- Page 1 3SE-P Series Customer: Customer Part Number: Innodisk Part Number: Innodisk Model Name: Date: Innodisk Customer Approver Approver...
-
Page 2: Table Of Contents
2.5” SATA SSD 3SE-P Table of contents LIST OF FIGURES ......................6 1. PRODUCT OVERVIEW ....................7 1.1 I 2.5” SATA SSD 3SE-P ..........7 NTRODUCTION OF 1.2 P ..................7 RODUCT IEW AND ODELS 1.3 SATA I ....................8 NTERFACE 1.4 2.5- .................. - Page 3 2.5” SATA SSD 3SE-P 4.1 2.5” SATA SSD 3SE-P P ..............16 IRECTIONS 4.2 E 2.5” SATA SSD 3SE-P ..........16 LECTRICAL ONNECTIONS FOR 4.3 F ...................... 16 ACTOR 4.4 D ..................... 17 EVICE RIVE 5. PART NUMBER RULE ....................18 Rev 1.6 TPS, Jul., 2015...
- Page 4 2.5” SATA SSD 3SE-P EVISION ISTORY Revision Description Date Preliminary First Released May, 2013 Rev 1.0 Modify ME dimension Aug., 2013 Update 16GB/32GB performance Add power consumption Rev 1.1 Modify 8GB/256GB performance Sep., 2013 Rev 1.2 Update LBA Nov., 2013 Rev 1.3 Modify Part Number rule Jan., 2014...
- Page 5 2.5” SATA SSD 3SE-P List of Tables 1: D ................... 9 ABLE EVICE PARAMETERS 2: P ....................9 ABLE ERFORMANCE 3: I 2.5” SATA SSD 3SE-P P ......... 9 ABLE OWER EQUIREMENT 4: P ..................9 ABLE OWER ONSUMPTION 5: T 2.5”...
-
Page 6: List Of Figures
2.5” SATA SSD 3SE-P List of Figures 1: I 2.5” SATA SSD 3SE-P ..............7 IGURE NNODISK 2: I D 2.5” SATA SSD 3SE-P B ........14 IGURE NNODISK LOCK IAGRAM 3: S .............. 16 IGURE IGNAL EGMENT AND OWER EGMENT Rev 1.6 TPS, Jul., 2015... -
Page 7: Product Overview
It designed with standard 2.5-inch form factor, which can be used in laptop. Innodisk 2.5” SATA SSD 3SE-P is designed for industrial field. The SSD have good performance, no latency time and small seek time. It effectively reduces the booting time of operation system and the power consumption is less than hard disk drive (HDD). -
Page 8: Sata Interface
II. SATA III interface can work with Serial Attached SCSI (SAS) host system, which is used in server computer. Innodisk 2.5” SATA SSD 3SE-P is compliant with Serial ATA Gen 1, Gen 2 and Gen 3 specification (Gen 3 supports 1.5Gbps /3.0Gbps/6.0Gbps data rate). SATA connector uses a 7-pin signal segment and a 15-pin power segment. -
Page 9: Product Specifications
340 MB/sec 340 MB/sec Write (max.) Note: Base on CrystalDiskMark 3.01 with file size 1000MB 2.3 Electrical Specifications 2.3.1 Power Requirement Table 3: InnoDisk 2.5” SATA SSD 3SE-P Power Requirement Item Symbol Rating Unit Input voltage +5 DC +- 5% 2.3.2 Power Consumption... -
Page 10: Environmental Specifications
The mean number of life units during which all parts of the item perform within their specified limits, during a particular measurement interval under stated conditions. Table 7: 2.5” SATA SSD 3SE-P MTBF Product Condition MTBF (Hours) Innodisk 2.5” SATA SSD 3SE-P Telcordia SR-332 GB, 25°C >3,000,000 Rev 1.6 TPS, Jul., 2015... -
Page 11: Ce And Fcc Compatibility
Serial ATA II 3.0Gbps Serial ATA I 1.5Gbps 2.9 Pin Assignment Innodisk 2.5” SATA SSD 3SE-P uses a standard SATA pin-out. See Table 8 for 2.5” SATA SSD 3SE-P pin assignment. Table 8: InnoDisk 2.5” SATA SSD 3SE-P Pin Assignment... -
Page 12: Mechanical Dimensions
2.5” SATA SSD 3SE-P 5V Power, Pre-Charge 5V Power 5V Power DAS/DSS Device Activity Signal / Disable Staggered Spinup 2.10 Mechanical Dimensions 2.11 Assembly Weight An Innodisk2.5” SATA SSD 3SE-P within SLC flash ICs, 16GB’s weight is 100 grams approx. The total weight of SSD will be less than 135 grams. -
Page 13: Seek Time
2.5” SATA SSD 3SE-P 2.12 Seek Time Innodisk 2.5” SATA SSD 3SE-P is not a magnetic rotating design. There is no seek or rotational latency required. 2.13 Hot Plug The SSD support hot plug function and can be removed or plugged-in during operation. User has to avoid hot plugging the SSD which is configured as boot device and installed operation system. -
Page 14: Theory Of Operation
Communication with the flash device(s) occurs through the flash interface. 3.2 SATA III Controller Innodisk 2.5” SATA SSD 3SE-P is designed with ID 167, a SATA III 6.0Gbps (Gen. 3) controller, which supports external DDDR3 DRAM. The Serial ATA physical, link and transport layers are compliant with Serial ATA Gen 1, Gen 2 and Gen 3 specification (Gen 3 supports 1.5Gbps/3.0Gbps/6.0Gbps data rate). -
Page 15: Error Detection And Correction
Innodisk 2.5” SATA SSD 3SE-P uses a static wear-leveling algorithm to ensure that consecutive writes of a specific sector are not written physically to the same page/block in the flash. This spreads flash media usage evenly across all pages, thereby extending flash lifetime. -
Page 16: Installation Requirements
2.5” SATA SSD 3SE-P 4. Installation Requirements 4.1 2.5” SATA SSD 3SE-P Pin Directions Figure 3: Signal Segment and Power Segment 4.2 Electrical Connections for 2.5” SATA SSD 3SE-P A Serial ATA device may be either directly connected to a host or connected to a host through a cable. -
Page 17: Device Drive
2.5” SATA SSD 3SE-P Figure 4: 2.5” SATA SSD 3SE-P Mechanical Screw Hole 4.4 Device Drive No additional device drives are required. Innodisk 2.5” SATA SSD 3SE-P can be configured as a boot device. Rev 1.6 TPS, Jul., 2015... -
Page 18: Part Number Rule
2.5” SATA SSD 3SE-P 5. Part Number Rule CODE D E S 2 5 - 3 2 G D 6 2.5” SATA Flash Operation Internal Customized Description Disk Capacity Category Flash SSD 3SE-P Mode Temp. Control Code Definition Code 1 (Disk) Code 13 (Flash Mode) - Page 19 2.5” SATA SSD 3SE-P Appendix Rev 1.6 TPS, Jul., 2015...
- Page 20 2.5” SATA SSD 3SE-P Rev 1.6 TPS, Jul., 2015...
- Page 21 2.5” SATA SSD 3SE-P Rev 1.6 TPS, Jul., 2015...
- Page 22 2.5” SATA SSD 3SE-P Rev 1.6 TPS, Jul., 2015...
