTIONS......................5 2.2.1. Single Fiber version (7705ET)..................5 2.2.2. Dual Fiber Version (7705ET-F2) ..................5 2.3. CARE AND HANDLING OF OPTICAL FIBER................5 2.3.1. - Page 2 7700 MultiFrame Manual 7705ET Ethernet Fiber Transceiver Figures Figure 1-1: 7705ET Block Diagram........................2 Figure 1-2: 7705ET-F2 Block Diagram ......................... 2 Figure 2-1: 7705ET Rear panels........................... 3 Figure 5-1: LED and Jumper Locations ......................10 Tables Table 2-1: Ethernet Connector Pin Definitions and Cable Wiring................. 4...
- Page 3 Nov 08 Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for the rights of third parties, which may be effected in any way by the use thereof. Any representations in this document concerning performance of Evertz products are for informational use only and are not warranties of future performance, either express or implied.
- Page 4 7700 MultiFrame Manual 7705ET Ethernet Fiber Transceiver This page left intentionally blank Revision 1.4...
-
Page 5: Overview
7700 MultiFrame Manual 7705ET Ethernet Fiber Transceiver OVERVIEW The 7705ET Ethernet Fiber Transceiver provides an economical method of transmitting two 10BaseT Ethernet channels or one 100Base-TX Ethernet channel over optical fiber. The converter is IEEE 802.3 10BASE-T and IEEE 802.3u 100BASE-TX compliant, mediates between a 10/100BASE-TX segment and supports both full duplex and half-duplex operation. -
Page 6: Figure 1-1: 7705Et Block Diagram
7700 MultiFrame Manual 7705ET Ethernet Fiber Transceiver 10/100 TX LN/ACT 10/100 Mode RJ45 Input Optical In/Out Ethernet Fiber XCVR Combiner Switch 10/100 TX LN/ACT 10/100 Mode RJ45 Input Fiber Link Indication Figure 1-1: 7705ET Block Diagram 10/100 TX LN/ACT 10/100... -
Page 7: Installation
7700 MultiFrame Manual 7705ET Ethernet Fiber Transceiver INSTALLATION The 7705ET comes with a companion rear plate that has two RJ-45 input connectors and one SC/PC (shown), ST/PC or FC/PC optical connector. The 7705ET-F2 version comes with a companion rear plate that has two RJ-45 input connectors and two SC/PC, ST/PC or FC/PC optical connectors. -
Page 8: Table 2-1: Ethernet Connector Pin Definitions And Cable Wiring
7705ET Ethernet Fiber Transceiver When connecting the 7705ET to a hub or switch a “straight through” cable must be used. When connecting the 7705ET to the Evertz 7700FC VistaLINK Frame Controller, another 7705ET, or the ® network interface card of a computer, a “crossover” cable must be used. -
Page 9: Optical Connections
7700 MultiFrame Manual 7705ET Ethernet Fiber Transceiver 2.2. OPTICAL CONNECTIONS The 7705ET modules are designed to work with single-mode or multi-mode optical fiber depending on the version (FC, F2) ordered. 2.2.1. Single Fiber version (7705ET) FIBER I/O: There is one SC/PC (shown), ST/PC or FC/PC female connector with the optical input/output from the 7705ET. -
Page 10: 2.3.2. Handling And Connecting Fibers
3 cm to avoid fiber-bending loss that will decrease the maximum attainable distance of the fiber cable. The Evertz fiber optic modules come with cable lockout devices, to prevent the user from damaging the fiber by installing a module into a slot in the frame that does not have a suitable I/O module. -
Page 11: Specifications
7705ET will depend on the device you are connecting to. When devices connect to each other on a network, they connect through a transmit and a receive line. When connecting the 7705ET to a hub or switch a “straight through” cable must be used. When connecting the 7705ET to the Evertz 7700FC VistaLINK Frame Controller, another 7705ET, or the network interface card of a computer, a ®... -
Page 12: Status Indicators
7700 MultiFrame Manual 7705ET Ethernet Fiber Transceiver STATUS INDICATORS The 7705ET series modules have 9 LED Status indicators on the front card edge to show operational status of the card at a glance. Figure 5-1 shows the location of the LEDs. -
Page 13: Rear Panel Ethernet Leds
7700 MultiFrame Manual 7705ET Ethernet Fiber Transceiver 10/100 This Green LED is On when a 100Base-TX link is established. The LED is Off when a 10Base-T link is established (the LINK LED is On) or if there is no link established (the LINK LED is Off). -
Page 14: Jumpers And User Adjustments
7700 MultiFrame Manual 7705ET Ethernet Fiber Transceiver JUMPERS AND USER ADJUSTMENTS MODULE OK LOCAL FAULT SERIAL FIBER LINK LN / ACT 10 / 100 HALF / FULL ETHERNET 1 ETHERNET 2 SFF POWER Note: Standard versions have one fiber connector, -F2 versions have two fiber connectors Figure 5-1: LED and Jumper Locations 5.1. -
Page 15: Configuring The Module For Firmware Upgrades
7700 MultiFrame Manual 7705ET Ethernet Fiber Transceiver 5.2. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES UPGRADE: The UPGRADE jumper J4 is used when firmware upgrades are being done to the module. For normal operation it should be installed in the RUN position. See the Upgrading Firmware section of this manual for more information. - Page 16 7700 MultiFrame Manual 7705ET Ethernet Fiber Transceiver This page left intentionally blank 7705ET - 12 Revision 1.4...
