- Page 1 Black 30” Cable Management Desk Organizer SKU: DESK-SKIRT-30 Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/desk-skirt-30...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury.
- Page 3 Package Contents A (x1) B (x2) C (x2) Panel Side Bar Mounting Clip D (x4) E (x6) Upper/Lower Joining Tube Included Hardware S-A (x2) ST4.8x19 Screw Tools Needed: Phillips Pencil Drill Screwdriver...
- Page 4 ASSEMBLY STEPS STEP 1 Assemble the steel bar frame using the Side Bars (B), Upper/Lower Bars (D) and Joining Tubes (E). Lighty tap each joint against a hard surface to ensure all bars and joiners are full pressed in. NOTE: Ensure all bars and joiners are fully pressed in for a secure fit. STEP 2 Open the flap and straps of the Panel (A) and insert the frame, making sure the frame is fully inserted and the material is tightly stretched around it.
- Page 5 STEP 3 Fasten the straps on Panel (A) to around the assembled frame to secure. STEP 4 Place the Mounting Clips (C) in the center of each exposed portion of the steel bars. NOTE: Make sure the wire management flap on the panel (A) is facing the inside of the desktop.
- Page 6 STEP 5 Center the assembled panel under the desktop. STEP 6 Mark the locations of the Mounting Clips (C) using a pencil. Drill pilot holes using a 1/8” (3mm) bit and mount the assembled panel to the underside of the desk using the ST4.8x19 Screws (S-A) as shown.
- Page 7 STEP 7 Route and organize the cables and secure them using the flap on the panel (A).
- Page 8 LAST UPDATED: 01/08/24 REV2 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
