- Page 1 001_03 03/2006 Installation, operating and maintenance instructions ELECTRIC COOKERS ACA1001 · ACA1002 ACJ0005 · ACJ0007 ACJ0008 ABJ0003 · ABJ0004 · ABJ1001 ABA1001 · ABA1002 · ABA1003 ACA1004 · ACA1006 ACA1005 ABJ0005 · ABJ0006 ACJ0006 ACA1003 · ACA1010...
- Page 2 INDEX Models and dimensionsi page. Technical data Installation instructions Installation Legal and technical requisites Installation Wiring Unipotential Using the appliance Ignition Cleaning and taking care of the appliance What to do if not using the appliance for a long time What to do if something goes wrong Maintenance WEEE Directive...
- Page 3 Dimensions 6 5 5 6 5 5 ABJ00003 Weight approx.18 kg 6 5 5 6 5 5 ABJ00004 Weight approx.33 kg 001 - 03 - Electric cookers...
- Page 4 Dimensions 7 0 0 7 0 0 ACJ00005 Weight approx.17,5 kg 7 0 0 7 0 0 ACJ00007 Weight approx.30,8 kg 7 0 0 7 0 0 ACJ00008 Weight approx.41 kg 001 - 03 - Electric cookers...
- Page 5 Dimensions ACA10001 7 0 0 7 0 0 Weight approx.52,4 kg ACA10002 7 0 0 7 0 0 Weight approx.89,6 kg 7 0 0 7 0 0 001 - 03 - Electric cookers...
- Page 6 Dimensions ACA10004 7 0 0 7 0 0 Weight approx.115 kg 6 5 5 7 0 0 ABA10001 ACA10006 Weight approx.94 kg Weight approx.119 kg 7 0 0 7 0 0 ACA10005 Weight approx.149 kg 001 - 03 - Electric cookers...
- Page 7 Dimensions 7 0 0 6 5 5 ABJ00005 ACJ00006 Weight approx.21 kg Weight approx.22,3 kg 7 0 0 6 5 5 ABJ00006 Weight approx.39,5 kg 001 - 03 - Electric cookers...
- Page 8 Dimensions ACA10003 Weight approx.51 kg 7 0 0 ACA10010 Weight approx.87,8 kg 7 0 0 001 - 03 - Electric cookers...
- Page 9 Dimensions 6 1 5 6 1 5 6 1 5 ABA10002 Weight aprox.118 kg ABA10003 6 1 5 6 1 5 Weight aprox.139 kg 001 - 03 - Electric cookers...
-
Page 10: Data Of Appliances
CAT/KAT GAS/GAZ II2H3B/P P mbar II2H3+ P mbar Data of appliances II2H3+ P mbar II2L3B/P P mbar 0051 The data plate is located on the front of the appliance and II2ELL3B/P P mbar TIPO/TYPE II2E+3+ P mbar MOD. II2H3B/P P mbar on the control panel. - Page 11 TABLE 1 Plates Plates Oven Oven Power Model Resistance (W) Voltage rating Lead wire / Section square round 2500 W 5900 W 1200 1800 1000 2100 2500 2000 W 2600 W 2600 W 4.6 kW 230 V 3 AC o 400 V 3N AC 4 x 2.5 mm o 5 x 1.5 mm 5.2 kW...
-
Page 12: Installation Instructions
INSTALLATION INSTRUCTIONS Installation Before beginning installation, remove all packaging from the appliance. Some parts are protected with an adhesive Installation, start-up and maintenance should only be car- film which should be carefully removed. ried out by expert personnel. Any remnants of glue should be thoroughly cleaned using All work required to install the appliance should be carried suitable substances such as benzine. -
Page 13: Using The Appliance
USING THE APPLIANCE Position ● corresponds to the fixed “on” setting of the hea- Warning! ting element. - Beware of inexpert handling! - Never leave the hotplates on unused! - Only use flatbottomed pots and pans, and make sure that the diameter of the pan is never smaller than the diameter of the hotplate it is being used on.. - Page 14 Turning the electric oven on and of The required temperature may be chosen by turning knob (Fig. 4) 24: warning light 26 comes on and goes out when the ele- ments are switched on. To turn off the oven, turn the two Select the type of heating required by turning knob 23, knobs to position ●...
-
Page 15: Information To Users
THE 2002/96/EC DIRECTIVE (WEEE): information to users This informational note is meant only for owners of equipment marked with the symbol shown in Fig. A on the adhesive label featuring the techni- cal specifications applied on the actual product (the label also giving the serial number). This symbol indicates that the product is classified, accor- ding to the regulations in force, as an item of electrical and electronic equipment and conforms to EU Directive... -
Page 16: Wiring Diagrams
Wiring diagrams ACA10001 ACJ00005 ABJ00003 2600 w 2000 w 1800 w 1150 w 1200 w 850 w 600 w 300 w 400 w 220 w 270 w 175 w 2 1 3 3 4 2 1 3 3 4 400 V 3N AC L1 L 2 L 3 N Line input terminal board Hotplate commutator... - Page 17 Wiring diagrams ACA10001 ACJ00005 ABJ00003 2600 w 2000 w 1800 w 1150 w 1200 w 850 w 600 w 300 w 400 w 220 w 270 w 175 w 2 1 3 3 4 2 1 3 3 4 230 V 3 AC L1 L 2 L 3 Line input terminal board Hotplate commutator...
- Page 18 Wiring diagrams ACA10002 ACJ00007 ABJ00004 2600 w 2000 w 1800 w 1150 w 1200 w 850 w 600 w 300 w 400 w 220 w 270 w 175 w 2 1 3 3 4 2 1 3 3 4 400 V 3N AC L1 L 2 L 3 N Line input terminal board Hotplate commutator...
- Page 19 Wiring diagrams ACA10002 ACJ00007 ABJ00004 2600 w 2000 w 1800 w 1150 w 1200 w 850 w 600 w 300 w 400 w 220 w 270 w 175 w 2 1 3 3 4 2 1 3 3 4 230 V 3 AC L1 L 2 L 3 Line input terminal board Hotplate commutator...
- Page 20 Wiring diagrams 001 - 03 - Electric cookers...
- Page 21 Wiring diagrams 001 - 03 - Electric cookers...
- Page 22 Wiring diagrams 001 - 03 - Electric cookers...
- Page 23 Wiring diagrams 001 - 03 - Electric cookers...
- Page 24 Wiring diagrams 001 - 03 - Electric cookers...
- Page 25 Wiring diagrams 001 - 03 - Electric cookers...
- Page 26 Wiring diagrams 001 - 03 - Electric cookers...
- Page 27 Wiring diagrams 001 - 03 - Electric cookers...
- Page 28 Wiring diagrams ABJ00005 Plate N 2 Cable color Green Plate N 1 Cable color Residual heat White Cable color pilot lamp Black 400 V 3N AC 50.17 50 55 mA Line input terminal board Energy regulator Pilot lamp Residual heat pilot lamp 1800 W cooking plate front 700/2100 W cooking plate rear 001 - 03 - Electric cookers...
- Page 29 Wiring diagrams ABJ00005 Plate N 2 Cable color Green Plate N 1 Cable color Residual heat White Cable color pilot lamp Black 230 V 3 AC 50.17 50 55 mA Line input terminal board Energy regulator Pilot lamp Residual heat pilot lamp 1800 W cooking plate front 700/2100 W cooking plate rear 001 - 03 - Electric cookers...
- Page 30 Wiring diagrams ABJ00006 Plate N 1 Mamut N 1 Grey Plate N 2 Mamut N 2 Green Plate N 3 Mamut N 3 Plate N 4 Mamut N 4 Purple Residual heat White Mamut N 0 lamp Black 400 V 3N AC 50.17 50.17 P2 5...
- Page 31 Wiring diagrams ABJ00006 Plate N 1 Mamut N 1 Grey Plate N 2 Mamut N 2 Green Plate N 3 Mamut N 3 Plate N 4 Mamut N 4 Purple Residual heat White Mamut N 0 lamp Black 230 V 3 AC 50.17 50.17 P2 5...
- Page 32 Wiring diagrams ACA10003 Terminal 4a Color cables Blue section 1.5 mm ACJ00006 Terminal 4 Color cables White section 1.5 mm Terminal 2 Color cables Red section 1.5 mm Residual heat Color cables Green section 1 mm lamps 400 V 3N AC 50 55 50 55 mA Line arrival terminal board...
- Page 33 Wiring diagrams ACA10003 Terminal 4a Color cables Blue section 1.5 mm ACJ00006 Terminal 4 Color cables White section 1.5 mm Terminal 2 Color cables Red section 1.5 mm Residual heat Color cables Green section 1 mm lamps 230 V 3 AC 50 55 50 55 mA Line arrival terminal board...
- Page 34 Wiring diagrams ACA10010 Terminal 4a Color cables Blue section 1.5 mm Terminal 4 Color cables White section 1.5 mm Terminal 2 Color cables Red section 1.5 mm Residual heat Color cables Green section 1 mm lamps 400 V 3N AC 50 55 50.17 50 55...
- Page 35 Wiring diagrams ACA10010 Terminal 4a Color cables Blue section 1.5 mm Terminal 4 Color cables White section 1.5 mm Terminal 2 Color cables Red section 1.5 mm Residual heat Color cables Green section 1 mm lamps 230 V 3 AC 50 55 50 55 50.17...
- Page 36 Wiring diagrams ACA10004 400 V 3N AC Line imput terminal board Hot plate commutator Switch Thermostat Pilot lamp Pilot lamp (voltage) Hot plate 2600 W Hot plate 2000 W Ceiling element Grill element Floor element Fan element Fan motor 001 - 03 - Electric cookers...
- Page 37 Wiring diagrams ACA10004 230 V 3 AC Line imput terminal board Hot plate commutator Switch Thermostat Pilot lamp Pilot lamp (voltage) Hot plate 2600 W Hot plate 2000 W Ceiling element Grill element Floor element Fan element Fan motor 001 - 03 - Electric cookers...
- Page 38 Wiring diagrams 001 - 03 - Electric cookers...
- Page 39 Wiring diagrams 001 - 03 - Electric cookers...
- Page 40 Wiring diagrams 001 - 03 - Electric cookers...
- Page 41 Wiring diagrams 001 - 03 - Electric cookers...
- Page 42 Wiring diagrams ACA10005 ABA10003 400 V 3N AC Line input terminal board Hot plate commutator Switch Thermostat Pilota lamp Pilota lamp (voltage) Hot plate 2600 W Hot plate 2000 W Ceiling element Grill element Floor element Fan element Fan motor 001 - 03 - Electric cookers...
- Page 43 Wiring diagrams ACA10005 ABA10003 230 V 3 AC Line input terminal board Hot plate commutator Switch Thermostat Pilota lamp Pilota lamp (voltage) Hot plate 2600 W Hot plate 2000 W Ceiling element Grill element Floor element Fan element Fan motor 001 - 03 - Electric cookers...
- Page 44 Wiring diagrams L 2 L 3 400 V 3N ~ 8.48 A R1/R2 L1 L 2 L 3 230 V 3 ~ 14.75 A Connected power: 5.9 kW 230/400 Terminal Switch Selector Thermostat Indicator light (power) Indicator light (heating) R1-2 Oven heating element Temperature limiter 001 - 03 - Electric cookers...
- Page 45 Wiring diagrams L 2 L 3 400 V 3N ~ 8.48 A R1/R2 L1 L 2 L 3 230 V 3 ~ 14.75 A Connected power: 5.9 kW 230/400 Terminal Switch Selector Thermostat Indicator light (power) Indicator light (heating) R1-2 Oven heating element Temperature limiter 001 - 03 - Electric cookers...
- Page 46 Wiring diagrams L1 L 2 L 3 N 400 V 3N AC(22,8 A) L1 L 2 L 3 230 V 3 AC(41 A) ABA10001 2000 w 1150 w 850 w 300 w 220 w 175 w mA Borne llegada línea Conmutador placa Conmutador horno Termostato horno...
- Page 47 WARNING DUE TO ITS POLICY OF CONTINUAL PRODUCT IMPRO- VEMENT, THE MANUFACTURER RESERVES THE RIGHT TO MAKE ANY CHANGES DEEMED NECESSARY. THE MANUFACTURER CANNOT BE HELD RESPONSI- BLE IF THE INSTRUCTIONS CONTAINED IN THIS MA- NUAL ARE NOT OBSERVED. THIS DOCUMENTATION IS ONLY INTENDED FOR QUALIFIED TECHNICIANS WHO ARE AWARE OF THE RESPECTIVE SAFETY REGULATIONS.
