Innodisk 3TS6-P Series Manual

2.5" sata ssd
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
3TS6-P Series
Customer:
Customer
Part
Number:
Innodisk
Part
Number:
Innodisk
Model Name:
Date:
Innodisk
Customer
Approver
Approver

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3TS6-P Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Innodisk 3TS6-P Series

Summary of Contents for Innodisk 3TS6-P Series

  • Page 1 3TS6-P Series Customer: Customer Part Number: Innodisk Part Number: Innodisk Model Name: Date: Innodisk Customer Approver Approver...
  • Page 2  Sequential Write up to 460 MB/s 400GB 0.82 800GB 1089 0.82 1.6TB 2178 0.82 3.2TB 4356 0.82 Data Retention 10 Years Warranty 5 Years DWPD based on Enterprise workload with 5 years limited warranty. For warranty details, please refer to: https://www.innodisk.com/en/support_and_service/warranty...

  • Page 3: Table Of Contents

    2.5” SATA SSD 3TS6-P Table of contents LIST OF FIGURES ......................7 1. PRODUCT OVERVIEW ....................8 1.1 I 2.5” SATA SSD 3TS6-P ..........8 NTRODUCTION OF NNODISK 1.2 P ..................8 RODUCT IEW AND ODELS 1.3 SATA I ....................9 NTERFACE 1.4 2.5- ..................
  • Page 4 2.5” SATA SSD 3TS6-P 3.11 Q ) ................... 18 UICK RASE PTIONAL 3.11.1 Quick Erase Command ................19 3.12 W ) ................20 RITE ROTECT PTIONAL 3.12.1 Write Protect Command ................20 3.12.2 Disable Write Protect Command .............. 21 4. INSTALLATION REQUIREMENTS ................23 4.1 2.5”...
  • Page 5 2.5” SATA SSD 3TS6-P EVISION ISTORY Revision Description Date First Released June, 2022 V1.0 TPS, June, 2022...
  • Page 6 2.5” SATA SSD 3TS6-P List of Tables 1: D ABLE EVICE PARAMETERS ........................... 10 2: P - 112 L 3D TLC ....................10 ABLE ERFORMANCE AYERS 3: S - 112 L 3D TLC ................10 ABLE USTAIN ERFORMANCE AYERS 4: L (QD1) ............................

  • Page 7: List Of Figures

    2.5” SATA SSD 3TS6-P List of Figures 1: I 2.5” SATA SSD 3TS6-P ....................8 IGURE NNODISK 2: I 2.5” SATA SSD 3TS6-P B IGURE NNODISK LOCK IAGRAM ..............16 3: D 2.5” SATA SSD IGURE IAGRAM OF WITH I ..................

  • Page 8: Product Overview

    TRIM enables SSD’s controller to skip invalid data instead of moving. It can free up significant amount of resources, extends the lifespan of SSD by reducing erase, and write cycles on the SSD. Innodisk’s handling of garbage collection along with TRIM command improves write performance on SSDs.

  • Page 9: Sata Interface

    2.5” SATA SSD 3TS6-P 1.3 SATA Interface Innodisk 2.5” SATA SSD 3TS6-P supports SATA III interface, and backward compliant with SATA I and SATA II. 1.4 2.5-inch Form Factor The Industry-standard 2.5-inch form factor design with metal material case is easy for installation, which has a compact design 69.85mm (W) x 100.00mm (L) x 7.00mm (H)

  • Page 10: Product Specifications

    2.5” SATA SSD 3TS6-P 2. Product Specifications 2.1 Capacity and Device Parameters 2.5” SATA SSD 3TS6-P device parameters are shown in Table 1. Table 1: Device parameters User Capacity Cylinders Heads Sectors Capacity(MB) 200GB 390721968 16383 190782 400GB 781422768 16383 381554 800GB 1562824368...

  • Page 11: Electrical Specifications

    2. Based on Random 4KB QD=1 workloads, measured as the time taken for 99.9 percentile of commands to finish the round-trip from host to drive and back to host. 2.3 Electrical Specifications 2.3.1 Power Requirement Table 6: Innodisk 2.5” SATA SSD 3TS6-P Power Requirement Item Symbol Rating...

  • Page 12: Power Consumption

    2.5” SATA SSD 3TS6-P 2.3.2 Power Consumption Table 7: Typical Power Consumption Mode Unit 200GB 400GB 800GB 1.6TB 3.2TB Read Write Watt (W) Idle Power-on Peak Note: Current results may vary depending on system components and power circuit design. Please refer to the test report for other capacities. 2.4 Environmental Specifications 2.4.1 Temperature Ranges Table 8: Temperature range for 2.5”...

  • Page 13: Ce And Fcc Compatibility

    2.5” SATA SSD 3TS6-P Product Condition MTBF (Hours) Innodisk 2.5” SATA SSD 3TS6-P Telcordia SR-332 GB, 25°C >3,000,000 2.5 CE and FCC Compatibility 2.5” SATA SSD 3TS6-P conforms to CE and FCC requirements. 2.6 RoHS Compliance 2.5” SATA SSD 3TS6-P is fully compliant with RoHS directive.

  • Page 14: Pin Assignment

    2.5” SATA SSD 3TS6-P 2.9 Pin Assignment Innodisk 2.5” SATA SSD 3TS6-P uses a standard SATA pin-out. See Table 11 for 2.5” SATA SSD 3TS6-P pin assignment. Table 11: Innodisk 2.5” SATA SSD 3TS6-P Pin Assignment Name Type Description Differential Signal Pair A...

  • Page 15: Mechanical Dimensions

    DSS25-XXXM71KCAXFP 2.11 Assembly Weight An Innodisk 2.5” SATA SSD 3TS6-P within 3D TLC flash ICs, 1.6TTB’s weight is 90 grams approx. 2.12 Seek Time Innodisk 2.5” SATA SSD 3TS6-P is not a magnetic rotating design. There is no seek or rotational latency required.

  • Page 16: Overview

    2.5” SATA SSD 3TS6-P 3. Theory of Operation 3.1 Overview Figure 2 shows the operation of Innodisk 2.5” SATA SSD 3TS6-P from the system level, including the major hardware blocks. Figure 2: Innodisk 2.5” SATA SSD 3TS6-P Block Diagram Innodisk 2.5” SATA SSD 3TS6-P integrates a SATA III controller and NAND flash memories.

  • Page 17: Wear-Leveling

    Innodisk 2.5” SATA SSD 3TS6-P uses a static wear-leveling algorithm to ensure that consecutive writes of a specific sector are not written physically to the same page/block in the flash. This spreads flash media usage evenly across all pages, thereby extending flash lifetime.

  • Page 18: Icell Technology

    Die RAID is a controller function which leveraged user capacity to back up the data in NAND flash. Die RAID supported can ensure the user data in the NAND Flash more consistent in certain scenario. Innodisk 2.5” SATA SSD 3TS6-P series is default enable the Die RAID function for the industrial application.

  • Page 19: Quick Erase Command

    2.5” SATA SSD 3TS6-P 3.11.1 Quick Erase Command - Protocol: No Data -Inputs Table 12: Execute Quick Erase command for inputs information Register Features Sector Count LBA Low LBA Mid LBA High Device Command -Normal Outputs Table 13: Quick Erase command for normal output information Register Error Sector Count...

  • Page 20: Write Protect (Optional)

    2.5” SATA SSD 3TS6-P 3.12 Write Protect (Optional) Write Protect can be triggered by sending ATA command or shorting GPIO Pins (GPIO Pins optional for certain Part Numbers). When Write Protect function is enabled, ATA write command would be aborted, which can prevent the disk from data modification or data deletion. Write-protected data in disk is read-only, that is, users could not write to it, edit it, append data to it, or delete it.

  • Page 21: Disable Write Protect Command

    2.5” SATA SSD 3TS6-P Status DRDY Device register- DEV shall specify the selected device. Status register BSY will be cleared to zero indicating command completion DRDY will be set to one. DF (Device Fault) will be cleared to zero. DRQ will be cleared to zero ERR will be cleared to zero.
  • Page 22 2.5” SATA SSD 3TS6-P Device register- DEV shall specify the selected device. Status register BSY will be cleared to zero indicating command completion DRDY will be set to one. DF (Device Fault) will be cleared to zero. DRQ will be cleared to zero V1.0 TPS, June, 2022...

  • Page 23: Installation Requirements

    2.5” SATA SSD 3TS6-P 4. Installation Requirements 4.1 2.5” SATA SSD 3TS6-P Pin Directions Figure 4: Signal Segment and Power Segment 4.2 Electrical Connections for 2.5” SATA SSD 3TS6-P A Serial ATA device may be either directly connected to a host or connected to a host through a cable.

  • Page 24: Device Drive

    2.5” SATA SSD 3TS6-P Figure 5: 2.5” SATA SSD 3TS6-P Mechanical Screw Hole 4.4 Device Drive No additional device drives are required. Innodisk 2.5” SATA SSD 3TS6-P can be configured as a boot device. V1.0 TPS, June, 2022...

  • Page 25: Smart Feature Set

    2.5” SATA SSD 3TS6-P 5. SMART Feature Set Innodisk 3TS6-P series support the SMART command set and defines some vendor-specific data to report SMART attributes of SSD. Value Command Read Data Read Attribute Threshold Enable/Disable Autosave Save Attribute Values Execute OFF-LINE Immediate...

  • Page 26: Smart Attributes

    2.5” SATA SSD 3TS6-P 5.1 SMART Attributes Innodisk 3TS6-P series SMART data attributes are listed in following table. Attribute Raw Attribute Value Attribute Name ID (hex) 5 (05h) Later Bad 9 (09h) Power-On hours Count 12 (0Ch) Drive Power Cycle Count...

  • Page 27: Part Number Rule

    2.5” SATA SSD 3TS6-P 6. Part Number Rule 9 10 11 12 CODE S S 2 5 - 2 0 0 M 7 1 2.5” SATA Operation Internal Customized Description Disk Capacity Category Flash mode CH. Flash icell Temp. Control Code Definition Code 1...
