7. Attach the Base Cover (84) to the Base (94)
with four #8 x 1/2" Screws (1). Be careful not
to overtighten the Screws.
With the help of a second person, tip the tread-
mill so that the Base (94) is flat on the floor.
8. Identify the Left Upright Cover (87). Slide the
Left Upright Cover onto the Left Upright (82).
Identify the Left Handrail (78). Start two 5/16" x
3/4" Patch Bolts (5) and two 5/16" Star Washers
(9) into the Left Handrail and the Left Upright
(82). Then start a 5/16" x 1 1/2" Patch Bolt (4)
into the Left Handrail and the Left Upright. Do
not tighten the Patch Bolts yet.
7
1
84
1
94
1
1
8
78
10
4
9
5
82
87
