Summary of Contents for Trek TQ
- Page 1 E-BIKE QUICK START GUIDE...
-
Page 2: Welcome To The Family
IMPORTANT SAFETY INSTRUCTIONS. SAVE THESE INSTRUCTIONS. Welcome to the family! This quick start guide explains the basic operation of the TQ system on your e-bike. For the most up to date information or to view this guide in additional languages, please use the QR codes or links below. - Page 3 A fews things to know about riding your new e-bike 1. Start slow We know — fast is fun. But e-bikes take a bit of getting used to. It may be tempting to ramp your e-bike up to the fastest setting right away, but we recommend taking it nice and easy the first few rides.
- Page 4 ON: Press and release OFF: Press and hold Lights ON|OFF (If connected to the TQ Smart Box) ON|OFF: Press both buttons at the same time Note: If front and/or rear lights are included with your e-bike, they may be pro- grammed to turn ON or OFF when the e-bike is turned ON or OFF.
-
Page 5: Pedal Assistance
Pedal assistance Select an assist mode – – – OFF: Press and hold OFF: Press and hold Assist level on the display Pedal assistance Stops when: • You stop pedaling • You reach the maximum assist speed (Maximum speeds vary by region.) Restarts when: •... -
Page 6: Walk Assistance
Walk assistance Walk assistance provides a little push for those times when you are walking or pushing your bike. Walk assistance is only available on bikes with the TQ remote. WARNING: Walk assistance should only be used when you are walking your bike. - Page 7 Scroll through the screens Press to scroll Battery Distance charge to empty Time to Time to empty empty Distance and Battery charge time to empty and time to empty Current Your effort speed Pedal Average assistance speed Power (Watts) Speed EN-5...
-
Page 8: Charge The Battery
WARNING: Charge the battery properly Refer to the TQ charger manual included with your bike for all charging instructions and safety information. Follow the safety warnings when charging your battery. Failure to follow the warnings may result in serious injury or death. - Page 9 Failure to follow these warnings may result in serious injury or death. WARNING: Install accessories carefully Consult with your Trek-authorized Trek dealer before installing any accessories. Only use the fasteners included with your bicycle or the accessory. Using the wrong bolt in the wrong place could cause a short circuit in the electrical system and/or damage to the battery which might lead to over-heating.
- Page 10 WARNING: Transport your e-bike safely • The TQ drive system adds weight to the bicycle. Overloading a bike car rack can result in death or serious injury. Refer to your bicycle rack manual to be sure it is compatible with your e-bike.
- Page 11 The Trek Central app Everything in the palm of your hand Connect to your e-bike like never before with the Trek Central app. • View your e-bike and ride stats • Plan your route and navigate • Tune your motor •...
-
Page 12: Industrie Canada
Compliance certification INDUSTRIE CANADA HMI Includes ICES Approved Module – IC ID: 8017A-MDBT42 Quad Lock® Charger Models QL-5289 and QL-5290 – IC ID: 27134-QLO IC Caution: This device contains license-exempt transmitter(s) that comply with Innovation, Science and Economic Development Canada’s license-exempt RSS(s). Operation is subject to the following two conditions: (1) this device may not cause interference, (2) this device must accept any interference, including interference that may cause undesired operation of the device. - Page 13 HMI Includes FCC Approved Module – FCC ID: SH6MDBT42 Quad Lock Charger Models QL-5289 and QL-5290 – FCC ID: 2AOU9-QLO This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 14 © 2025 Trek Bicycle Corporation | Rev3...
