SKY-4001TH
INSTALLATION AND OPERATING INSTRUCTIONS

INTRODUCTION

SKYTECH'S remote control system was developed to provide a safe, reliable and
user-friendly remote control system for gas heating appliances. This all battery system
operates independently of household current. The system operates on radio
frequencies with a non-directional signals. The SKYTECH'S operating range is
approximately 20 feet range. The system operates on one of 256 security codes that
are user programmable; the remote receiver' s code must be matched to that of the
transmitter prior to initial use.
Review THERMO SAFETY SECTION under RECEIVER section. This high
temperature safety feature shuts down the appliance when a potentially unsafe
condition exists.

TRANSMITTER

ON
BUTTON
ON
OFF
SET
OFF
BUTTON
BATTERY
COMPARTMENT
FRONT
ON
OFF
SET
SET
BUTTON
batteries into the battery compartment. (Use
caution that batteries are installed in the proper
BACK
direction)
1
KEY SETINGS
l
2
l
3
l
This remote control SYSTEM
offers the user a battery-operated
remote control that operates most
millivolt gas valves used in some
heater rated gas logs, gas fireplaces
HOUSE
and other gas heating appliances.
CODE
UNIT
The transmitter operates on Lithium
CODE
3V battery.
Before using the transmitter, install
the Lithium 3V transmitter
ON
-Operates unit to on position,
Manually ON.
OFF -Operates unit to off position,
Manually OFF.
SET -Sets temperature in thermo mod.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SKY-4001TH and is the answer not in the manual?

Questions and answers

Summary of Contents for Skytech SKY-4001TH

  • Page 1 SKY-4001TH INSTALLATION AND OPERATING INSTRUCTIONS INTRODUCTION SKYTECH’S remote control system was developed to provide a safe, reliable and user-friendly remote control system for gas heating appliances. This all battery system operates independently of household current. The system operates on radio frequencies with a non-directional signals.
  • Page 2 LCD – Liquid Crystal Display Display Indicates CURRENT room temperature. ℉ OR ℃ Indicates degrees Fahrenheit or Celsius. FLAME/ON Indicates burner/valve in operation. THERMO Indicates remote is in THERMO THERMO operation. OFF Indicates burner/valve is off. Battery Indicates battery power is low. SETTING ℉/℃...
  • Page 3 THERMOSTAT FUNCTION SETTING DESIRED ROOM TEMPERATURE This remote control system can be thermostatically controlled when the transmitter is in the THERMO mode (The word THERMO must be displayed on the screen). To set the THERMO THERMO MODE and DESIRED room temperature, Press the SET key until the LCD screen shows the word THERMO, then the remote is in the thermostatic mode.
  • Page 4 normal operating cycle of an appliance may be 2-4 times per hour depending on how well the room or home is insulated from the cold or drafts. The factory setting for the “swing number” is 1. This represents a temperature variation of +/-1° F (0.5℃) between SET temperature and ROOM temperature, which determines when the fireplace will be activated.
  • Page 5 SKY-4001LCD INSTALLATION AND OPERATING INSTRUCTIONS INTRODUCTION SKYTECH’S remote control system was developed to provide a safe, reliable and user-friendly remote control system for gas heating appliances. This all battery system operates independently of household current. The system operates on radio frequencies with a non-directional signals.
  • Page 6 LCD – Liquid Crystal Display Display Indicates CURRENT room temperature. ℉ OR ℃ Indicates degrees Fahrenheit or Celsius. FLAME/ON Indicates burner/valve in operation. OFF Indicates burner/valve is off. Battery Indicates battery power is low SETTING ℉/℃ SCALE The factory setting for temperature is ℉.
  • Page 7 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
