Using a loader with your Cyborg

Your marker can operate using any commercially available loader. The software
and beam sensor will compensate for the speed of the hopper, ensuring that
the marker fires as quickly as the loader allows.

Installing a loader onto your Cyborg

Open the cam lever as shown. This should allow your loader neck to fit into
the feed tube as shown. If your loader does not fit into the feed tube, then
you may have to loosen the cam lever - this is done by rotating the cam lever
(anticlockwise). Once your loader is pushed all the way down into the feed
tube, close the cam lever. If your loader is loose, you may need to open the
cam lever, and tighten it (by turning clockwise) to adjust the cam system to
hold your hopper tightly. Only ever adjust your cam lever by one turn at a time
to prevent overtightening.
DO NOT OVER TIGHTEN YOUR FEED CLAMP! OVERTIGHTENING MAY RESULT
IN DAMAGE TO YOUR LOADER OR CLAMP.

Removing your loader

Open the clamp by swinging the lever on its hinge. This will loosen the loader
and allow you to remove it easily. If it does not remove easily, then it means
that you have the cam lever overtightened.
Cyborg 6.indd 11-12

USING YOUR CYBORG

To get the most out of your Cyborg, make sure that you follow the instructions in this section to ensure that the
Cyborg is adjusted correctly.

Adjusting the velocity

Twist lever clockwise to
tighten the cam lever
Your Cyborg is equipped with internal digital gauges to help you tune your gun. Your gun will be pretuned when
system
you get it, so you can adjust your velocity using the adjustment point on the front of your grip frame. use a 1/8"
allen key from the set provided, and use only small adjustments whilst checking over a chrono. Turn anti clock-
wise to increase velocty.
DO NOT ADJUST YOUR VELOCITY ABOVE 300FPS, AND ALWAYS OBEY LOCAL LAWS
AND REQUIREMENTS.

Adjusting the trigger

Your trigger has four adjustment screws, they are located in the front face of the trig-
ger and also on the upper face. In order of top to bottom, they are the trigger rest
point, spring tension, actuation point and stop point.
Push lever into place to
lock your loader onto
the marker
You can easily adjust these screws to personalise the feel of your trigger.
CAUTION! WHEN ADJUSTING THE SWITCH ACTUATION SCREW, MAKE CERTAIN
THAT YOU DO NOT ADJUST THE SCREW IN TOO FAR, AS THIS MAY RESULT IN
DAMAGE TO YOUR MICROSWITCH.
Adjusting your velocity
10
