Trek 6i, 8i, 9i, 11i Owner's Manual

Bicycle computer
Hide thumbs Also See for 6i, 8i, 9i, 11i:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual , Installation
TREK INCITE
Bicycle Computer Owner's Manual
This manual explains the installation and use of several Trek bicycle computer models:
• Incite 6i
• Incite 9i
Please read this manual carefully and save it for future reference.
If you do not understand the information in this manual, or you have a question about your Incite
computer that this manual does not cover, consult your Trek dealer. If you have a question or problem
that your Trek dealer can't handle, contact us at:
Trek Bicycle Corporation
Attn: Customer Service
801 W. Madison Street
Waterloo, Wisconsin 53594
http://www. trekbikes.com
CONTENTS
Safety and general guidelines............................... i
Functions.............................................................. 1
Installation ........................................................ 2-3
Setting the computer ........................................ 4-7
6i, 8i ................................................................ 4-5
9i, 11i .............................................................. 6-7
Replacing the battery........................................... 8
Troubleshooting and Warranty............................ 9

SAFETY AND GENERAL GUIDELINES

While riding your bicycle, do not stare at the computer for long
periods of time (Figure 1). If you do not watch the road, you
could hit an obstacle, which may cause you to lose control and
fall.
Make sure the computer wire cannot contact the tire or wheel
spokes. The wire could be damaged causing the computer to
malfunction. Also, the wire could get caught, causing you to
lose control and fall.
Incite 8i
Incite 11i
(920) 478-4670
Figure 2- Keep the wire
Figure 1- Watch the road
out of the spokes
when riding.
© Copyright Trek Bicycle Corporation
2004 All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6i, 8i, 9i, 11i and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Trek 6i, 8i, 9i, 11i

Summary of Contents for Trek 6i, 8i, 9i, 11i

  • Page 1: Table Of Contents

    If you do not understand the information in this manual, or you have a question about your Incite computer that this manual does not cover, consult your Trek dealer. If you have a question or problem that your Trek dealer can’t handle, contact us at:...

  • Page 2: Functions

    FUNCTIONS Not all Trek Incite computer models have all these functions. Table 1- Function abbreviations, names and explanations Function Explanation Speed Current speed of the bicycle displayed in miles per hour (MPH) or kilometers per hour (KPH). Highest readings: • 6i, 8i: 107.3mph or 172.7kph •...

  • Page 3: Installation

    • Placing the magnet and sensor(s) on the bike Placing the computer on the handlebar The Trek Incite computer can be mounted on the handlebar or on the stem (Figure To install the computer on the handlebar 1. Determine your bicycle’s handlebar diameter: 22.2mm, 25.4/26.0mm, or 31.8mm.

  • Page 4: Attaching The Computer Wire

    Attaching the computer wire The computer wire is usually longer than needed. Extra wire length can be diverted by wrapping it around the brake housing prior to routing it down the fork blade or down tube (Figure 9). Make sure the computer wire is not pulled tight when the handlebar is turned all the way to either side.

  • Page 5: Set Odometer & Wheel Size

    SETTING THE COMPUTER The computer must be set, or “programmed,” so that it gives its readout in the units preferred by the user, and so that it calculates with the correct wheel size. There are three ways to use the buttons: •...

  • Page 6: Second Wheel Size

    To set Clock 1. Cycle Mode to CLK. 2. Hold Mode. 3. Cycle Set to 12 or 24 hour clock. 4. Push Mode to select clock. 5. Cycle Set to the hour. 6. Push Mode to select. 7. Cycle Set to the minute. 8.

  • Page 7: Incite 9I And 11I Settings

    INCITE 9I AND 11I Setting the 9i and 11i is done by pushing the three buttons in a specific sequence. The button on the side of the computer is the Set button. The two buttons on the bottom are the left and right Mode buttons.

  • Page 8: Setting The Computer

    To set a custom wheel size 1. Cycle Mode to TME. 2. Hold Set. The wheel selection icon appears in the upper left corner. 3. Cycle Set to your preferred wheel. 4. Cycle Mode to the four-digit number. 5. Press Set. 6.

  • Page 9: Changing Functions And Other Normal Use

    CHANGING FUNCTIONS AND OTHER NORMAL USE These are everyday tasks that are not explained elsewhere in the manual. Changing mode Once the computer is programmed and installed, it is very easy to use. To change to different modes (functions), simply press the Mode button(s) at the bottom of the computer. Continue pushing the button until the desired function appears denoted by its three letter abbreviation.

  • Page 10: Limited Warranty

    This warranty covers- Trek Incite computer models 6i, 8i, 9i, and 11i for a period of two years from the date of sale. This warranty does not cover- • Normal wear and tear, including the length of battery life •...
