- Page 1 016_03 07/2004 Installation, operating and maintenance instructions ELECTRIC COOKERS ADA1001 ADA1002 ADA1003 · ADA1004 ADA1005 · ADA1006...
- Page 2 INDEX Models and dimensions Cleaning and taking care of the page appliance page Technical data What to do if not using the appliance for a long time Installation instructions What to do if something goes wrong Installation Legal and technical requisites Installation Maintenance Wiring...
- Page 3 Dimensions ADA10001 ADA10003 400 x 900 x 875 800 x 900 x 875 63 kg 111 kg Weight approx. Weight approx. 1200 x 900 x 875 131 kg Weight approx. ADA10004 ADA10006 800 x 900 x 875 1200 x 900 x 875 138 kg 168 kg Weight approx.
-
Page 4: Technical Data
2 - CHARACTERISTICS OF THE APPLIANCES The data plate is located on the rigth hand side of the CAT/KAT GAS/GAZ II2H3B/P P mbar control panel and contains all the data needed for connecting II2H3+ P mbar II2H3+ P mbar II2L3B/P P mbar it up to the mains electricity supply. -
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS Warning! Before beginning installation, remove all packaging from the appliance. Some parts are protected with an adhesive In compliance with international regulations, when film which should be carefully removed. connecting the appliance to the mains power supply, a Any remnants of glue should be thoroughly cleaned using device with a minimum aperture of 3 mm between con- suitable substances such as benzine. -
Page 6: Appliance
6 to begin cooking max. 5/10 min; Daily cleaning means better performance and a longer useful life. 5 for high temperature cooking; Before starting to clean the appliance, disconnect from the mains.** 4 for medium temperature cooking; Remove all the extractable parts from the oven and wash separately. -
Page 7: Wiring Diagrams
Wiring diagrams ADA10001 3000 w 2250 w 1500 w 750 w 500 w 300 w 2 1 3 3 4 230 V 3~ 26,7 A 230 V ~ 26,7 A 400 V 3N~ 15,3 A L 1 L 2 N Line input terminal board Hotplate commutator Pilot lamp... - Page 8 Wiring diagrams ADA10003 4000 w 3000 w 2500 w 2250 w 1500 w 1500 w 1000 w 750 w 600 w 500 w 430 w 300 w 2 1 3 3 4 400 V 3N~ 22,9 A L1 L 2 L 3 N L1 L 2 L 3 230 V 3~ 38,2 A Line input terminal board...
- Page 9 Wiring diagrams 016 -- 03...
- Page 10 Wiring diagrams 016 -- 03...
-
Page 11: Wiring Diagrams
Wiring diagrams 016 -- 03... - Page 12 Wiring diagrams Terminal 4a Color cables Blue section 1.5 mm Terminal 4 Color cables White section 1.5 mm Terminal 2 Color cables Red section 1.5 mm Residual heat Color cables Green section 1 mm lamps 400 V 3N AC 50.17 50 55 SPIA SPIA...
- Page 13 Wiring diagrams Terminal 4a Color cables Blue section 1.5 mm Terminal 4 Color cables White section 1.5 mm Terminal 2 Color cables Red section 1.5 mm Residual heat Color cables Green section 1 mm lamps 230 V 3 AC 50 55 50.17 SPIA SPIA...
- Page 14 Wiring diagrams Terminal 4a Color cables Blue section 1.5 mm Terminal 4 Color cables White section 1.5 mm Terminal 2 Color cables Red section 1.5 mm Residual heat Color cables Green section 1 mm lamps 400 V 3N AC 50 55 50.17 50 55 50.17...
- Page 15 Wiring diagrams Terminal 4a Color cables Blue section 1.5 mm Terminal 4 Color cables White section 1.5 mm Terminal 2 Color cables Red section 1.5 mm Residual heat Color cables Green section 1 mm lamps 230 V 3 AC 50 55 50.17 50 55 50.17...
- Page 16 WARNING THE MANUFACTURER CANNOT BE HELD RESPONSIBLE FOR ANY INACCURACIES IN THIS BOOKLET DUE TO COPYING OR PRINTING ERRORS. DUE TO ITS POLICY OF CONTINUAL PRODUCT IMPRO- VEMENT, THE MANUFACTURER RESERVES THE RIGHT TO MAKE ANY CHANGES DEEMED NECESSARY. THE MANUFACTURER CANNOT BE HELD RESPONSI- BLE IF THE INSTRUCTIONS CONTAINED IN THIS MA- NUAL ARE NOT OBSERVED.
