6.
second person, orient the Console (5), the
Console Cover (7), and the Console Bracket (4)
as shown. Route the wires (A) on the Console
through the Console Cover and the Console
Bracket as shown;
Attach the Console (5) and the
Console Cover (7) to the Console Bracket (4)
with four M4 x 22mm Screws (107);
7. Attach the Tablet Holder (6) to the Console (5)
with four #8 x 16mm Screws (111);
With the help of a
6
5
A
5
4
7
5
7
4
7
107
6
111
