- Page 1 71” Cable Management Desk Organizer SKU: DESK-SKIRT-71 Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/desk-skirt-60...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 Package Contents B (x2) C (x4) A (x1) Side Bar T Joiner Panel D (x3) E (x6) F (x2) Mounting Clip Upper/Lower Middle G (x4) Joiner Included Hardware W-A (x1) 3/4” Screw Tools Needed: Phillips Power Pencil Screwdriver Drill...
- Page 4 ASSEMBLY STEPS STEP 1 Connect the centers of the T Joiners (C) to the ends of the Middle Bars (F). Connect the Upper/Lower Bars (E) to the sides of the T Joiners (C), then connect the Joiners (G) and Side Bars (B) to the sides to complete the frame assembly. Lighty tap each joint against a hard surface to ensure all bars and joiners are full pressed in.
- Page 5 STEP 2 Open the flap and straps of the Panel (A) and insert the frame, making sure the frame is fully inserted and the material is tightly stretched around it. Note: Confirm that frame pieces are fully secure into each other before sliding into panel.
- Page 6 STEP 3 Place the plastic Mounting Clips (D) in the center of each exposed portion of the steel bars. NOTE: Make sure the wire management flap on the Panel (A) is facing the inside of the desktop. S-A (x1) STEP 4 Center the assembled panel under the desktop and use a pencil to mark the locations of Plastic Mounting Clips (D).
- Page 7 STEP 5 Drill pilot holes using a 1/8” (3mm) bit. Mount the assembled panel to the underside of the desk using 3/4” Screws (W-A) as shown into Plastic Mounting Clips (D). Route and organize the cables and secure them using the flap on Panel (A).
- Page 8 LAST UPDATED: 01/08/24 REV1.1 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
