Linear Technology LTC2107 Demo Manual

Description
Demonstration circuit 2183A supports the
high speed and high dynamic range ADC. It was specially
designed for applications that require a single-ended AC-
coupled input. DC2183 supports the LTC2107 using the
DDR LVDS output mode.
The LTC2107 characteristics are listed in Table 1. De-
pending on the version, the circuitry on the analog inputs
is optimized for analog input frequencies from 5MHz to
70MHz or 70MHz to 180MHz.
Table 1: DC2183 Variants
DC2183 VARIANTS
2183A-A
2183A-B
performance summary
PARAMETER
Supply Voltage – DC2183
Analog Input Range
Logic Input Voltages
Logic Output Voltages (Differential)
Sampling Frequency (Encode Clock Frequency)
Convert Clock Level (Single Ended)
Convert Clock Level (Differential)
