Skytech SKY-4001 Installation And Operating Instructions

(SKY-4001)
INSTALLATION AND OPERATING INSTRUCTIONS

INTRODUCTION

SKYTECH'S remote control system was developed to provide a safe, reliable and
user-friendly remote control system for gas heating appliances. Its battery operation
allows the system to operate independently of household current. The system operates
on radio frequencies with non-directional signals. The SYSTEM' s operating range is
approximately 20 feet. The system operates on one of 255 security codes programmed
at the factory.

COMPONENTS

WARNING

THE SKYTECH SKY -4001 MUST BE INSTALLED EXACTLY AS OUTLINED IN
THESE INSTRUCTIONS. FOLLOW INSTRUCTIONS CAREFULLY DURING
INSTALLATION. ANY MODIFICATION OF THE SKYTECH SKY -4001 OR ANY
OF ITS COMPONENTS WILL VOID THE WARRANTY AND MAY POSE A FIRE
HAZARD.

TRANSMITTER

ON
OFF
face of the transmitter. When a button on the transmitter is pressed, a signal light on
the transmitter illuminates briefly to verify that a signal has been sent. Upon initial
use, there may be a delay of five seconds before the remote receiver will respond to
the transmitter. This is part of the system' s design. If the signal light does not
illuminate, check the position of the transmitter' s battery.
The transmitter operates on a 3v battery
(included) made specifically for remote
controls and electronic lighters. Before using
the transmitter, remove the insulation tab
protecting one end of the battery in the battery
compartment.
The transmitter has ON and OFF functions that
are activated by pressing either button on the
