2.2.1.1 DLPC4420AEVM Connectors
Reference Designator
J1
J2
J3
J4
J5
J6
J7
J8
J9
J10
J11
J12
J13
J14
J15
J16
J17
J18
J19
J20
J21
J22
J23
J24
J25
J26
J27
J28
J29
J30
J31
J32
J33
J34
J35
J36
J37
J38
J39
J40
J41
J42
J43
J44
J45
J46
DLPU126 – DECEMBER 2023
Submit Document Feedback
Description
Colorwheel #2 motor drive
Colorwheel #1 motor drive
Lamp Ballast Control
Colorwheel #2 Index Sensor
Colorwheel #1 Index Sensor
Fan #3
Fan #2
Fan #1
V-By-One Input
I2C1 Bus
FE_12V
I2C2 Bus
I2C0 Bus
Blue_LED_EN / Lamp Mode
FAN #6
FAN #5
FAN #4
Keyboard Interface
FPGA Testmux
5 V Fan
FPGA_JTAG
12 V Input
FPGA Testmux
FPGA Testmux
FPGA Test Points
RS_232_M (Primary)
ASIC JTAG
JTAG TDO1/2 Bus Selection
Manual Reset Jumper
Optional DLP1000 #3 Header
HOLD_BL
Vx1 Swap PN
Vx1 Swap Bit Order
LED_EN
RS_232_S (Secondary)
PWM SSI Driver I/F
JTAG Boundary Scan
ADC Sensor Interface
SPI Driver and Control I/F
FAN6_EN
Mini-USB
SM_PIC (Actuator Test Points)
XPR
SSI_TSP
ADC Integrating Sensor Board I/F
D_BLK
Copyright © 2023 Texas Instruments Incorporated
Physical Connection Type
Cable
Cable
Cable
Cable
Cable
Cable
Cable
Cable
Cable
Cable
Jumper (short)
Cable
Cable
Jumper selection
Cable
Cable
Cable
Cable
Header
Cable
Cable
Power (Barrel)
Test Points
Header
Header
Cable
Cable
Jumper selection
Jumper (short)
Cable
Jumper (short)
Jumper (short)
Jumper (short)
Jumper selection
Cable
Cable
Cable
Jumper selection)
Cable
Jumper selection
Cable
Cable
Cable
Test Points
Cable
Cable
DLP ® Display ≥0.47-in Array 4K UHD Evaluation Module
Hardware
