Simplex 4100-6077 Quick Start Manual page 3

Product Selection and Peripherals Reference
MX Loop Interface Module
Model Description
4100-6077 MX Loop interface module for 4100ES and 4100U fire alarm control panels
4010-9917 MX Loop interface module for 4010ES fire alarm control panels
Compatible Peripherals
Addressable Smoke and Heat Sensors and Accessories
Model Description
4098-5201 Heat Sensor
4098-5202 Photoelectric Smoke Sensor
4098-5203 Photoelectric Smoke Sensor with Heat Sensor
4098-5207 5" Sensor Base with Remote LED Output
4098-5208 5" Isolator Base with Remote LED Output
4098-5209 Loop Powered (LP) Sounder Base, 85 dB @ 3 ft (1 m)
4098-5210 Loop Powered (LP) Sounder Base, 85 dB @ 10 ft (3 m)
4098-5211 4-Wire Sounder Base
4098-5275 6" Adapter for the 5" Base
2098-9808 Remote LED Alarm Indicator
4098-5276 Address Flags (pack of 100)
4098-5277 Address Flag Labels
4098-5214 Duct Housing and Accessories
Addressable Manual Stations and Callpoints
Model Description
4099-5201 Single Action Manual Station
4099-5202 Double Action Manual Station
4099-5203 Indoor Callpoint with LED (Breakglass)
4099-5204 Outdoor Callpoint with LED (Breakglass)
Addressable Interface Modules
Model Description
4090-5201 Mini-IAM, supervised contact monitoring module
4090-5202 Dual Input IAM, dual supervised contact monitoring module
4090-5203 Relay IAM
4090-5204 Signal IAM
Monitor ZAM; Note: For conventional devices requiring
25 VDC power, use Voltage Regulator Module 4100-5130 for
4090-5205
4100ES/4100U or 4010-9916 for 4010ES fire alarm control
panels
4090-5206 Line Isolator Module
4090-5213 Addressable Module Cover
Device Accessories and Service Tools
Model Description
4100ES/4100U Voltage Regulator Module, 25 VDC nominal; isolated and resettable output; includes earth
4100-5130
detection circuit and trouble relay for status monitoring
4010-9916 Same as above for 4100ES/4100U
516.800.917 MX Sensor Head Removal Tool, ref. MX Model 800RT
516.800.918 MX Service Tool, ref. MX Model 801AP
516.800.922 MX Ancillary Program Lead (Spare)
516.800.923 MX Service Tool Accessory Kit
MX Model Reference
801H
801P
801PH
5B-UL
5BI-UL
802SB
812SB
912SB
6A-5B-UL
–
800F
–
–
MX Model Reference
–
–
CP820
CP830
MX Model Reference
MIM800
CIM800
RIM800
SNM800
DIM800
LIM800
M520
3
Data Sheet Reference
S4098-0045
S4098-0046
Data Sheet Reference
S4099-0003
S4099-0004
Data Sheet Reference
S4090-0012
S4100-0059-4, 3/2012
