- Page 31 Troubleshooting 101 By James@Macdev Here are the simply and best steps to check for what is wrong if the bolt creeps forward. Step 1 1‐ Remove the power tube cap (black end part with slots) 2‐ Push the power tube out. the first offending o‐ring to check is the middle o‐ring on the power tube. you can do this by sliding the power tube back in slowly and feeling the squeeze on it (note ‐ the front o‐ ring will usually feel stiffer due to it being dryer, this is the o‐ring which falls off the ledge inside the bolt and air continually wants to blow it dry) 3‐Push the power tube in slowly till you feel the front o‐ring fall off the ledge which is the groove inside the bolt. next you should feel the middle o‐ring touch in the bore of the bolt, if it does not touch or feels like it does not touch hard enough it needs replacing. This an 011 just like the switching o‐ring on the cyborg hammer, at this point it is important to use a process of elimination, put the gun back together and try it. if it works good job if not move on to step 2. Step 2 1‐ Remove power tube cap 2‐ Push out power tube 3‐ Unscrew the on/off keg 4‐ Remove the valve from inside the on/off keg. You will notice little dots on one end of the valve this denotes that end goes in first. 5‐ To feel if the o‐rings are sealing correctly you can put the valve back into the keg in reverse, feel for the first o‐ring and if you are unsure if it feels right push it in to try the second o‐ring. 6‐ If the second one is stiffer than the first you can for a quick fix swap them (all rings on the valve are the same size 017). 7‐ put it back together and try it, if it odes not work just replace the o‐rings. Step 3 If it’s leaking out the front its the front power tube o‐ring. ...
