Instructions for use
INTRAmatic contra-angle 80 ES - 1.004.4375
D D istributed by:
KaVo Dental GmbH
Bismarckring 39
D-88400 Biberach
Tel. +49 7351 56-0
Fax +49 7351 56-1488
Contents
C C ontents
1 User instructions ............................................................................................................................................... 5
2 Safety ............................................................................................................................................................... 7
2.1
Description of safety instructions ............................................................................................................ 7
2.1.1
Description of safety instructions: Warning symbol ................................................................... 7
2.1.2
Description of safety instructions: Structure .............................................................................. 7
2.1.3
Description of safety instructions: Description of danger levels ................................................ 8
2.2
Safety instructions .................................................................................................................................. 9
3 Product description ......................................................................................................................................... 15
3.1
Purpose - Proper use .......................................................................................................................... 16
3.2
Technical data ...................................................................................................................................... 18
3.3
Transportation and storage conditions ................................................................................................. 19
Contents
4 4 First use .......................................................................................................................................................... 21
4.1
Check the amount of water .................................................................................................................. 22
5 Operation ........................................................................................................................................................ 24
5.1
Attaching the medical device ................................................................................................................ 25
5.2
Removing the medical device .............................................................................................................. 26
5.3
Insert the milling cutters or diamond grinders ...................................................................................... 26
5.4
Removing the milling tool or diamond grinder ...................................................................................... 29
6 Troubleshooting .............................................................................................................................................. 31
6.1
Check for malfunctions ......................................................................................................................... 31
6.2
Troubleshooting .................................................................................................................................... 32
6.2.1
Troubleshooting: Exchanging the O-rings on the motor coupling ........................................... 32
6.2.2
Troubleshooting: Cleaning the spray nozzle ........................................................................... 34
7 Setup methods according to DIN EN ISO 17664 ........................................................................................... 35
7.1
Preparation at the site of use ............................................................................................................... 35
Manufacturer:
Kaltenbach & Voigt GmbH
Bismarckring 39
D-88400 Biberach
www.kavo.com
1
2
Advertisement
Table of Contents
Related Manuals for KaVo INTRAmatic contra-angle 80 ES
Summary of Contents for KaVo INTRAmatic contra-angle 80 ES
-
Page 1: Table Of Contents
Instructions for use INTRAmatic contra-angle 80 ES - 1.004.4375 D D istributed by: Manufacturer: KaVo Dental GmbH Kaltenbach & Voigt GmbH Bismarckring 39 Bismarckring 39 D-88400 Biberach D-88400 Biberach Tel. +49 7351 56-0 www.kavo.com Fax +49 7351 56-1488 Contents C C ontents 1 User instructions ............................... - Page 2 Drying ..............................45 Care products and systems - Servicing ....................46 7.5.1 Care products and systems - Servicing: Care with KaVo Spray ..........47 7.5.2 Care products and systems - Servicing: Servicing with KaVo QUATTROcare ....... 49 Packaging ............................. 51 Contents Sterilisation ............................
-
Page 3: Safety
Safety 2 2 S S afety 2.1.1 D D escription of safety instructions: Warning symbol Warning symbol 2.1.2 D D escription of safety instructions: Structure DANGER The introduction describes the type and source of the hazard. This section describes the potential consequences of non-observance. ▶... - Page 4 To ensure proper function, the medical device must be set up according to the reprocessing methods described in the KaVo Instructions for Use, and the care products and care systems described therein must be used. KaVo recommends specifying a service interval at the dental office for a licensed shop to clean, service and check the functioning of the medical device.
-
Page 5: Product Description
Product description 3 3 P P roduct description INTRAmatic contra-angle handpiece 80 ES,M M at. no. 1.004.4375 Product description 3 3 .1 P P urpose – Proper use Purpose: This medical device is ▪ Only intended for dental treatment. Any other type of use or alteration to the product is impermissible and can be hazardous. -
Page 6: Transportation And Storage Conditions
Product description 3 3 .3 T T ransportation and storage conditions CAUTION It is hazardous to start up the medical device after it has been stored strongly refrigerated. This can cause the medical device to malfunction. ▶ Prior to start-up, very cold products must be heated to a temperature of 20°C to 25°C (68°F to 77°F). -
Page 7: Operation
First use CAUTION Hazard from insufficient spray water. Insufficient spray water can cause the medical device to overheat and damage the tooth. ▶ Check the spray water channels and clean the spray nozzles with the nozzle needle M M at. no. 0.410.0931 if necessary. ▶... -
Page 8: Removing The Milling Tool Or Diamond Grinder
Operation WARNING Use of unauthorised tools. Injury to the patient or damage to the medical device. ▶ Observe manufacturer instructions and use the tool properly. ▶ Only use tools that do not deviate from the specified data. CAUTION Injury from using worn tools. Tools can fall out during treatment and harm the patient. -
Page 9: Troubleshooting
▶ Do not use Vaseline or other grease or oil. Troubleshooting Note The O-rings on the motor coupling may only be lubricated with a cotton ball wetted with KaVo spray. ▶ Press the O-ring between your fingers to form a loop. ▶... -
Page 10: Setup Methods According To Din En Iso 17664
Can only be done with KaVo CLEANspray or KaVo DRYspray. ▶ Cover the medical device with the KaVo CLEANpac bag, and place it on the corresponding care adapter. Press the spray button three times for 2 seconds each time. Remove the medical device from the spray... -
Page 11: Cleaning: Automated Internal Cleaning
Setup methods according to DIN EN ISO 17664 ▶ Afterwards, rinse for 3-5 seconds with KaVo DRYspray. S S ee also: KaVo CLEANspray / KaVo DRYspray Instructions for Use Note KaVo CLEANspray and KaVo DRYspray for manual interior cleaning are only available in the following countries: Germany, Austria, Switzerland, Italy, Spain, Portugal, France, Luxem‐... -
Page 12: Disinfection: Manual Disinfection - Internal
The efficacy of manual internal disinfection must be demonstrated by the manufacturer of the disinfection agent. With KaVo products, use only dis‐ infection agents that have been released by KaVo with respect to the com‐ patibility of materials (e.g. WL-cid / made by ALPRO). -
Page 13: Care Products And Systems - Servicing: Care With Kavo Spray
Carry out the servicing according to the instructions in the section, "Care with KaVo Spray". Setup methods according to DIN EN ISO 17664 7 7 .5.2 C C are products and systems - Servicing: Servicing with KaVo QUATTROcare Cleaning and care unit with expansion pressure for effective cleaning and care. - Page 14 ISO 17665-1 (e.g. KaVo STERIclave B 2200 / 2200 P) CAUTION Premature wear and malfunctions from improper servicing and care. Reduced product life. ▶ Before each sterilisation cycle, service the medical device with KaVo care products. Setup methods according to DIN EN ISO 17664 CAUTION Contact corrosion due to moisture.
-
Page 15: Storage
24 months from data of invoice, subject to the following conditions: In case of justified complaints, KaVo will honour its warranty with a free replacement or repair. Other claims of any nature whatsoever, in particular with respect to compensation, are excluded. -
Page 16: Terms And Conditions Of Warranty
Terms and conditions of warranty cordance with KaVo's instructions for use or other manufacturer's instruc‐ tions. No liability is assumed when defects or their consequences are derived from manipulations or changes to the product by the customer or a third party.
