MACDEV XDR Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
XDR
TM
www.macdevpaintball.com
(c) Copyright 2021 Mac Developments Pty Ltd (MacDev).
MacDev - Proudly Australian
This paintball marker is covered by the following granted patents as well as international pending patents:
XDR
TM
U.S. Patent Nos. 5,228,427; 5,755,213; 5,957,119; 6,260,821; 6,349,711; 6,494,195; 6,644,295; 6,644,296; 6,823,857;
Owners Manual
6,694,963; 6,810,871; 7,017,497; 7,044,119.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XDR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MACDEV XDR

Summary of Contents for MACDEV XDR

  • Page 1 (c) Copyright 2021 Mac Developments Pty Ltd (MacDev). MacDev - Proudly Australian This paintball marker is covered by the following granted patents as well as international pending patents: U.S. Patent Nos. 5,228,427; 5,755,213; 5,957,119; 6,260,821; 6,349,711; 6,494,195; 6,644,295; 6,644,296; 6,823,857;...
  • Page 2 Copyright Mac Developments Pty. Ltd. 2021 All rights reserved period of 12 months from the date of original purchase. If requested by MacDev, an original proof of purchase must be provided. Warranty exceptions include, but are not limited to, accidental damage, misadventure, reasonable No part of this document may be copied or reproduced in any form or by any means without the prior written wear and tear and consumable components such as O-rings, detents, batteries and eyes.

  • Page 3: Table Of Contents

    CONTENTS Solving common difficulties. Common problems and solutions Know your Marker (Page 5) Technical assistance All users should read this section to learn the parts of your marker and their names. Specifications (Page 22) Specifications (Page 22) Quick Setup (page 7) Learn how to set your marker up for use the first time.
  • Page 4 KNOW YOUR XDR Congratulations on your purchase of a new MacDev XDR. Your marker uses a highly efficient spool valve drive for a flat, constant and accurate shot. The drive is powered by a high precision, low power solenoid valve, manufactured in house by MacDev.

  • Page 5: Quick Setup

    QUICK SETUP Install an air system Fit your loader Use any loader you like with the elec frame version, your mark- er will use the beam sensor to wait for a ball before firing. If Your marker can accept any standard screw in air 1.

  • Page 6: Turning On Your Marker

    Adjusting velocity Turning on your marker DO NOT ADJUST YOUR VELOCITY ABOVE 300FPS, AND ALWAYS OBEY LOCAL LAWS AND REQUIREMENTS. Use a 1/8” allen key to adjust velocity as shown. Tap the power button to turn on. Long press the power button The arrow on the diagram is anti clockwise, which power button to turn off.

  • Page 7: Using A Mech Frame Accessory

    Using a mech frame accessory Charging your battery Your marker has a LiPO batery buit in. Your marker is shipped with If you have the mech frame accessory, youcan change it the frame the battery charged, so you do not need to charge it before first use using the two frame mounting screws shown.

  • Page 8: Advanced Setup

    ADVANCED SETUP Once you have found a setting you would like to change, press and hold the trigger until the setting flashes. The setting can now be changed by tapping the scroll button to increase its value (or change to a different option), or Tourney lock tapping the power button to decrease its value.

  • Page 9: Maintenance

    - this is the amount of extra dwell given to the solenoid to overcome FSDO - if directed to do so by the above parameter. When maintaining your marker, use only MacDev accessories. Your marker is packaged with a small tube of MacDev Ramp semishots - this setting (and the other three below) is only used if you are using the Ramp firemode.

  • Page 10: Maintaining The Drivetrain

    Maintaining the drivetrain (every 10,000 shots) Unscrew regulator from frame (degass marker first) To maintain your drive, ensure your marker is fully degassed and pull the drive cover up to Piston stem The piston may not come out with the regulator release the drive.

  • Page 11: Troubleshooting

    Bolt is not moving Trying to cycle your marker without air can listed. If at any time you are unsure about how to work on your marker, please contact a certified MacDev technician reading correctly lead to sensor fault signals, ignore them un- or service centre.
  • Page 12 25 BPS (only allowed with eyes on, and paint) MACDEV TECHNICAL Electronics ASSISTANCE Software Militiasoft V1.xx Hardware XDR V1.2 (Lead Free) Display Single colour OLED, low power usage 128x32px If you require technical assistance, Power LiPO 3.7V battery please contact your local MacDev...
