Summary of Contents for Trek INCITE 6i

Page 1 TREK INCITE 6i and 8i Bicycle Computer Owner’s Manual This manual explains the instal- lation and use of the Trek Incite 6i and Incite 8i bicycle computer. Please read this manual carefully and save it for future reference. If you do not understand the...
Page 2: Table Of Contents
CONTENTS Safety and general guidelines ...1 Functions ...2 Installation ...4 Placing the computer on the handlebar ...5 Placing the magnet ...7 Attaching the computer wire ...8 Attaching the sensor ...9 Easy setup (ReSet) ...11 ReStart- Getting ready to ride ...17 Additional information ...18 Troubleshooting ...19 Replacing the battery ...20...
Page 3: Safety And General Guidelines
SAfETy ANd gENERAl guIdElINES While riding your bicycle, do not stare at the computer for long periods of time (Figure 1). If you do not watch the road, you could hit an obstacle, which may cause you to lose control and fall.
Page 4: Functions
fuNCTIONS Table - Function abbreviations, names, and explanations function Explanation CLOCK Time of day Displays in hours and minutes, or stopwatch showing seconds. 2-hour with AM/PM or 24-hour format Highest reading: 23:59 (clock) ODOMETER Distance ridden Displays in miles or kilometers. TRP-Trip (since last Restart) TTL- Total since last Reset Highest reading: 99,999...
Page 5 SPEED Always displays Current speed of the bicycle in miles per hour (MH) or kilometers per hour (KMH) AVG- (8i only) Average speed since last Restart, displayed to tenths. MAX- Highest value since last Restart Highest readings: 80.5mph or 29.6kph WHEEL Always displays SELECTION...
Page 6: Installation
INSTAllATION Stem mount Handlebar mount Figure 3- Location on bicycle of sensors and computer Tools needed: • Electrical tape • Slot-type screwdriver • Phillips-type screwdriver • Scissors Installation Speed sensor...
Page 7: Placing The Computer On The Handlebar
Placing the computer on the handlebar The Trek Incite 6i and 8i computer can be mounted on the handlebar or on the stem (Figure 3). To install the computer on handlebar 1. Select the bar clamp that fits your bike.
Page 8 Figure 5- Make sure the com- puter cannot be bounced off. Figure 6- Nylon tie threaded through computer base Installation Check that the computer base cannot be rotated around the handlebar, and that the computer cannot slide backwards on the computer base (Figure 5).
Page 9: Placing The Magnet
The wheel magnet must be aligned so that it passes across the sensor. As the magnet passes the sensor, it must be no further from the sensor than 1 to 3mm (1/32 to 1/8 inch). The wheel magnet has a ‘T’ shaped slot with two configura- tions: round spokes and flat or bladed spokes (Figure 7).
Page 10: Attaching The Computer Wire
Attaching the computer wire The computer wire is usually longer than needed. Extra wire length can be diverted by wrapping it around the brake housing prior to routing it down the fork blade or down tube (Figure 8). Make sure the computer wire is not pulled tight when the handlebar is turned all the way to either side.
Page 11: Attaching The Sensor
Attaching the sensor The magnet must pass across the line on the sensor (Figure 9). To install the sensor 1. Align the sensor with the magnet. 2. Orient the sensor so that the clearance between the sensor and the magnet is between 1 to 3mm.
Page 12 5. Tighten the nylon ties and trim the excess length (Figure 10). Figure 0- Trim excess nylon tie length Installation...
Page 13: Easy Setup (Reset)
You can program the starting values of your computer in a single, easy procedure: • Units • Clock • Wheelsize • Odometer The Units setting tells the computer which conversion to use: metric or SAE (“English”): MH = miles KMH = kilometers You can set the clock for 12 or 24 hour display, which changes how time appears in the afternoon, such as 3PM: 12 hour clock...
Page 14: Using The Buttons
Mode Figure - Buttons on the Incite 6i computer To set the computer, you must buttons in a specific sequence. Easy setup (ReSet) When setting the computer, there are three ways to use the buttons. To help you remember, notice the way each term is underlined.
Page 15: To Set The Computer
6. Push to select. The next digit flashes. 7. Repeat steps 5 and 6 until all digits are selected. The computer returns to the start screen. To set 6i wheel size For 8i, go to page 14, Cycle Mode to TME.
Page 16: To Set 8I Wheel Size
Note: If you want to set a custom wheel size, go to page 24 now. Cycle Mode The Wheel Size changes. Set• 4. Hold to select. The computer returns to current speed. Figure 3- Select wheel screen Easy setup (ReSet) To set 8i wheel size The 8i allows you to use two different wheel sizes.
Page 17: To Select The Wheel For Use
Cycle Mode The wheel size changes. Set• 6. Hold to select. The computer returns to current speed. To set the second wheel size, repeat the instructions, but select the other Wheel Select icon. To select the wheel for use Cycle Mode to TRP Mode...
Page 18: To Set Clock
To set Clock Cycle Mode to CLK (Figure 14). Set• 2. Hold “12” or “24” flashes. Figure 4- CLOCK screen Easy setup (ReSet) Cycle Mode 12 and 24 interchange on the screen. Push Set• to select The clock appears on the screen with the Hour flashing.
Page 19: Restart- Getting Ready To Ride
RESTART- gETTINg REAdy TO RIdE Your computer stores data for two intervals- since last ReSet and since last ReStart. ReSet sets ALL data to zero. ReStart sets only the Trip data to zero. The trip modes include • TRP • TME •...
Page 20: Additional Information
AddITIONAl INfORMATION Changing mode Once the computer is programmed and installed, it is very easy to use. To change to different modes (functions), simply Mode button until the desired function appears, shown by the spelled name of the function. Removing the computer from the computer base The computer is held on its base by a flexible snap.
Page 21: Troubleshooting
The Incite 6i computer is designed to be easy to install and maintain. However, computers occasionally have problems. Table 3 shows some possible problems, causes, and solutions: Table 3- Common problems and solutions Blank screen Computer is in shipping mode. Push a button.
Page 22: Replacing The Battery
REPlACINg ThE BATTERy If the computer is giving erratic information, the computer or hear rate strap battery may be running low on power (normally accompanied by the low battery icon, Figure 15). Replace the batteries whenever the computer malfunctions, or every 6 months.
Page 23 4. Lift the battery cover, exposing the battery. Be careful to avoid losing the rubber O-ring seal. 5. Remove the old battery. It may be possible to shake the battery out. Otherwise, carefully pry the battery up with a thin tool or knife blade. 6.
Page 24: Setting Custom Wheel Size
SETTINg CuSTOM WhEEl SIzE The procedure is almost the same as the basic setup on pages 13-14, except instead of picking a wheel size from the menu, you can program in a 4-digit number. Selecting the custom value 4-digit number There are two methods for selecting the custom wheel size value:...
Page 25 Cycle Mode through the wheel sizes to the 4-digit number Push Set• The left-hand digit flashes. Mode Cycle The right-had digit changes. Push Set• to select. The second digit flashes. 7. Repeat steps 5 and 6 to select all four wheel-size digits. Set•...
Page 26 Figure 8- Measuring rollout for wheel size 3. While you sit on the bike, have the helper roll the bike forward one revolution of the wheel, so that the valve stem is again directly over the floor. 4. Mark the new location of the valve stem. 5.
Page 27: This Warranty Does Not Cover
Trek Bicycle Corporation warrants each new Incite computer against defects in workmanship and materials. This warranty covers Trek Incite computer models 6i, 8i, 9i, 11i, ACH, and ACH Digital for a period of two years from the date of sale. This warranty does not cover •...
