M.2 (P80) 4IG2-P Table of contents 1. PRODUCT OVERVIEW ............................8 1.1 I M.2 (P80) 4IG2-P ................8 NTRODUCTION OF NNODISK 1.2 P ....................... 8 RODUCT IEW AND ODELS ............................9 NTERFACE 2.1 C ....................9 APACITY AND EVICE ARAMETERS 2.2 P ............................
Page 3
M.2 (P80) 4IG2-P 4.3 D ............................19 EVICE RIVE 5. SMART / HEALTH INFORMATION ......................20 5.1 G ) .................... 20 DENTIFIER 6. PART NUMBER RULE ............................25 V1.3 TPS, Feb., 2023...
Page 4
M.2 (P80) 4IG2-P Features: Power Requirements: PCIe Gen. 4x4, NVMe SSD Input Voltage: 3.3V±5% Innodisk 3D TLC NAND Support iSLC technology Max Operating 10.2W M.2 2280-D2-M Wattage: iPowerguard Idle Wattage: 2.4W iDataguard Thermal throttling Management ...
Page 6
M.2 (P80) 4IG2-P List of Tables 1: D ............................. 9 ABLE EVICE PARAMETERS 2: P - 112 L 3D TLC ....................9 ABLE ERFORMANCE AYERS 3: I M.2 (P80) 4IG2-P P ..............10 ABLE NNODISK OWER EQUIREMENT 4: T ......................10 ABLE YPICAL OWER...
Page 7
M.2 (P80) 4IG2-P List of Figures 1: I M.2 (P80) 4IG2-P (S )............8 IGURE NNODISK TANDARD EMPERATURE 2: I M.2 (P80) 4IG2-P (W ) ..............8 IGURE NNODISK EMPERATURE 3: I M.2 (P80) 4IG2-P ....14 IGURE NNODISK WITH HEAT SPREADING COPPER LAYER DIAGRAM 4: I M.2 (P80) 4IG2-P...
TRIM enables SSD’s controller to skip invalid data instead of moving. It can free up significant amount of resources, extends the lifespan of SSD by reducing erase, and write cycles on the SSD. Innodisk’s handling of garbage collection along with TRIM command improves write performance on SSDs.
M.2 (P80) 4IG2-P PCIe Interface Innodisk M.2 (P80) 4IG2-P supports PCIe Gen. 4 interface and compliant with NVMe 1.4. M.2 (P80) 4IG2-P can work under PCIe Gen. 1, Gen. 2, Gen. 3 and Gen. 4. Most of operating system includes NVMe in-box driver now. For more information about the driver support in each OS, please visit http://nvmexpress.org/resources/drivers.
M.2 (P80) 4IG2-P 2.3 Electrical Specifications 2.3.1 Power Requirement Table 3: Innodisk M.2 (P80) 4IG2-P Power Requirement Item Symbol Rating Unit Input voltage +3.3 DC +- 5% 2.3.2 Power Consumption Table 4: Typical Power Consumption Mode Power Consumption (W) Read Write 10.2...
M.2 (P80) 4IG2-P 2.8 Transfer Mode M.2 (P80) 4IG2-P support following transfer mode: PCIe Gen. 4: 8GB/s PCIe Gen. 3: 4GB/s PCIe Gen. 2: 2GB/s PCIe Gen. 1: 1GB/s V1.3 TPS, Feb., 2023...
An Innodisk M.2 (P80) 4IG2-P within NAND flash ICs, 160GB’s weight is 7 grams approximately. 2.12 Seek Time Innodisk M.2 (P80) 4IG2-P is not a magnetic rotating design. There is no seek or rotational latency required. 2.13 NAND Flash Memory Innodisk M.2 (P80) 4IG2-P uses 3D TLC NAND flash memory, which is non-volatility, high...
3.2 PCIe Gen. 4 x4 Controller Innodisk M.2 (P80) 4IG2-P is a PCIe Gen. 4x4 controller is compliant with NVMe 1.4, up to 32.0Gbps transfer speed. Also it is compliant with PCIe Gen. 1, Gen. 2, Gen. 3, and Gen. 4 specification.
Innodisk M.2 (P80) 4IG2-P uses a combination of two types of wear leveling- dynamic and static wear-leveling to distribute write cycling across an SSD and balance erase count of each block, thereby extending flash lifetime.
Die RAID is a controller function which leveraged user capacity to back up the data in NAND flash. Die RAID supported can ensure the user data in the NAND Flash more consistent in certain scenario. Innodisk M.2 (P80) 4IG2-P series is default enable the Die RAID function for the industrial application.
M.2 (P80) 4IG2-P 4. Installation Requirements 4.1 M.2 (P80) 4IG2-P Pin Directions Figure 7: Signal Segment and Power Segment 4.2 Electrical Connections for M.2 (P80) 4IG2-P M.2 interconnect is based on a 75 position Edge Card connector. The 75 position connector is intended to be keyed so as to distinguish between families of host interfaces and the various Sockets used in general Platforms.
Set Features command; please refer to NVM Express 1.3 5.1 Get Log Page (Log Identifier 02h) Innodisk 4IG2-P series SMART / Health Information Log are listed in following table. Table 11: Get Log Page – SMART / Health Information Log...
Page 21
M.2 (P80) 4IG2-P this field may be used to trigger an asynchronous event. Warning and critical overheating composite temperature threshold values are reported by the WCTEMP and CCTEMP fields in the Identify Controller data structure. Available Spare: Contains a normalized percentage (0 to 100%) of the remaining spare capacity available.
Page 22
M.2 (P80) 4IG2-P 79:64 Host Read Commands: Contains the number of read commands completed by the controller. For the NVM command set, this is the number of Compare and Read commands. 95:80 Host Write Commands: Contains the number of write commands completed by the controller.
Page 23
M.2 (P80) 4IG2-P 199:196 Critical Composite Temperature Time: Contains the amount of time in minutes that the controller is operational and the Composite Temperature is greater than the Critical Composite Temperature Threshold (CCTEMP) field in the Identify Controller data structure. If the value of the CCTEMP field is 0h, then this field is always cleared to 0h regardless of the Composite Temperature value.
Page 24
The innodisk M.2 (P80) series thermal sensor take ambient air temperature as a reference with any airflow condition, and the data can refer to iSMART. Notes: More detailed health info has been defined by innodisk and will be shown on iSMART V5.3.21 (or later version).
Page 26
