- Page 1 3ME Series Customer: Customer Part Number: Innodisk Part Number: Innodisk Model Name: Date: Innodisk Customer Approver Approver...
-
Page 2: Table Of Contents
2.5” SATA SSD 3ME Table of contents LIST OF FIGURES ................................6 1. PRODUCT OVERVIEW ............................... 7 1.1 I 2.5” SATA SSD 3ME ..............7 NTRODUCTION OF 1.2 P RODUCT IEW AND ODELS ......................7 1.3 SATA I NTERFACE ..........................7 1.4 2.5- INCH ACTOR... - Page 3 2.5” SATA SSD 3ME 4.1 2.5” SATA SSD 3ME P IRECTIONS ..................16 4.2 E 2.5” SATA SSD 3ME..............16 LECTRICAL ONNECTIONS FOR 4.3 F ACTOR ............................. 16 4.4 D EVICE RIVE ............................ 17 5. PART NUMBER RULE ....................18 6.
- Page 4 2.5” SATA SSD 3ME EVISION ISTORY Revision Description Date Preliminary First Released May, 2013 Rev. 1.0 Add CE/FCC certifications June, 2013 Rev. 1.1 1. Add RoHS declaration July, 2013 2. Add power consumption Rev. 1.1 TPS, July. 2013...
-
Page 5: List Of Tables
2.5” SATA SSD 3ME List of Tables 1: D ................... 9 ABLE EVICE PARAMETERS 2: P ....................9 ABLE ERFORMANCE 3: I 2.5” SATA SSD 3ME P ..........9 ABLE OWER EQUIREMENT 4: P ..................9 ABLE OWER ONSUMPTION 5: T 2.5”... -
Page 6: List Of Figures
2.5” SATA SSD 3ME List of Figures 1: I 2.5” SATA SSD 3ME ................. 7 IGURE NNODISK 2: I D 2.5” SATA SSD 3ME B .......... 14 IGURE NNODISK LOCK IAGRAM 3: S .............. 16 IGURE IGNAL EGMENT AND OWER EGMENT Rev. -
Page 7: Product Overview
SATA III interface can work with Serial Attached SCSI (SAS) host system, which is used in server computer. Innodisk 2.5” SATA SSD 3ME is compliant with Serial ATA Gen 1, Gen 2 and Gen 3 specification (Gen 3 supports 1.5Gbps /3.0Gbps/6.0Gbps data rate). SATA connector uses a 7-pin signal segment and a 15-pin power segment. -
Page 8: Inch Form Factor
2.5-inch is a popular form factor in industrial field. 2.5-inch is most laptop’s hard disk’s form factor. Innodisk 2.5” SATA SSD 3ME can easy install in laptop. Innodisk 2.5” SATA SSD 3ME has a compact design 70mm (W) x100.0mm (L) x 6.8mm (H). -
Page 9: Product Specifications
165 MB/sec 240 MB/sec Write (max.) Note: Base on CrystalDiskMark 3.01 with file size 1000MB 2.3 Electrical Specifications 2.3.1 Power Requirement Table 3: InnoDisk 2.5” SATA SSD 3ME Power Requirement Item Symbol Rating Unit Input voltage +5 DC +- 5% 2.3.2 Power Consumption... -
Page 10: Environmental Specifications
The mean number of life units during which all parts of the item perform within their specified limits, during a particular measurement interval under stated conditions. Table 7: 2.5” SATA SSD 3ME MTBF Product Condition MTBF (Hours) Innodisk 2.5” SATA SSD 3ME Telcordia SR-332 GB, 25°C >3,000,000 Rev. 1.1 TPS, July. 2013... -
Page 11: Ce And Fcc Compatibility
Serial ATA II 3.0Gbps Serial ATA I 1.5Gbps 2.9 Pin Assignment Innodisk 2.5” SATA SSD 3ME uses a standard SATA pin-out. See Table 8 for 2.5” SATA SSD 3ME pin assignment. Table 8: InnoDisk 2.5” SATA SSD 3ME Pin Assignment... -
Page 12: Mechanical Dimensions
2.5” SATA SSD 3ME 5V Power, Pre-Charge 5V Power 5V Power DAS/DSS Device Activity Signal / Disable Staggered Spinup 2.10 Mechanical Dimensions 2.11 Assembly Weight An Innodisk2.5” SATA SSD 3ME within MLC flash ICs, 16GB’s weight is 100 grams approx. The total weight of SSD will be less than 135 grams. -
Page 13: Seek Time
2.5” SATA SSD 3ME 2.12 Seek Time Innodisk 2.5” SATA SSD 3ME is not a magnetic rotating design. There is no seek or rotational latency required. 2.13 Hot Plug The SSD support hot plug function and can be removed or plugged-in during operation. User has to avoid hot plugging the SSD which is configured as boot device and installed op eration system. -
Page 14: Theory Of Operation
2.5” SATA SSD 3ME 3. Theory of Operation 3.1 Overview Figure 2 shows the operation of Innodisk 2.5” SATA SSD 3ME from the system level, including the major hardware blocks. ID106 Figure 2: Innodisk FiD 2.5” SATA SSD 3ME Block Diagram Innodisk 2.5”... -
Page 15: Error Detection And Correction
Innodisk 2.5” SATA SSD 3ME uses a static wear-leveling algorithm to ensure that consecutive writes of a specific sector are not written physically to the same page/block in the flash. This spreads flash media usage evenly across all pages, thereby extending flash lifetime. -
Page 16: Installation Requirements
2.5” SATA SSD 3ME 4. Installation Requirements 4.1 2.5” SATA SSD 3ME Pin Directions Figure 3: Signal Segment and Power Segment 4.2 Electrical Connections for 2.5” SATA SSD 3ME A Serial ATA device may be either directly connected to a host or connected to a host through a cable. -
Page 17: Device Drive
2.5” SATA SSD 3ME Figure 4: 2.5” SATA SSD 3ME Mechanical Screw Hole 4.4 Device Drive No additional device drives are required. Innodisk 2.5” SATA SSD 3ME can be configured as a boot device. Rev. 1.1 TPS, July. 2013... -
Page 18: Part Number Rule
2.5” SATA SSD 3ME 5. Part Number Rule CODE D E S 2 5 - 3 2 G D 0 2.5” SATA Flash Operation Internal Customized Description Disk Capacity Category Flash SSD 3ME Mode Temp. Control Code Definition Code 1 (Disk) Code 13 (Firmware version) -
Page 19: Appendix
2.5” SATA SSD 3ME 6. Appendix CE/FCC/RoHS (TBD) Rev. 1.1 TPS, July. 2013... - Page 20 2.5” SATA SSD 3ME Rev. 1.1 TPS, July. 2013...
- Page 21 2.5” SATA SSD 3ME Rev. 1.1 TPS, July. 2013...
