- Page 1 TQ Drive System E-BIKE QUICK START GUIDE RYCHLÝ NÁVOD GUÍA DE INICIO RÁPIDO GUIDE DE DÉMARRAGE RAPIDE GUIDA RAPIDA クイックスタートガイド 빠른 시작 가이드 SKRÓCONA INSTRUKCJA OBSŁUGI GUIA RÁPIDO SPRIEVODCA RÝCHLYM ŠTARTOM 快速入门指南...
-
Page 2: Welcome To The Family
Welcome to the family! You’ve made the right decision — get ready for the ride of your life! An electric bicycle (call it an e-bike to sound hip) is like a regular bicycle, but with more pedaling power. A lot more. “Isn’t an e-bike cheating?”... - Page 3 Start your engines! Battery charge remaining Power ON = Hold 1 second Power OFF = Hold 3 seconds NOTE: System will turn off after 5-15 minutes of inactivity. Assistance level There are three assistance levels to give you the right boost at the right time (your bike will have one of the two remote types shown below).
-
Page 4: Display Screens
Display screens There is a lot of data at your fingertips. Scroll through the four screens to learn more about your ride. PRO TIP: While riding, you can also scroll through the screens using the remote (WALK mode must be disabled, see page 7). -
Page 5: Charging The Battery
Charging the battery Bars flash when charging % of battery charged Time until full charge Close the charge port Fully charge the battery cover when not charging. before first use. WARNING: Follow safety guidelines when charging the battery • Only charge the battery with a TQ charger. Using the wrong charger risks the life of the battery and presents a potential fire hazard. -
Page 6: Connect Your Phone
Track your ride, customize your ride feeling (such as adjusting the power of the assistance levels), and much more. Tap your bike Download the Trek Enter the numbers on the (you only have to pair your display into your phone. -
Page 7: Walk Mode
Walk mode Give yourself a little push if you have to walk your bike up a hill. Keep in mind, your gear affects the walk speed and torque. You can enable/disable WALK mode in SETUP mode (see page 7). • High gear — use for flat ground (faster walk speed) •... -
Page 8: Setup Mode
Setup mode You can change a few basic settings in SETUP mode. Enter SETUP mode (hold both buttons for 5 seconds). Kilometers or miles? Press any button on the remote to scroll Beep for through options. notifications? Press to select option. Enable WALK mode? EN-7... -
Page 9: Reset Mode
Press to select option. These settings are RESET: Not RESET: • Bluetooth connections • Bike ID • Motor tune (adjusted in • Speed settings the Trek Connect app) • Odometer • SETUP mode settings • Wheel size • Some system faults EN-8... - Page 10 Care for your battery and e-bike Below are a few special warnings to keep you and your bike safe. Consult the comprehensive e-bike manual at trekbikes.com/manuals for a full list of warnings. Install accessories carefully Consult with a certified e-bike technician before installing accessories. Using the wrong bolt in the wrong place could cause a short circuit in the electrical system and/or damage the battery which might lead to over-heating.
- Page 11 United Kingdom Trek Bicycle Corporation Ltd. 9 Sherbourne Drive, Tilbrook, Milton Keynes, MK7 8HX Tel.: +44 1908 360 140 Australia & New Zealand Trek Australia & New Zealand Customer Service PO Box 1747 Fyshwick, ACT2609 Australia Australia Tel.: +61 2 6173 2400 customerservice_australia@trekbikes.com...
- Page 12 © 2022 Trek Bicycle Corporation...
