MACDEV PRIME XTS Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
www.macdevpaintball.com
(c) Copyright 2019 Mac Developments Pty Ltd (MacDev).
MacDev - Proudly Australian
The Prime paintball marker is covered by the following granted patents as well as international pending patents:
U.S. Patent Nos. 5,228,427; 5,755,213; 5,957,119; 6,260,821; 6,349,711; 6,494,195; 6,644,295; 6,644,296; 6,823,857;
6,694,963; 6,810,871; 7,017,497; 7,044,119.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRIME XTS and is the answer not in the manual?

Questions and answers

Related Manuals for MACDEV PRIME XTS

Summary of Contents for MACDEV PRIME XTS

  • Page 1 (c) Copyright 2019 Mac Developments Pty Ltd (MacDev). MacDev - Proudly Australian The Prime paintball marker is covered by the following granted patents as well as international pending patents: U.S. Patent Nos. 5,228,427; 5,755,213; 5,957,119; 6,260,821; 6,349,711; 6,494,195; 6,644,295; 6,644,296; 6,823,857;...
  • Page 2 PRIME PRIME™ XTS Owners Manual...
  • Page 3 Mac Developments Pty. Ltd. All proprietary rights and information are the sole property of Mac Developments Pty. Ltd. MacDev, Prime, Conquest, Gladiator, MatchStick, Cyborg, Shift and Drone are all trademarks of Mac Developments Pty Ltd.
  • Page 4 The MacDev electro-pneumatic marker is warranted to be free from all manufacturing and production defects for a period of 12 months from the date of original purchase. If requested by MacDev, an original proof of purchase must be provided. Warranty exceptions include, but are not limited to, accidental damage, misadventure, reasonable wear and tear and consumable components such as O-rings, detents, batteries and eyes.

  • Page 5: Table Of Contents

    CONTENTS Know your Prime (Page 5) All users should read this section to learn the parts of your Prime and their names. Quick Setup (page 7) Learn how to set your marker up for use the first time. Assemble your barrel Install and air system Fit your loader Turning on your marker...
  • Page 6 Troubleshooting (Page 19) Solving common difficulties. Common problems and solutions Technical assistance Specifications (Page 22)

  • Page 7: Know Your Prime

    KNOW YOUR Prime® XTS...
  • Page 8 The latest features have been added around this powerful base core to bring you a marker with unrivalled usability, quality and reliability. Please take the time to learn the parts of your Prime XTS, it will help you when reading this manual. Numbered basic parts as shown in the figure on the left: 1.

  • Page 9: Quick Setup

    Your marker comes with a Shift 3 barrel system. Screw the two halves together, before screwing the barrel into your marker. The barrel and back are reverse threaded. Your marker is shipped with two inserts. Select the best match to your paint. More Shift 3 inserts are available from MacDev if you require more insert sizes.

  • Page 10: Install And Air System

    Install an air system Your marker can accept any standard screw in air system. A pressure of 450psi is preferred, however 300-800psi is acceptable. 1. Open the lever 2. Screw n an air system 3. Close the lever to engage the air. WHEN SCREWING YOUR AIR SYSTEM INTO THE ASA, THE THREADS SHOULD BE...

  • Page 11: Fit Your Loader

    Fit your loader Use any loader you like with your Prime XTS, your marker will use the beam sensor to wait for a ball 1. Open the lever before firing. If you would like to fire at a faster rate, use a faster loader.

  • Page 12: Turning On Your Marker

    Turning on your marker Tap the power button to turn on. Long press the power button to turn off. Long press the scroll button to toggle the eyes on and off. power button scroll button Understanding the OLED display Your OLED dislay indicates the battery level, eye status, fire mode and recent rate of fire.

  • Page 13: Adjusting Your Velocity

    Adjusting velocity DO NOT ADJUST YOUR VELOCITY ABOVE 300FPS, AND ALWAYS OBEY LOCAL LAWS AND REQUIREMENTS. Use a 1/8” allen key to adjust velocity as shown. The arrow on the diagram is anti clockwise, which is increasing velocity. Always use a chronograph, and use small adjustments.

  • Page 14: Advanced Setup

    ADVANCED SETUP Tourney lock lock button The marker board is equipped with a tourney lock system. When the tourney lock system is activated, the marker cannot be reprogrammed on the field - making it tournament legal. If your board is in locked mode, you can view your settings, but a lock indicator will be shown on the right hand side of the screen, indicating that your board will need to be unlocked before settings may be changed.

  • Page 15: Settings In Detail

    Once you have found a setting you would like to change, press and hold the trigger until the setting changes to red. The setting can now be changed by tapping the scroll button to increase its value (or change to a different option), or tapping the power button to decrease its value.
  • Page 16 Eye sensitivity - the sensitivity of the software to changes in your eyes. Please do not change this parameter unless directed (default 10). Forced shot - when enabled, this will allow the user to force a shot by holding the trigger in - even if the eyes cannot detect a ball.

  • Page 17: Using The Usb Connector

    Changing the front grip angle Your Prime XTS front grip can be used ina an 8 degree or vertical position. It is shipped in the 8 degree position. To change it to vertical, remove the frame completely, and follow these steps:...

  • Page 18: Maintenance

    5 cases. You should perform inline regulator maintenance every 20 cases. You can clean and maintain your marker more often, it is up to you. When maintaining your marker, use only MacDev accessories. Your marker is packaged with an allen key set and a small tube of MacDev Militia Lube, only use Militia Lube for lubrication.

  • Page 19: Maintaining The Drivetrain

    Maintaining the drivetrain (every 10,000 shots) To maintain your drive, ensure your marker is fully degassed and pull the drive cover up to release the drive. Slide the drive out of your Prime. Unscrew the drive parts to access the components shown in the diagram below. Clean the old grease and dirt from the keg, bolt and valve.

  • Page 20: Maintaining The Inline Regulator

    Unscrew regulator from frame (degass marker first) Piston stem The piston may not come out with the regulator (Lubricate here) body. Never use pliers or any tool to grab the piston, this can damage it. Use a 1/8” allen key pushed into the centre hole of the allen key to help remove the #8 o-ring piston if it is lodged in the frame bore.
  • Page 21 If you are experiencing difficulties with your marker, please check this table first to see if there is an easy solution listed. If at any time you are unsure about how to work on your marker, please contact a certified MacDev technician or service centre.
  • Page 22 Symptom Possible Cause Solution The beam sensor is not Bolt is not moving Trying to cycle your Prime without air can reading correctly lead to sensor fault signals, ignore them un- less your bolt is moving back and forth. Eyes are dirty Check that the eyes are clean and not blocked.
  • Page 23 Symptom Possible Cause Solution Your Prime fires high on Creeping regulator Clean and lubricate the reglulator, ensure that the first shot or the seat and piston are in good condition. inconsistently. Your Prime fires low on Sticking drivetrain Clean and relubricate the drivetrain. If you the first shot continue to have problems: -increase the dwell by 1-2 ms.
  • Page 24 Display 65K colour OLED, low power usage 128x32px If you require technical assistance, Power 9V standard battery 6LR61 please contact your local MacDev Fire modes Semi, NXL, PSP, Custom ramp, Full Auto service centre. You can also find Connectivity Mini USB...
