Sunricher Universal Series Instructions

Universal series RF Receiver
Important: Read All Instructions Prior to Installation

Function introduction

DC Power input
V+
V-
RF Controller
Learning
Switch
GND
Push switch input

Learning Key:

Paring with RF remote

Product Data

Output
Input Output
Current
Voltage Power
4x8A@12-36VDC 4x(96-288)W@12-36VDC
12-48VDC
4x4A@48VDC 4x192W@48VDC
Radio Frequency : 868/915/434mhz
Waterproof grade: IP20
Safety & Warnings
• DO NOT install with power applied to device.
• DO NOT expose the device to moisture.

Pair/delete the pairing with RF remote

1.Do wiring according to connection diagram.
2.Pair RF Receiver with RF remote: please refer to the instruction of the remote that you would like to pair with.
3.Delete the pairing:
(1)Wire up the RF receiver correctly, power on.
(2)Press and hold down the " Learning Key" button on receiver for over 3 seconds until the connected light
flashes, which means well deleted.

PUSH DIM:

When connected to Push Switch, click push switch for switch ON/OFF,hold push switch to dim up/down the
brightness

Product Dimension

170 mm
Common Anode Output(+)
V+
CH 1 output(-)
CH1
CH 2 output(-)
CH2
CH 3 output(-)
CH3
CH 4 output(-)
CH4
Connector
Wire Size Remarks
Current Rating
2
0.05-3.3mm
Max. 20A Constant voltage
(12-30AWG)

Wiring Diagram

Wiring Diagram
70020037

1) When total load of each receiver is not over 20A

V+
12V/24V/36V/48V
CV PSU
V-
V+
V-
RF Controller
Learning
Switch
GND
V+
V-
RF Controller
Learning
Switch
GND
2) When Total Load Of Each Receiver Is Over 20A
Size(LxWxH)
170x59x29mm
V+
12V/24V/36V/48V
CV PSU
V-
V+ V-
V+
V-
Learning
Switch
GND
With Push Switch
1) When total load of each receiver is not over 20A
PUSH
SWITCH Can be controlled by
L
N
G
V+ V+
V+
1- V-
CH1
CH2
CH3
CH4
2- V-
3- V-
4- V-
V+ V+
V+
1- V-
CH1
CH2
CH3
CH4
2- V-
3- V-
4- V-
L
N
G
V+ V+
V+
1- V-
CH1
RF Controller
CH2
CH3
CH4
2- V-
3- V-
4- V-
L
V+
12V/24V/36V/48V
N
CV PSU
V-
G
V+ V+
V- CH1
RF Controller
Learning
Switch CH2
CH3
CH4
GND
push switch
AC Power
50/60Hz
Connect with Single Color LED
Connect with Single Color LED
AC Power
50/60Hz
Connect with Single Color LED
AC Power
50/60Hz
V+ V+
Connect with Single Color LED
1- V-
2- V-
3- V-
4- V-
