  • Page 1 3MR2-P Series Customer: Customer Part Number: Innodisk Part Number: Innodisk Model Name: Date: Innodisk Customer Approver Approver...

  • Page 2: Table Of Contents

    2.5” SATA SSD 3MR2-P Table of contents LIST OF FIGURES ......................6 1. PRODUCT OVERVIEW ....................7 1.1 I 2.5” SATA SSD 3MR2-P ..........7 NTRODUCTION OF NNODISK 1.2 P ..................7 RODUCT IEW AND ODELS 1.3 SATA I ....................8 NTERFACE 1.4 2.5- ..................
  • Page 3 2.5” SATA SSD 3MR2-P 3.10 S ....................18 ECURITY RASE 1. AFFSI5020 ...................... 20 2. DoD 5220.22-M ....................21 3. USA Navy NAVSO P-5239-26 ................22 4. NSA Manual 130-2 ..................23 5. USA-Army 380-19 ................... 24 6. NISPOMSUP Chap 8, Sect. 8-501 ..............25 7.
  • Page 4 2.5” SATA SSD 3MR2-P EVISION ISTORY Revision Description Date Rev 1.0 First Released April, 2017 Rev 1.0 TPS, Apr., 2017...

  • Page 5: List Of Tables

    2.5” SATA SSD 3MR2-P List of Tables 1: D ................... 9 ABLE EVICE PARAMETERS 2: P ....................9 ABLE ERFORMANCE 3: I 2.5” SATA SSD 3MR2-P P ........10 ABLE NNODISK OWER EQUIREMENT 4: P ..................10 ABLE OWER ONSUMPTION 5: T 2.5”...

  • Page 6: List Of Figures

    2.5” SATA SSD 3MR2-P List of Figures 1: I 2.5” SATA SSD 3MR2-P ..............7 IGURE NNODISK 2: I D 2.5” SATA SSD 3MR2-P B ........15 IGURE NNODISK LOCK IAGRAM 3: S .............. 35 IGURE IGNAL EGMENT AND OWER EGMENT Rev 1.0 TPS, Apr., 2017...

  • Page 7: Product Overview

    MIL-STD-810G standards. The SSD is equipped ruggedized hardware design and thus it can perform well in the harsh environment. Furthermore, Innodisk 2.5” SATA SSD 3MR2-P supports TRIM for windows 7, which can improve performance when deleting files. 2.5” SATA SSD 3MR2-P is developed with Innodisk owned technical knowhow to ensure the data integrity and highest levels of reliability.

  • Page 8: Sata Interface

    II. SATA III interface can work with Serial Attached SCSI (SAS) host system, which is used in server computer. Innodisk 2.5” SATA SSD 3MR2-P is compliant with Serial ATA Gen 1, Gen 2 and Gen 3 specification (Gen 3 supports 1.5Gbps /3.0Gbps/6.0Gbps data rate). SATA connector uses a 7-pin signal segment and a 15-pin power segment.

  • Page 9: Product Specifications

    2.5” SATA SSD 3MR2-P 2. Product Specifications 2.1 Capacity and Device Parameters 2.5” SATA SSD 3MR2-P device parameters are shown in Table 1. Table 1: Device parameters User Capacity Cylinders Heads Sectors Capacity(MB) 13695696 13587 6687 16GB 16383 29323728 14318 32GB 60579792 16383...

  • Page 10: Electrical Specifications

    2.5” SATA SSD 3MR2-P 2.3 Electrical Specifications 2.3.1 Power Requirement Table 3: Innodisk 2.5” SATA SSD 3MR2-P Power Requirement Item Symbol Rating Unit Input voltage +5 DC +- 5% 2.3.2 Power Consumption Table 4: Power Consumption Mode Power Consumption Read 122 mA (max.)

  • Page 11: Ce And Fcc Compatibility

    Table 7: 2.5” SATA SSD 3MR2-P MTBF Product Condition MTBF (Hours) Innodisk 2.5” SATA SSD 3MR2-P Telcordia SR-332 GB, 25°C >3,000,000 2.5 CE and FCC Compatibility 2.5” SATA SSD 3MR2-P conforms to CE and FCC requirements.

  • Page 12: Pin Assignment

    2.5” SATA SSD 3MR2-P 2.9 Pin Assignment Innodisk 2.5” SATA SSD 3MR2-P uses a standard SATA pin-out. See Table 8 for 2.5” SATA SSD 3MR2-P pin assignment. Table 8: Innodisk 2.5” SATA SSD 3MR2-P Pin Assignment Name Type Description Differential Signal Pair A...

  • Page 13: Mechanical Dimensions

    2.5” SATA SSD 3MR2-P 2.10 Mechanical Dimensions DRS25-XXXD81BX1XX DRS25-02TD81BXAXX Rev 1.0 TPS, Apr., 2017...

  • Page 14: Assembly Weight

    An Innodisk 2.5” SATA SSD 3MR2-P within MLC flash ICs, 1TB’s weight is 90 grams approx. 2.12 Seek Time Innodisk 2.5” SATA SSD 3MR2-P is not a magnetic rotating design. There is no seek or rotational latency required. 2.13 Hot Plug The SSD support hot plug function and can be removed or plugged-in during operation.

  • Page 15: Theory Of Operation

    Communication with the flash device(s) occurs through the flash interface. 3.2 SATA III Controller Innodisk 2.5” SATA SSD 3MR2-P is designed with ID 201, a SATA III 6.0Gbps (Gen. 3) controller, which supports external DDDR3 DRAM. The Serial ATA physical, link and transport layers are compliant with Serial ATA Gen 1, Gen 2 and Gen 3 specification (Gen 3 supports 1.5Gbps/3.0Gbps/6.0Gbps data rate).

  • Page 16: Wear-Leveling

    Innodisk 2.5” SATA SSD 3MR2-P uses a static wear-leveling algorithm to ensure that consecutive writes of a specific sector are not written physically to the same page/block in the flash. This spreads flash media usage evenly across all pages, thereby extending flash lifetime.

  • Page 17: Icell Technology

    2.5” SATA SSD 3MR2-P 3.8 iCell Technology iCell circuit is designed with several capacitors to be able to provide power after host power off. The SSD controller can write all DRAM buffer data to flash, so that is why 2.5” SATA SSD 3MR2-P can ensure all data can be written to disk without any data loss.

  • Page 18: Security Erase

    Command. All Data Block of flash chip will be erased by sending flash erase command. SE Pin can be set as one military Secure Erase standards. Innodisk provides the following Security Erase for options: (1) AFFSI 5020 (2) DoD 5220.22-M...
  • Page 19 2.5” SATA SSD 3MR2-P 3.10.1 Secure Erase Command Identify Information Word 159 of Identify Table shows the SE pin’s function. Identify Table can be read by sending ECh ATA command. Table 9: Identify Information Secure Function Support 7-15 Reserved 1= Secure Erase ATA Vendor Command Supported Reserved 1=Quick Erase ATA Vendor Command Supported 1=Destroy ATA Vendor Command Supported...

  • Page 20: Affsi5020

    2.5” SATA SSD 3MR2-P 0x27: NISPOMSUP Chap 8, Sect. 8-501 0x28: NSA Manual 9-12 0x29: IRIG106 1. AFFSI5020 This function is compliant with AFFSI 5020 specification. Steps: 1. The whole disk is erased using Flash Erase Command. 2. The whole disk is filled with random data. -Protocol: Non Data Command -Inputs Table 10: Execute AFFSI 5020 command for inputs information...

  • Page 21: Dod 5220.22-M

    2.5” SATA SSD 3MR2-P BSY will be cleared to zero indicating command completion DRDY will be set to one. DF (Device Fault) will be cleared to zero. DRQ will be cleared to zero ERR will be cleared to zero. 2. DoD 5220.22-M This function is compliant with DoD 5220.22-M specification.

  • Page 22: Usa Navy Navso P-5239-26

    2.5” SATA SSD 3MR2-P DEV shall specify the selected device. Status register BSY will be cleared to zero indicating command completion DRDY will be set to one. DF (Device Fault) will be cleared to zero. DRQ will be cleared to zero ERR will be cleared to zero.

  • Page 23: Nsa Manual 130-2

    2.5” SATA SSD 3MR2-P LBA Mid LBA High Device Status DRDY Device register- DEV shall specify the selected device. Status register BSY will be cleared to zero indicating command completion DRDY will be set to one. DF (Device Fault) will be cleared to zero. DRQ will be cleared to zero ERR will be cleared to zero.

  • Page 24: Usa-Army 380-19

    2.5” SATA SSD 3MR2-P -Normal Outputs Table 17: NSA Manual 130-2 command for normal output information Register Error Sector Count LBA Low LBA Mid LBA High Device Status DRDY Device register- DEV shall specify the selected device. Status register BSY will be cleared to zero indicating command completion DRDY will be set to one.

  • Page 25: Nispomsup Chap 8, Sect. 8-501

    2.5” SATA SSD 3MR2-P Sector Count LBA Low LBA Mid LBA High Device Command -Normal Outputs Table 19: USA Army 380-19 command for normal output information Register Error Sector Count LBA Low LBA Mid LBA High Device Status DRDY Device register- DEV shall specify the selected device.

  • Page 26: Nsa Manual 9-12

    2.5” SATA SSD 3MR2-P -Inputs Table 20: Execute NISPOMSUP Chap 8, Sect. 8-501 command for inputs information Register Features Sector Count LBA Low LBA Mid LBA High Device Command -Normal Outputs Table 21: NISPOMSUP Chap 8, Sect. 8-501 command for normal output information Register Error Sector Count...
  • Page 27 2.5” SATA SSD 3MR2-P 3. Verify the overwrite procedure by randomly rereading the overwritten information. -Protocol: Non Data Command -Inputs Table 22: Execute NSA Manual 9-12 command for inputs information Register Features Sector Count LBA Low LBA Mid LBA High Device Command -Normal Outputs...

  • Page 28: Irig1006

    2.5” SATA SSD 3MR2-P 8. IRIG1006 This function is compliant with IRIG106 specification. Step: 1. The whole disk is erased using Flash Erase Command. 2. The whole disk is filled with pattern 0x55, and read back to verify. 3. The whole disk is erased using Flash Erase Command. 4.

  • Page 29: Destroy (Firmware Destroy)

    ERR will be cleared to zero. 3.11 Destroy (Firmware Destroy) Innodisk Unrecoverable FW Destroy function implements an ultimate data erase of the SSD. Once Unrecoverable Destroy is triggered, beside all the user data and SSD information, also SSD firmware will be erased and which is unusable. Triggered pin definition is set for optional and available for customization (Pin 1/2 or Pin 3/4).

  • Page 30: Write Protect

    2.5” SATA SSD 3MR2-P Sector Count LBA Low LBA Mid LBA High Device Status DRDY Device register- DEV shall specify the selected device. Status register BSY will be cleared to zero indicating command completion DRDY will be set to one. DF (Device Fault) will be cleared to zero.
  • Page 31 2.5” SATA SSD 3MR2-P Command -Normal Outputs Table 29: Execute Enable Write Protect command for normal output information Register Error Sector Count LBA Low LBA Mid LBA High Device Status DRDY Device register- DEV shall specify the selected device. Status register BSY will be cleared to zero indicating command completion DRDY will be set to one.

  • Page 32: Hardware-Based Aes 256Bit Function (Optional)

    ERR will be cleared to zero. 3.13 Hardware-based AES 256bit function (Optional) Innodisk 2.5” SATA SSD 3MR2-P is designed with AES engine, which is built-in the controller. When controller receives the data package from host, AES engine encrypts the data package and save the encrypted data into NAND flash.
  • Page 33 This method works best for the SSD as a removable device in different systems. Innodisk provides the test tool to execute the AES hardware encryption. This user-friendly tool, developed by Innodisk Corporation, allows the customer to use/test encryption functions.
  • Page 34 0XF6 3.13.5 TCG OPAL OPAL is a set of specifications for features of data storage devices that enhance security. These specifications are published by the Trusted Computing Group’s Storage Work Group. Innodisk (*1) 3MG2-P is compliant with TCG OPAL 2.0 .

  • Page 35: Installation Requirements

    2.5” SATA SSD 3MR2-P 4. Installation Requirements 4.1 2.5” SATA SSD 3MR2-P Pin Directions Quick Erase Security Erase Optional for WP or FW destroy Figure 3: Signal Segment and Power Segment Rev 1.0 TPS, Apr., 2017...

  • Page 36: Electrical Connections For 2.5" Sata Ssd 3Mr2-P

    Please boot the installation Operation System from CD-ROM, and install Operation System into SSD. Figure 4: 2.5” SATA SSD 3MR2-P Mechanical Screw Hole 4.4 Device Drive No additional device drives are required. Innodisk 2.5” SATA SSD 3MR2-P can be configured as a boot device. Rev 1.0 TPS, Apr., 2017...

  • Page 37: Smart Feature Set

    2.5” SATA SSD 3MR2-P 5. SMART Feature Set Innodisk 3MR2-P series support the SMART command set and defines some vendor-specific data to report SMART attributes of SSD. Value Command Read Data Read Attribute Threshold Enable/Disable Autosave Save Attribute Values Execute OFF-LINE Immediate...
  • Page 38 2.5” SATA SSD 3MR2-P 178 (B2h) Runtime invalid block count 181 (B5h) Total program fail count 182 (B6h) Total erase fail count 187 (BBh) Uncorrectable error count 192 (C0h) Power-Off Retract Count 194 (C2h) MSB Controlled temperature 195 (C3h) Hardware ECC recovered 196 (C4h) Reallocation event count 198 (C6h)

  • Page 39: Aes Algorithm Certification

    2.5” SATA SSD 3MR2-P 6. AES Algorithm Certification The following provides technical information about controller implementations that have been validated as confirming to the Advanced Encryption Standard (AES) Algorithm, Deterministic Random Bit Generator (DRBG) Algorithm, and Secure Hash Standard (SHS). 6.1 AES Algorithm Val.

  • Page 40: Rev 1.0 Tps, Apr

    2.5” SATA SSD 3MR2-P Secure Hash Algorithm Validation System (SHAVS). This testing is performed by NVLAP accredited Cryptographic And Security Testing (CST) Laboratories. SHA-256 Rev 1.0 TPS, Apr., 2017...

  • Page 41: Part Number Rule

    2.5” SATA SSD 3MR2-P 7. Part Number Rule 9 10 11 12 CODE R S 2 5 - 3 2 G D 8 1 2.5” SATA Operation Internal Customized Description Disk Capacity Category Flash mode CH. Flash icell SSD 3MR2-P Temp.
  • Page 42 2.5” SATA SSD 3MR2-P Appendix Rev 1.0 TPS, Apr., 2017...
  • Page 43 2.5” SATA SSD 3MR2-P Rev 1.0 TPS, Apr., 2017...
  • Page 44 2.5” SATA SSD 3MR2-P Rev 1.0 TPS, Apr., 2017...
  • Page 45 2.5” SATA SSD 3MR2-P Rev 1.0 TPS, Apr., 2017...
