2.5" SATA SSD 3TI7
Customer:
Customer
Part
Number:
Innodisk
Part
Number:
Innodisk
Model Name:
Date:
Innodisk
Customer
Approver
Approver

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the InnoAGE 2.5” SATA SSD 3TI7 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Innodisk InnoAGE 2.5” SATA SSD 3TI7

Summary of Contents for Innodisk InnoAGE 2.5” SATA SSD 3TI7

  • Page 1 2.5” SATA SSD 3TI7 Customer: Customer Part Number: Innodisk Part Number: Innodisk Model Name: Date: Innodisk Customer Approver Approver...

  • Page 2: Table Of Contents

    InnoAGE 2.5” SATA SSD 3TI7 Table of contents LIST OF FIGURES ......................6 1. PRODUCT OVERVIEW ....................7 1.1 I AGE 2.5” SATA SSD 3TI7 ..........7 NTRODUCTION OF 1.2 P RODUCT IEW AND ODELS ....................... 7 1.3 SATA I NTERFACE ...........................
  • Page 3 InnoAGE 2.5” SATA SSD 3TI7 3.8 G /TRIM ......................19 ARBAGE OLLECTION 3.9 T ..............................19 3.10 OWER UARD ..........................20 3.11 D RAID ............................20 3.12 H 256- AES ....................20 ARDWARE BASED 3.12.1 I AGE SSD AES F WITH HART ...................
  • Page 4 InnoAGE 2.5” SATA SSD 3TI7 EVISION ISTORY Revision Description Date Rev 1.0 First Released Apr., 2020 Rev 1.0 TPS, Apr., 2020...
  • Page 5 InnoAGE 2.5” SATA SSD 3TI7 List of Tables 1: D ABLE EVICE PARAMETERS ............................. 8 2: P ABLE ERFORMANCE ..............................9 3: I AGE 2.5” SATA SSD 3TI7 P ABLE NNODISK OWER EQUIREMENT ..........9 4: P ABLE OWER ONSUMPTION ..........................

  • Page 6: List Of Figures

    InnoAGE 2.5” SATA SSD 3TI7 List of Figures 1: I AGE 2.5” SATA SSD 3TI7 ..................7 IGURE NNODISK 2: I 2.5” SATA SSD 3TI7 B IGURE NNODISK LOCK IAGRAM ..........17 3: E IGURE DGE TO LOUD YSTEM RCHITECTURE ....................

  • Page 7: Product Overview

    TRIM enables SSD’s controller to skip invalid data instead of moving. It can free up significant amount of resources, extends the lifespan of SSD by reducing erase, and write cycles on the SSD. Innodisk’s handling of garbage collection along with TRIM command improves write performance on SSDs.

  • Page 8: Sata Interface

    InnoAGE 2.5” SATA SSD 3TI7 1.3 SATA Interface Innodisk InnoAGE 2.5” SATA SSD 3TI7 supports SATA III(6.0Gb/s) interface, and compliant with SATA I (1.5Gb/s) and SATA II(3.0Gb/s). 2. Product Specifications 2.1 Capacity and Device Parameters InnoAGE 2.5” SATA SSD 3TI7 device parameters are shown in Table 1.

  • Page 9: Performance

    67,000 74,000 Write (QD32) Note: the information is based on CrystalDiskMark 5.1.2 with file size 1000MB test pattern 2.3 Electrical Specifications 2.3.1 Power Requirement Table 3: Innodisk InnoAGE 2.5” SATA SSD 3TI7 Power Requirement Item Symbol Rating Unit Input voltage +5 DC +- 5% 2.3.2 Power Consumption...

  • Page 10: Humidity

    Table 7: InnoAGE 2.5” SATA SSD 3TI7 MTBF Product Condition MTBF (Hours) Innodisk InnoAGE 2.5” SATA Telcordia SR-332 GB, 25°C >3,000,000 SSD 3TI7 2.5 CE and FCC Compatibility InnoAGE 2.5” SATA SSD 3TI7 conforms to CE and FCC requirements.

  • Page 11: Reliability

    InnoAGE 2.5” SATA SSD 3TI7 2.7 Reliability Parameter Value Read Cycles Unlimited Read Cycles Flash endurance 3,000 P/E cycles Wear-Leveling Algorithm Support Bad Blocks Management Support DIE RAID Recovery Support Error Correct Code Support TBW* (Total Bytes Written) Units: TB Capacity Sequential workload Client workload...

  • Page 12: Transfer Mode

    2.9.1 SATA Connector pin assignment Innodisk InnoAGE 2.5” SATA SSD 3TI7 uses a standard SATA pin-out. See Table 8 for InnoAGE 2.5” SATA SSD 3TI7 pin assignment. Table 8: Innodisk InnoAGE 2.5” SATA SSD 3TI7 Pin Assignment Name Type Description...

  • Page 13: Innoage Tm 2.5" Sata Ssd Pin Header Definition

    GPIO pins to connect with system for customized application. Pin header 2 is design for connecting with daughter board from SPI to Ethernet. See table 9 and 10. Table 9: Innodisk InnoAGE 2.5” SATA SSD 3TI7 Pin Header 1 Assignment...

  • Page 14: Figure 1: Innodisk Inno

    InnoAGE 2.5” SATA SSD 3TI7 Table 10: Innodisk InnoAGE 2.5” SATA SSD 3TI7 Pin Header 2 Assignment MISO H2/Pin 1 H2/Pin 3 H2/Pin 5 H1/Pin 7 H1/Pin 9 H2/Pin 2 H2/Pin 4 H2/Pin 6 H1/Pin 7 H1/Pin 9 MOSI 3.3V...

  • Page 15: Mechanical Dimensions

    InnoAGE 2.5” SATA SSD 3TI7 2.10 Mechanical Dimensions 2.10.1 InnoAGE 2.5” SATA SSD * DES25-XXXDK1EXXXF(256~1TB) * DES25-XXXDK1EXXXF(256~1TB) * DES25-XXXDK1EXXXF(256~1TB) * DES25-XXXDK1EXXXF(256~1TB) * DES25-XXXDK1EXXXF(256~1TB) * DES25-XXXDK1EXXXF(256~1TB) * DES25-XXXDK1EXXXF(256~1TB) * DES25-XXXDK1EXXXF(256~1TB) * DES25-XXXDK1EXXXF(256~1TB) * DES25-XXXDK1EXXXF(256~1TB) 2.10.2 Ethernet Daughter Board Horizontal Type Vertical Type Cable Connection to Ethernet Daughter Board Rev 1.0 TPS, Apr., 2020...

  • Page 16: Assembly Weight

    InnoAGE 2.5” SATA SSD 3TI7 2.11 Assembly Weight An Innodisk InnoAGE 2.5” SATA SSD 3TI7 within flash ICs, 32GB’s weight is 8 grams approximately. 2.12 Seek Time Innodisk InnoAGE SATA SSD 3TI7 is not a magnetic rotating design. There is no seek or rotational latency required.

  • Page 17: Theory Of Operation

    InnoAGE 2.5” SATA SSD 3TI7 3. Theory of Operation 3.1 Overview Figure 2 shows the operation of Innodisk InnoAGE 2.5” SATA SSD 3TI7 from the system level, including the major hardware blocks. Figure 2: Innodisk InnoAGE 2.5” SATA SSD 3TI7 Block Diagram Innodisk InnoAGE 2.5”...

  • Page 18: Error Detection And Correction

    Figure 4: InnoAGE SSD with an embedded Azure Sphere 3.4 Error Detection and Correction Innodisk InnoAGE 2.5” SATA SSD 3TI7 is designed with hardware LDPC ECC engine with hard-decision and soft-decision decoding. Low-density parity-check (LDPC) codes have excellent error correcting performance close to the Shannon limit when decoded with the belief-propagation (BP) algorithm using soft-decision information.

  • Page 19: Wear-Leveling

    Innodisk InnoAGE InnoAGE 2.5” SATA SSD 3TI7 uses a static wear-leveling algorithm to ensure that consecutive writes of a specific sector are not written physically to the same page/block in the flash.

  • Page 20: Ipower Guard

    Die RAID is a controller function which leveraged user capacity to back up the data in NAND flash. Die RAID supported can ensure the user data in the NAND Flash more consistent in certain scenario. Innodisk M.2 (S80) 3TE7 series is default enable the Die RAID function for the industrial application.

  • Page 21: Encrypted Key Management

    The SSD must keep the encrypted key value when receiving the reset commands. This method works best for the SSD as a removable device in different systems. Innodisk provides the test tool to execute the AES hardware encryption. This user-friendly tool, developed by Innodisk Corporation, allows the customer to use/test encryption functions.

  • Page 22: Quick Erase

    InnoAGE 2.5” SATA SSD 3TI7 Figure 5: InnoAGE SSD partitioned for future recovery purposes Figure 6: PC reset pin connection to InnoAGE SSD Block Diagram 3.13 Quick Erase Quick Erase function is designed for emergency data erase in few seconds by providing ATA command.

  • Page 23: Sanitizing Innoage Ssd

    InnoAGE 2.5” SATA SSD 3TI7 3.15 Sanitizing InnoAGE SSD Sanitizing means rendering encrypted data useless by changing the AES encryption key. This operation is initiated through the ATA Cryptographic Erase command. After the key has been altered, the data written with the previous key would appear to be random, incomprehensible data. This function also allows the user to verify that hardware encryption actually works.

  • Page 24: Figure 8: Screenshot Ofi

    InnoAGE 2.5” SATA SSD 3TI7 Figure 8: Screenshot of InnoAGE SSD management platform Rev 1.0 TPS, Apr., 2020...

  • Page 25: Innoage 2.5" Sata Ssd 3Ti7 Pin Directions

    InnoAGE 2.5” SATA SSD 3TI7 4. Installation Requirements 4.1 InnoAGE 2.5” SATA SSD 3TI7 Pin Directions Figure 9: Signal Segment and Power Segment 4.2 Electrical Connections for InnoAGE 2.5” SATA SSD 3TI7 A Serial ATA device may be either directly connected to a host or connected to a host through an adaptor card.

  • Page 26: Device Drive

    InnoAGE 2.5” SATA SSD 3TI7 4.4 Device Drive No additional device drives are required. Innodisk InnoAGE 2.5” SATA SSD 3TI7 can be configured as a boot device. Rev 1.0 TPS, Apr., 2020...

  • Page 27: Smart Feature Set

    InnoAGE 2.5” SATA SSD 3TI7 5. SMART Feature Set Innodisk 3TI7 series support the SMART command set and defines some vendor-specific data to report SMART attributes of SSD. Table 11: SMART command Value Command Value Command Read Data Read Log...
  • Page 28 InnoAGE 2.5” SATA SSD 3TI7 Temperature ID 0 ID 1 ID 2 ID 3 ID 4 ID 5 Flash ID Later bad block info (Read/Write/Erase) Total LBA written(LBA=32MB) Total LBA read(LBA=32MB) Rev 1.0 TPS, Apr., 2020...

  • Page 29: Part Number Rule

    InnoAGE 2.5” SATA SSD 3TI7 6. Part Number Rule 11 12 19 20 21 22 23 CODE D T S 2 5 - 4 G D K 1 E 1 0 G - X X X Flash Operation Internal OS back up Customized Description Disk 2.5”...

  • Page 30: Appendix

    InnoAGE 2.5” SATA SSD 3TI7 7. Appendix Rev 1.0 TPS, Apr., 2020...
  • Page 31 InnoAGE 2.5” SATA SSD 3TI7 Rev 1.0 TPS, Apr., 2020...
  • Page 32 InnoAGE 2.5” SATA SSD 3TI7 Rev 1.0 TPS, Apr., 2020...
  • Page 33 InnoAGE 2.5” SATA SSD 3TI7 Rev 1.0 TPS, Apr., 2020...
  • Page 34 InnoAGE 2.5” SATA SSD 3TI7 Rev 1.0 TPS, Apr., 2020...
  • Page 35 InnoAGE 2.5” SATA SSD 3TI7 Rev 1.0 TPS, Apr., 2020...
  • Page 36 InnoAGE 2.5” SATA SSD 3TI7 Rev 1.0 TPS, Apr., 2020...
